Chapter 8 Online Insertion and Removal for Switch Fabric Cards
DETAILED STEPS
Command or Action
Step 1 show platform
Example:
RP/0/RP0/CPU0:router# show platform
Step 2 admin configure
Example:
RP/0/RP0/CPU0:router# admin configure
Step 3
show controller fabric plane all
Example:
RP/0/RP0/CPU0:router(admin-config)# show
controller fabric plane all
Step 4 controller fabric plane plane_number shut
Example:
RP/0/RP0/CPU0:router(admin-config)#
controller fabric plane 1 shut
Step 5
show controller fabric plane all
Example:
RP/0/RP0/CPU0:router(admin-config)# show
controller fabric plane all
Step 6 no hw-module node fabric-card power
Example:
RP/0/RP0/CPU0:router(config)# no hw-module
node 0/SM1/SP power
Step 7
commit
Example:
RP/0/RP0/CPU0:router(config)# commit
Purpose
Displays all cards on the router.
Allows you to identify a fabric card (identified with a SM
•
prefix).
The number following the SM prefix identifies the
•
corresponding fabric plane, as follows:
Fabric Fabric
–
Board
SM0
–
SM1
–
– SM2
Enters admin configuration mode.
Displays the status of each fabric plane.
Shuts down the fabric plane.
Displays the status of each fabric plane.
The down flag of the show controller fabric plane
•
command display should read P, which indicates that the
down flag has been administratively shut down.
Shuts down the fabric card.
The down flag of the show controller fabric plane
•
command display should read pPm.
Commits the target configuration to the router running
configuration.
Cisco CRS-1 Series Carrier Routing System Getting Started Guide
Performing an OIR
#
0
1
2
8-3
