Please note
-
this Instruction Manual contains important safety information. Please
make sure that you read it before using your Washing Machine for the first time. It also
contains valuable Troubleshooting tips so that you can solve faults without having to call
for a service engineer.
Instruction Manual for your Baumatic
BFW1000W
FULLY ELECTRONIC
WASHING MACHINE
Please note
: for fast access to using your
Washing Machine, please look at the bold-font
items listed on the Contents page (page 3).
DD 13/02/07
1
Advertisement
Table of Contents
Related Manuals for Baumatic BFW1000W
Summary of Contents for Baumatic BFW1000W
- Page 1 Washing Machine for the first time. It also contains valuable Troubleshooting tips so that you can solve faults without having to call for a service engineer. Instruction Manual for your Baumatic BFW1000W FULLY ELECTRONIC...
-
Page 3: Table Of Contents
CONTENTS Important Safety Information……………………………………………………………….….4 Your Washing Machine’s Control Panel………………………………..…….……...….5 Start / Pause Button………………………………………………………..………………………..5 Function Indicator Lights…………………………………………………….…………………..…5 Function Buttons……………………………………………………………………………………..…6 Easy Iron Function …………………………………………………………….………………………..6 Washing Your Laundry…………………………..…………………………………..……………..7 Before Loading Your Washing Machine………………………………………………..…..7 Washing Labels and their Meanings…………………………………………………………..…8 Loading Your Washing Machine……………….………………………………………………..9 Filling Your Washing Machine’s Dispenser Drawer with Detergent……9-10 Running Your Washing Machine……………………………………………………………...11 Using the Program Knob………………………………………………………………………..…11 Washing Tables……………………………………………………………………………………..12-13... -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING: THIS IS IMPORTANT SAFETY INFORMATION. PLEASE READ THIS BEFORE USING YOUR WASHING MACHINE. DO NOT USE AN EXTENSION CORD OR PLUG INTO A MULTIPLE SOCKET. DO NOT INSERT A PLUG WITH A DAMAGED CORD OR THAT IS BROKEN INTO THE SOCKET. -
Page 5: Your Washing Machine's Control Panel
Your Washing Machine’s Control Panel *NOTE: Your Washing Machine has soft-touch buttons. You only need to press these lightly to operate your machine. You need to make sure that the program knob has been brought fully to the STOP position before selecting a new program or changing between programs. Function indicator lights When the ‘START/PAUSE’... -
Page 6: Function Buttons
Function Buttons Rinse Hold * NOTE: This function should be used when you’re not going to be taking your clothes out of your washing machine immediately after the end of a program. This will keep wrinkles from appearing, as when the button is pressed, the last rinsing water is not drained. -
Page 7: Washing Your Laundry
Washing your laundry NOTE: (*VERY IMPORTANT*) – You must ensure that the transportation bolts have been removed before you attempt to use your Washing Machine. See pages 27-29. Only once you are sure this has been done, can you do the following: 1) Plug in you machine 2) Turn on the water supply Note on using your Washing Machine for the... -
Page 8: Washing Labels And Their Meanings
• REMEMBER TO READ THE LABELS ON YOUR CLOTHES BEFORE ATTEMPTING TO WASH THEM: WASHING LABELS & THEIR MEANINGS... -
Page 9: Loading Your Washing Machine
Loading your Washing Machine Open the door of your washing machine. Load your clothes inside the drum one item at a time and spread them about well. When you shut the door of your machine, be careful that no pieces of clothing are jammed between the door and the gasket seal. - Page 10 *NOTE: Only use detergents for automatic washing machines. The amount that you will need for different washing loads and types will be written on the packaging of your detergent. The harder the water in your area, the more detergent you will need to use. SOFTENERS Fill the softener compartment in your detergent drawer with softener.
-
Page 11: Running Your Washing Machine
Running your Washing Machine Program Selection and Features Select the program that’s right for the clothes you want to wash according to the Table on the next page. THE PROGRAM KNOB With the program knob, you can select the program you’d like to wash your clothes with. -
Page 12: Washing Tables
WASHING TABLES – PLEASE FIND THE TYPE OF WASHING YOU WANT TO PUT INTO YOUR WASHING MACHINE AND CHECK IT AGAINST THE MAXIMUM WEIGHT ALLOWED. ADDITIONAL DETERGENT TYPE OF EXAMPLE OF PROGRAM FUNCTION COMPART- LOAD LAUNDRY CLOTHES MENT BUTTON (Kg) Dirty, boil, cotton &... - Page 13 ADDITIONAL DETERGENT TYPE OF EXAMPLE OF PROGRAM FUNCTION COMPART- LOAD LAUNDRY CLOTHES MENT BUTTON (Kg) Nylon socks, Dirty, synthetic or synthetic mixture blouses. All baby laundry Baby laundry Slightly dirty, synth- Nylon socks, thetic or synthetic blouses mixture Sport clothes Sports clothes/ Jeans Slightly dirty,...
-
Page 14: Starting A Washing Program
Starting a Washing Program • Adjust the program knob to a program you desire (see previous page) o The ‘PROGRAM READY’ light will come on. o If you want, you can select one or more additional functions. • Run the program which you have selected by pressing the ‘START/PAUSE’... -
Page 15: Child Lock
*Note when the washing cycle has ended, you will not be able to open the door right away. It will unlock approximately two minutes after the program ends. You can then open the door by pulling the handle of the door towards yourself. -
Page 16: Maintenance & Cleaning
MAINTENANCE AND CLEANING: Please note: Before attempting any kind of maintenance or cleaning on your washing machine: Unplug your machine Close the Water Tap WATER INLET FILTERS On the tap part of your machine’s water inlet hose and the ends of the water inlet valves, there are filters to prevent dirt and foreign materials from getting into the water. - Page 17 Remove the kick-plate by pushing it upwards with your hands away from the lower securing claws and pulling it towards yourself. Before opening the filter cover, place a cup in front of the filter cover to prevent flow of the remaining water in the machine. Loosen the filter cover by rotating it anti-clockwise and drain the water.
-
Page 18: Cleaning The Detergent Drawer
Cleaning the Detergent Drawer DETERGENT DRAWER Detergents may form sediment in your detergent drawer or in the housing of the detergent drawer over time. • To clean the sediment, pull out the detergent drawer from time to time. To pull out the detergent drawer •... -
Page 19: Cleaning The Cabinet
Cleaning the Cabinet Clean the exterior surface of your machine with lukewarm water and a cleaning substance that will not harm or scratch the cabinet. After rinsing with clean water, wipe it with a soft and dry cloth. PLEASE NOTE: If your washing machine is installed in a location where the ambient temperature can fall below 0 C, do °... -
Page 20: Notes On Stains And How To Remove Them From Your Clothes
NOTES ON STAINS AND HOW TO REMOVE THEM FROM YOUR CLOTHES... -
Page 21: Notes On Stains And How To Remove Them From Your Clothes
NOTES ON STAINS AND HOW TO REMOVE THEM FROM YOUR CLOTHES... -
Page 22: Troubleshooting
TROUBLESHOOTING – Should your washing machine have a problem, checking the problem against this chart may keep you from needing to call for service! PROBLEM PROBABLE CAUSE WHAT YOU CAN DO It is unplugged Insert the plug into the socket. Your fuse is defective. - Page 23 PROBLEM PROBABLE CAUSE WHAT YOU CAN DO You haven’t put enough You Washing machine’s clothes in the drum operation is unaffected. Don’t put too many clothes Your Washing You have put too many in the machine. Machine is clothes in the drum Spread your clothes more vibrating evenly.
- Page 24 PROBLEM PROBABLE CAUSE WHAT YOU CAN DO The Water drains from your Washing The end of the water drain Place the water drain hose at a Machine as hose is in too low a better height. soon as it has position for the machine.
-
Page 25: Error Codes
ERROR CODES Error Failure Probable Failure What Needs Doing Code Indicator Shut the door properly so that it ‘clicks’. If there is The ‘START/ The door is not still a problem, turn off Err 01 PAUSE’ shut properly. the machine, unplug and light blinks call the nearest authorized service centre immediately. - Page 26 Error Failure Probable Failure What Needs Doing Code Indicator The START/ Shut down your machine and PAUSE light The Heater in your unplug. Turn off your tape and Err 05 and PROGRAM machine or the heat report it to the nearest END lights are sensor has failed.
-
Page 27: Installation Instructions
INSTALLATION INSTRUCTIONS 1) REMOVING THE TRANSPORTATION SCREWS: * PLEASE NOTE THAT FAILURE TO REMOVE THE TRANSPORTATION SCREWS WILL RESULT IN YOUR GUARANTEE BECOMING VOID! * o THE TRANSPORTATION SCREWS, WHICH CAN BE FOUND AT THE REAR OF YOUR WASHING MACHINE, MUST BE TAKEN OFF BEFORE YOU CAN USE YOUR MACHINE. -
Page 28: Electrical Connection
*WARNING! (PLEASE NOTE) Baumatic Ltd are not responsible for any damages arising out of usage following failure to earth (ground) your appliance. CONNECTING TO THE WATER MAINS •... - Page 29 PLEASE NOTE:...
-
Page 30: Directive Conformity Confirmation
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 31: Conditions Of Guarantee
Baumatic appliance. * In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fitted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date. - Page 32 Headquarters Baumatic Ltd. Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX, United Kingdom Sales Telephone +44 118 933 6900 Sales Fax +44 118 931 0035 Service Telephone +44 118 933 6911 Service Fax +44 118 986 9124 Spares Telephone...
