- Page 1 BASIC SERIAL COMMAND SPECIFICATIONS PDG-DXL2000 Ver.1.00 SANYO Electric Co., Ltd DS Company Projector Division...
-
Page 2: Table Of Contents
PDG-DXL2000 Basic Serial Command Specifications ÿ CONTENTS ÿ Overview .........................4 Serial Interface Specifications..................4 2.1. Transfer Specifications ..................4 2.2. Connection ......................4 Notes for Communication .....................5 Functional Execution Command Table................6 Status Read Command Table..................8 Functional Execution Command ..................9 6.1. Format ........................9 6.2. Command Pipelining ....................9 6.3. - Page 3 PDG-DXL2000 Basic Serial Command Specifications 6.32. BRIGHTNESS – Command...................15 6.33. IMAGE (Toggle) Command...................16 6.34. Direct on Setting Command ................16 6.35. Direct on Cancel Command.................16 6.36. Power Management Ready Command ...............16 6.37. Power Management OFF Command ..............16 6.38. Power Management Shut down Command............16 6.39.
-
Page 4: Overview
PDG-DXL2000 Basic Serial Command Specifications 1. Overview 1.1. These specifications define projector control commands for PDG-DXL2000. 1.2. The projector control commands are used to remotely control a projector through RS-232C from a computer. 2. Serial Interface Specifications 2.1. Transfer Specifications Item Specifications Synchronous system... -
Page 5: Notes For Communication
PDG-DXL2000 Basic Serial Command Specifications Notes for Communication The projector control command is defined as one command/one line that starts with “C” and ends with carriage return (0x0D). There are two types of Commands: Functional Execution Commands and Status Read Commands. -
Page 6: Functional Execution Command Table
PDG-DXL2000 Basic Serial Command Specifications Functional Execution Command Table Command Item Command Item POWER ON BRIGHTNESS + POWER OFF BRIGHTNESS - (Quick Power OFF) ――― POWER OFF ――― ――― ――― HDMI ――― Computer 1 ――― Computer 2 Video IMAGE (Toggle) ―――... - Page 7 PDG-DXL2000 Basic Serial Command Specifications Command Item Command Item ――― ――― ――― ――― ――― ――― ――― FREEZE ON ――― FREEZE OFF ――― ――― ――― ZOOM - ――― ZOOM + ――― ――― ――― Auto PC ADJ. ――― PRESENTATION TIMER ――― ――― ―――...
-
Page 8: Status Read Command Table
PDG-DXL2000 Basic Serial Command Specifications Status Read Command Table Command Item Memo Status Read Input Mode Read ――― (Corresponding) Lamp Time Read Setting Read ――― Temp Read Lamp Mode Read ――― means no function. 8/25... -
Page 9: Functional Execution Command
PDG-DXL2000 Basic Serial Command Specifications Functional Execution Command 6.1. Format 6.1.1 PC issues a command in format as below. “C” COMMAND [CR] Command: two characters (See Basic Functional Execution Command Table) A projector changes received data to decode and returns a result after being ready to receive next command. -
Page 10: Operation Requirements
PDG-DXL2000 Basic Serial Command Specifications 6.4. Operation Requirements 1) When the projector’s status is any of below, Functional Execution Commands are limited. Projector Status Available Functional Execution Commands In standby status C00ÿ POWER ON C00ÿ POWER ON → Countdown is terminated Countdown in process C01ÿ... -
Page 11: Power On Command
PDG-DXL2000 Basic Serial Command Specifications 6.5. POWER ON Command Command “C00” [CR] Power ON When already Power is ON, nothing is done. Detail When sending this command during processing Countdown, Countdown is terminated. Acceptable [ACK] [CR] Response Unacceptable “ÿ ”[CR] 6.6. -
Page 12: Computer 2 Command
PDG-DXL2000 Basic Serial Command Specifications 6.10. Computer 2 Command Command “C06” [CR] Select Computer2 Input Although projector returns “OK”, Input search is not executed with this command while Input search is set to On1/On2. Detail Note) When “Monitor out” is selected in Terminal menu, projector returns “OK”... -
Page 13: Audio Mute Off Command
PDG-DXL2000 Basic Serial Command Specifications 6.15. AUDIO MUTE OFF Command Command “C0C” [CR] Sound Mute OFF. Detail This command works the same as “MUTE” button of the remote control for Mute OFF, but does not work for Mute ON. Acceptable [ACK] [CR] Response Unacceptable... -
Page 14: Image Real Command
PDG-DXL2000 Basic Serial Command Specifications 6.21. Image Real Command Command “C12” [CR] Detail Set image to Real mode. Acceptable [ACK] [CR] Response Unacceptable “ÿ ”[CR] 6.22. Image Cinema Command Command “C13” [CR] Detail Set image to Cinema mode. Acceptable [ACK] [CR] Response Unacceptable “ÿ... -
Page 15: Menu On Command
PDG-DXL2000 Basic Serial Command Specifications 6.28. MENU ON Command Command “C1C” [CR] Detail Display On-Screen Display Menu. Acceptable [ACK] [CR] Response Unacceptable “ÿ ”[CR] 6.29. MENU OFF Command Command “C1D” [CR] Detail Hide On-Screen Display Menu. Acceptable [ACK] [CR] Response Unacceptable “ÿ... -
Page 16: Image (Toggle) Command
PDG-DXL2000 Basic Serial Command Specifications 6.33. IMAGE (Toggle) Command Command “C27”[CR] Switch Image Setting status. Detail This command works the same as “IMAGE” button of the remote control. Acceptable [ACK] [CR] Response Unacceptable “ÿ ”[CR] 6.34. Direct on Setting Command Command “C28”... -
Page 17: D.zoom + Command
PDG-DXL2000 Basic Serial Command Specifications 6.39. D.ZOOM + Command Command “C30” [CR] Enter Digital Zoom mode and expand image size. Detail This command works the same as “D.ZOOM ▲” button of the remote control. Acceptable [ACK] [CR] Response Unacceptable “ÿ ”[CR] 6.40. -
Page 18: Pointer Down Command
PDG-DXL2000 Basic Serial Command Specifications 6.45. POINTER DOWN Command Command “C3D” [CR] Move down the Pointer of On-Screen Display Menu. Detail This command works the same as the pointer “▼” of the projector and the remote control. Acceptable [ACK] [CR] Response Unacceptable “ÿ... -
Page 19: Computer 1 Analog Rgb Command
PDG-DXL2000 Basic Serial Command Specifications Unacceptable “ÿ ”[CR] 6.51. Computer 1 Analog RGB Command Command “C50” [CR] Select Analog RGB in Computer 1 input. Detail Although projector returns “OK”, Input search is not executed with this command while Input search is set to On1/On2. Acceptable [ACK] [CR] Response... -
Page 20: Keystone ! " Command
PDG-DXL2000 Basic Serial Command Specifications Detail Correct keystone distortion by reducing upper part of image. Acceptable [ACK] [CR] Response Unacceptable “ÿ ”[CR] 6.57. KEYSTONE ↓Command Command “C8F” [CR] Detail Correct keystone distortion by reducing down part of image. Acceptable [ACK] [CR] Response Unacceptable “ÿ... -
Page 21: Status Read Command
PDG-DXL2000 Basic Serial Command Specifications 7. Status Read Command 7.1. Format 7.1.1. PC issues commands in format as below; “CR” Command [CR] Commandÿ 1 character(See Basic Status Read Command Table) 7.1.2. When a projector receives the appropriate command, it returns a character line as the required data. -
Page 22: Status Read Command
PDG-DXL2000 Basic Serial Command Specifications 7.4. Status Read Command Command “CR0” [CR] Detail Get the projector’s operating status Acceptable “%1” [CR] ”00” = Power ON “80” = Standby “40” = Countdown in process “20” = Cooling Down in process “10” = Power Failure “28”... - Page 23 PDG-DXL2000 Basic Serial Command Specifications moves to Power OFF status due to power failure. Fan also stops unlike Cooling Down status. “28” [CR] Status: Cooling Down in process due to Temperature Anomaly When the inside temperature is out of the operating temperature, it automatically starts Cooling Down.
-
Page 24: Input Mode Read Command
PDG-DXL2000 Basic Serial Command Specifications 7.5. Input Mode Read Command Command “CR1” [CR] Detail Get the selected Input No. Acceptable “%1” [CR] ”1” = Computer 1 is selected ”2” = Computer 2 is selected Response “3” = HDMI is selected “4”... -
Page 25: Lamp Mode Read Command
PDG-DXL2000 Basic Serial Command Specifications 7.9. Lamp Mode Read Command Command “CR7” [CR] Get lamp mode status. Detail For 1 lamp projector, get if it is lighting or not. Acceptable “%1” [CR] “00” [CR]=Light is out. Response “01” [CR]=Light is on. Unacceptable “ÿ...
