For instructions on configuration, please see your User's Manual.

Rev. dwl.120.2k-12-18-00,10am

1 1

Insert DWL-650 Driver CD

With the laptop turned ON, insert

the driver CD for the DWL-650 Wireless PC

Adapter into the CD-ROM.

The driver CD will automatically load.

Click the "Install Drivers" button.

2 2

Installing the Drivers

The following "Welcome" screen will be

displayed.

Click Next.

Rev. dwl.120.2k-12-18-00,10am

Quick Install Guide

for Windows 2000

DWL-650

11 Mbps Wireless PC Card Adapter

Page 1 Quick Install Guide Quick Install Guide For instructions on configuration, please see your User’s Manual. for Windows 2000 for Windows 2000 DWL-650 11 Mbps Wireless PC Card Adapter Insert DWL-650 Driver CD Insert DWL-650 Driver CD With the laptop turned ON, insert the driver CD for the DWL-650 Wireless PC Adapter into the CD-ROM.
Page 2 Installing the Drivers Installing the Drivers continued continued Then the “Software License Agreement” will be displayed. Click Yes to accept. The next screen will prompt for the System ID. The word “default” will be displayed in the text box. Type in the desired name of the System ID in the provided text box.
Page 3 At the following window, Finish Installation Finish Installation select “CD-ROM drives”. Click Next to continue. Windows will recognize new hardware. At the next window, Click Next to continue. At the “Welcome” screen, Click Next to continue. The following screen will only appear at initial installation.
Page 4 Installing the Drivers Installing the Drivers continued continued The next screen will appear. Click Next Windows will then load the system files. After the system files are loaded, Windows will prompt to restart the computer. Click Finish Installing DWL-650 Installing DWL-650 Wireless PC CARD Wireless PC CARD After the computer reboots if the...
