D-Link DCS-3710 Specifications

Product Highlights
1.3 Megapixel Resolution
HD-720p high resolution video ensures that you capture
the details that you need
Wide Dynamic Range (WDR)
Wide Dynamic Range technology neutralizes imperfect
lighting, providing clear images with the right amount of
contrast even when a subject is backlit
High-Quality Video Feeds
Real-time video compression with H.264, MPEG-4, and
MJPEG codecs
DCS-3710
HD Day & Night WDR Network Camera
Features
• Sony Exmor 1/3" 1.3 Megapixel WDR CMOS
Sensor
• WDR for high contrast scenes
• Real-time H.264, MPEG-4 and Motion JPEG
compression
• HD resolution up to 1.3M (1280x1024)
• DC iris varifocal 2.9 mm (W) to 8.2 mm (T)
f1.0 CS mount lens
• Built-in mechanical IR-cut filter for day/
night surveillance
• Simultaneous multi-stream support
• ePTZ
• Supports multiple access lists
• Privacy Mask feature
• SD Card slot
• 2-way audio support
• 2 alarm inputs / 1 alarm output
• Power over Ethernet (PoE)
• 3GPP mobile surveillance
• Built-in Samba client for NAS
• ONVIF-Compliant
High Resolution Surveillance
The D-Link DCS-3710 is a high-end HD Day & Night WDR Network Camera, equipped with a
1/3" Megapixel WDR Progressive Scan CMOS sensor and a 2.9-8.2 mm DC auto iris lens. The
DCS-3710 captures video in both dark and light environments, and even subjects shot with
backlighting by neutralizing imperfect lighting and generating a realistic image. In addition,
the removable IR-cut filter for day/night functionality provides clear detail and high quality
video at any hour of the day. The DCS-3710 incorporates Power over Ethernet (PoE) allowing
it to be easily installed in a variety of locations.
Wide Dynamic Range (WDR) Applications
The Wide Dynamic Range (WDR) function provides clear video even under backlit condi-
tions where the intensity of illumination can vary significantly, making the DCS-3710
perfect for extreme high-contrast environments. For example, when placed indoors, the
DCS-3710 will adjust itself to the intense sunlight that may be streaming in through a
nearby window. This makes it an ideal solution for high contrast scenes, such as lobbies,
entryways and shipping docks.
Flexible Connectivity
The DCS-3710 includes input and output ports allowing connectivity to external devices
such as IR sensors, switches, and alarm relays. It also comes with an RS-485 interface, providing
connectivity to an optional pan/tilt enclosure which effectively adds pan/tilt functionality to
the DCS-3710.
