- Page 1 Screwdriver MODEL 6802BV 004201 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
SPECIFICATIONS Model 6802BV Capacities Self drilling screw 6 mm (1/4”) Bit shank size 1/4” Hex No load speed (RPM) 0 - 2,500/min. Overall length 265 mm (10-1/2”) Net weight 1.7 kg (3.7lbs) • Manufacturer reserves the right to change specifications without notice. •... -
Page 3: Personal Safety
5. Avoid body contact with grounded sur- 14. Use safety equipment. Always wear eye faces such as pipes, radiators, ranges and protection. Dust mask, non-skid safety refrigerators. There is an increased risk of shoes, hard hat, or hearing protection must electric shock if your body is grounded. -
Page 4: Specific Safety Rules
SERVICE 24. When servicing a tool, use only identical replacement parts. Follow instructions in 23. Tool service must be performed only by the Maintenance section of this manual. qualified repair personnel. Service or main- Use of unauthorized parts or failure to follow tenance performed by unqualified personnel Maintenance instructions may create a risk of could result in a risk of injury. - Page 5 SAVE THESE INSTRUCTIONS WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury. SYMBOLS USD201-2 The followings show the symbols used for tool. V ....... volts ....no load speed ˚ A ....... amperes ....Class II Construction Hz .....
-
Page 6: Functional Description
FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Depth adjustment 004146 Pull the locking sleeve forward and then turn it to adjust the depth. Initially, adjust the locator assembly to create a dis- tance of approximately 0.5 mm from the tip of the locator to the tip of the socket bit. - Page 7 NOTE: • Even with the switch on and motor running, the bit will not rotate until you fit the point of the bit in the screw head and apply forward pressure to engage the clutch. Reversing switch action 004159 This tool has a reversing switch to change the direction of rotation.
-
Page 8: Operation
OPERATION Fit the screw on the point of the bit and place the point of the screw on the surface of the workpiece to be fastened. Apply pressure to the tool and start it. Withdraw the tool as soon as the clutch cuts in. -
Page 9: Maintenance
CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 10 Memo...
- Page 11 Memo...
- Page 12 Memo...
- Page 13 Stamp Timbre Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold...
- Page 14 Your answers to the following questions are appreciated. 1. This product was purchased from? 3. How did you first learn of Makita Power Tools? Hardware/lumber Store Industrial Supply Magazine/Newspaper Catalog Tool Distributor Other ( From dealer Other ( Store display 2.
- Page 15 When you need service... DATE • Explain the problem in a letter PURCHASED: • Enclose the letter with the tool DEALER’S NAME • Package carefully and send prepaid & ADDRESS: to the nearest Makita factory or authorized service centre MODEL NO.: SERIAL NO.:...
- Page 16 WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
