Installing The Processor - NEC POWERMATE PRO2180 Manual

Release the processor by pulling the lever on the socket
4.
away from the socket and as far back as it goes without
forcing.
Before picking up the processor, reduce static
discharge by touching the metal frame of the
system unit.
5. Lift the processor out of the socket.

Installing the Processor

Remove the processor currently in the system (see
1.
previous procedure).
Before picking up the processor, reduce static
discharge by touching the metal frame of the
system unit.
Align the notched corner of the processor with the
2.
alignment corner in the socket and insert the processor.
Swing the lever down to lock the processor into the
3.
socket.
5-22 Installing Options
!
CAUTION
!
CAUTION
