- Page 1 LAVE-VAISSELLE FFB74717PM Besoin d’un conseil ? Une question sur ce produit ? RDV sur la communauté SAV Darty : https://sav.darty.com Déjà 1/2 million de solutions grâce à l’avis des utilisateurs.
- Page 2 EN User Manual | Dishwasher FFB74717PM...
-
Page 3: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. - Page 4 for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning...
-
Page 5: Safety Instructions
• Follow the maximum number of 14 place settings. • The appliance door should not be left in an open position to avoid the tripping hazard. • If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard. - Page 6 Make sure that there is access to the • Do not store items or apply pressure on mains plug after the installation. the open door of the appliance. • Do not pull the mains cable to disconnect • The appliance can release hot steam if the appliance.
-
Page 7: Product Description
• Disconnect the appliance from the mains • Remove the door catch to prevent children supply. and pets to get closed in the appliance. • Cut off the mains cable and discard it. 3. PRODUCT DESCRIPTION Worktop Air vent Ceiling spray arm Rinse aid dispenser Upper spray arm Detergent dispenser... -
Page 8: Control Panel
4. CONTROL PANEL On/off button Extra Hygiene button Display Extra Power button Programme selection button Glass Care button AUTO programme button Indicators Delay button 4.1 Indicators Indicator Description Salt indicator. It is on when the salt container needs refilling. It is always off while the pro‐ gramme operates. - Page 9 Programme Dishwasher Degree of Programme phases Options load soil Crockery, cut‐ Normal to • Prewash • Extra Power 160 min lery, pots, pans heavy, dried- • Dishwashing 60 °C • Glass Care • Intermediate rinse • Extra Hygiene • Final rinse 60 °C •...
- Page 10 Programme Dishwasher Degree of Programme phases Options load soil Crockery, cut‐ • Prewash lery, pots, pans • Dishwashing 50 - 60 °C • Intermediate rinse • Final rinse 60 °C • Drying • AirDry This programme offers the most efficient use of water and energy consumption for crockery and cutlery with normal soil.
-
Page 11: Settings
Water (l) Energy (kWh) Duration (min) Programme 1)2) 12.1 1.220 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. The values for programmes other than ECO are indicative only. 5.2 Information for test institutes To receive the necessary information for conducting performance tests (e.g. - Page 12 area. Your local water authority can advise area. Set the right level of the water softener you on the hardness of the water in your to assure good washing results. Water hardness German de‐ French de‐ mmol/l mg/l (ppm) Clarke de‐ Water softener grees (°dH) grees (°fH)
- Page 13 programme. This activity increases the total If standard detergent or multi-tablets without water consumption of a programme by rinse aid are used, activate the notification to additional 4 litres and the total energy keep the rinse aid refill indicator active. consumption of a programme by additional 2 Wh.
- Page 14 6.5 Acoustic signals The duration of the drying phase and the door opening time vary depending on the selected Acoustic signals sound when a malfunction of programme and options. the appliance occurs. It is not possible to When AirDry opens the door, the display deactivate these acoustic signals.
-
Page 15: Options
6.8 Cycle counter The displays shows uC and then the number of cycles. You can view the number of completed Press any button to exit the cycle counter. dishwashing cycles in the cycle counter. 1. Press the on/off button to activate the dishwasher. - Page 16 2. Fill the salt container. 3. Fill the rinse aid dispenser. 4. Open the water tap. 5. Start a programme to remove any processing residuals that can still be inside the appliance. Do not use detergent and do not put dishes in the baskets.
-
Page 17: Daily Use
4. Close the lid. Make sure that the lid locks into position. Fill the rinse aid dispenser when the indicator (A) is clear. 9. DAILY USE 1. Open the water tap. 2. Press the on/off button to activate the appliance. For information about the detergent Make sure that the appliance is in programme dosage, refer to the manufacturer's... - Page 18 • The related indicator is on. Press and hold simultaneously • The display shows the programme until the appliance is in programme number for approximately 3 seconds selection mode. and then shows the programme duration. 4. Close the appliance door to start the Cancelling the programme programme.
-
Page 19: Hints And Tips
10. HINTS AND TIPS 10.1 General 10.2 Using salt, rinse aid and detergent Follow the hints below to ensure optimal cleaning and drying results in daily use and to • Only use salt, rinse aid and detergent protect the environment. designed for dishwasher. -
Page 20: Care And Cleaning
10.5 Before starting a programme 4. When the programme is complete, adjust the water softener according to the water Before you start the selected programme, hardness in your area. make sure that: 5. Adjust the released quantity of rinse aid. 6. - Page 21 11.2 Removal of foreign objects Check the filters and the sump after each use of the dishwasher. Foreign objects (e.g. pieces of glass, plastic, bones or toothpicks, etc) decrease the cleaning performance and can cause damage to the drain pump. CAUTION! If unable to remove the foreign objects, contact an Authorised Service Centre.
- Page 22 2. Wash the spray arm under running water. 7. Reassemble the filters (B) and (C). Use a thin pointed tool, e.g. a toothpick, 8. Put back the filter (B) in the flat filter (A). to remove particles of soil from the holes. Turn it clockwise until it locks.
- Page 23 2. To detach the spray arm from the basket, holes. Clogged holes can cause press the spray arm upwards and unsatisfactory washing results. simultaneously turn it clockwise. The ceiling spray arm is placed on the ceiling of the appliance. The spray arm (C) is installed in the delivery tube (A) with the mounting element (B).
-
Page 24: Troubleshooting
5. To install the spray arm (C) back, insert the mounting element (B) in the spray arm and fix it in the delivery tube (A) by turning it clockwise. Make sure that the mounting element locks into place. 6. Install the cutlery drawer on the sliding rails and block the stoppers. - Page 25 Problem and alarm code Possible cause and solution The anti-flood device is on. • Close the water tap. The display shows i30. • Make sure that the appliance is correctly installed. • Make sure the baskets are loaded as instructed in the user manual. Malfunction of the water level detec‐...
- Page 26 Problem and alarm code Possible cause and solution Rattling or knocking sounds from • The tableware is not properly arranged in the baskets. Refer to basket the inside of the appliance. loading leaflet. • Make sure that the spray arms can rotate freely. The appliance trips the circuit-beak‐...
- Page 27 Problem Possible cause and solution There are stains and dry water drops • The released quantity of rinse aid is not sufficient. Adjust the rinse on glasses and dishes. aid dosage to a higher level. • The quality of the rinse aid can be the cause. The interior of the appliance is wet.
-
Page 28: Technical Information
13. TECHNICAL INFORMATION Dimensions Width / height / depth (mm) 596 / 850 / 610 Voltage (V) 220 - 240 Electrical connection Frequency (Hz) Water supply pressure Min. / max. MPa (bar) 0.05 (0.5) / 1 (10) Water supply min. 5 - max. 60 °C Cold water or hot water Capacity Place settings... - Page 29 117835890-A-172023...
