You can use the following parameters in "SET MENU" to adjust a variety of system settings and customize the way this
unit operates. Change the initial settings (indicated in bold under each parameter) to reflect the needs of your listening
environment.
■ Auto setup
AUTO SETUP
Use this feature to automatically adjust speaker and system parameters (see page 26).
■ Manual setup
MANUAL SETUP
Use this feature to manually adjust speaker and system parameters.
Sound menu 1 SOUND MENU
Parameter
A)SPEAKER SET
B)SP LEVEL
C)SP DISTANCE
D)CENTER GEQ
E)LFE LEVEL
F)DYNAMIC RANGE
G)AUDIO SET
H)HDMI SET
I)EXTD SUR.
Input menu 2 INPUT MENU
Parameter
A)INPUT ASSIGNMENT
B)INPUT RENAME
C)VOLUME TRIM
D)DECODER MODE
E)MULTI CH SET

SET MENU

Selects the size of each speaker, the speakers for low-frequency signal output, and the
crossover frequency, and the location of the front speakers connected to the FRONT B
terminals.
Adjusts the output level of each speaker.
Adjusts the delay time of each speaker.
Adjusts the tonal quality of the center speaker.
Adjusts the output level of the LFE channel for Dolby Digital or DTS signals.
Adjusts the dynamic range of Dolby Digital or DTS signals.
Adjusts the muting level, audio delay, maximum volume level and initial volume level.
Selects whether to play back HDMI audio signals on this unit or on another HDMI
component connected to the HDMI OUT jack.
Use this feature to enjoy 6.1/7.1-channel playback for multi-channel sources using the
Dolby Pro Logic IIx, Dolby Digital EX, or DTS-ES decoders by using the connected
surround back speakers.
Assigns the input jacks of this unit according to the component to be used.
Changes the name of the input source.
Adjusts the output volume of each input source.
Selects the decoder mode for the sources connected to the DIGITAL INPUT jacks on the
rear panel of this unit.
Selects the video source played in the background of the sources input from the MULTI CH
INPUT jacks.
Features
Features
SET MENU
Page
65
67
68
68
68
69
69
70
70
Page
71
71
72
72
72
63
