HIKVISION D0T Series User Manual
Bullet camera
Hide thumbs
Also See for D0T Series:
- User manual (17 pages) ,
- User manual (17 pages) ,
- User manual (15 pages)
Table of Contents
Advertisement
Quick Links
D0T Series Bullet Camera
User Manual
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Model
DS-2CE16D0T-IR(F)
DS-2CE16D0T-IRP(F)
DS-2CE16D0T-IT(P)F
DS-2CE16D0T-IT1/3/5(C)
DS-2CE16D0T-IT1/3/5F(C)
DS-2CE16D0T-ITPF (C) SKD
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
030000240328
Advertisement
Table of Contents
Related Manuals for HIKVISION D0T Series
Summary of Contents for HIKVISION D0T Series
- Page 1 D0T Series Bullet Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Model DS-2CE16D0T-IR(F) DS-2CE16D0T-IRP(F) DS-2CE16D0T-IT(P)F DS-2CE16D0T-IT1/3/5(C)
-
Page 2: Legal Disclaimer
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part of this Document may be excerpted, copied, translated, or modified in whole or in part by any means without written permission. -
Page 3: Regulatory Information
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE LATTER PREVAILS. © Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved. Regulatory Information EU Compliance Statement This product and - if applicable - the supplied accessories too are marked with "CE"... - Page 4 This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
-
Page 5: Overview Of Cables
Do not expose the device to high electromagnetic radiation or extremely hot, cold, dusty or damp environment. To avoid heat accumulation, good ventilation is required for the operating environment. Keep the camera away from liquid while in use for ... -
Page 6: Installation
2 Installation 0°~360 0°~360 ° ° 0°~360 0°~360° ° 0°~90° 0°~180° 0°~360 0°~360° ° 0°~360 0°~360° ° 0°~90° 0°~180°... - Page 7 0°~360° 0°~75° 0°~360° 0°~360° 0°~360° 0°~75° 0°~360° 0°~360° 0°~360° 0°~75° 0°~75° 0°~360°...
- Page 8 0°~355 -30°~30° ° 0°~75° 0°~360° 0°~355° 0°~75° 0°~360 ° 0°~75°...
-
Page 9: Menu Description
3 Menu Description Please follow the steps below to call the menu. Note: The actual display may vary with your camera model. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. Figure 3-1 Connection 2. -
Page 10: Video Format
3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDEO FORMAT You can set the video format to 2MP@30fps, 2MP@25fps, PAL or NTSC. Note: When switching the video output to TVI/ CVI/ AHD, you can set the video format to 2MP@30fps or 2MP@25fps; when switching the video output to CVBS, you can set the video format to PAL or NTSC. -
Page 11: Video Settings
IR LIGHT You can turn on/off the IR LIGHT to meet different circumstances. SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure. The SMART IR value can be adjusted from 0 to 3. -
Page 12: Image Mode
VIDEO SETTINGS IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS SATURATION MIRROR BACK EXIT SAVE & EXIT Figure 3-5 VIDEO SETTING IMAGE MODE IMAGE MODE is used to adjust the image saturation, and you can set it to STD (Standard) or HIGH-SAT (High Saturation). -
Page 13: Factory Default
HV: The image flips 180° both horizontally and vertically. 3.5 FACTORY DEFAULT Reset all the settings to the factory default. 3.6 EXIT Move the cursor to EXIT and click Iris+ to exit the menu. 3.7 SAVE & EXIT Move the cursor to SAVE & EXIT and click Iris+ to save the settings, and exit the menu.
