Cabling the CSS 11503 and CSS 11506 Modules
The 1000BASE-T SFP GBIC on a CSS supports 1000 Mbps full-duplex operation
only and uses standard four twisted-pair, Category 5e cable at lengths up to
328.08 ft. (100 m).
The GEM front panel LEDs indicate the network status for each of the connectors
(Link LEDs).
Figure 2-7
1
2
3
Cisco 11500 Series Content Services Switch Hardware Installation Guide
2-18
Figure 2-7
Gigabit Ethernet Module Connectors and LEDs
3
2
4
ST AT US
1
GE 1
LI NK
GE 2
Bicolor status LED (green and
red)
Amber status LED
SFP GBIC (one of two)
Chapter 2
illustrates the LEDs and connectors on a GEM.
4
5
LI NK
6
4 Link LED (next to its
corresponding SFP GBIC)
5 Spring-loaded screw (one of two)
6
Ejector (one of two)
Cabling and Troubleshooting the CSS
