  • Page 1 Operating Instructions Heated Incubator MIR-H163 MIR-H263 MIR-H163  MIR-H263    Series MIR-H263 Please read the operating instructions carefully before using this product, and save the operating instructions for future use. See page 26 for all model numbers.
  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION P. 2 PRECAUTIONS FOR SAFE OPERATION P. 3 ENVIRONMENTAL CONDITIONS P. 7 INCUBATOR COMPONENTS P. 8 Control panel and keypad P. 10 INSTALLATION SITE P. 12 INSTALLATION P. 13 PRELIMINARY RUN P. 13 KEY OPERATION FLOW P. 14 NORMAL MODE AND TIMER MODE C P.
  • Page 3: Introduction

    INTRODUCTION ■ Read the operating instructions carefully before using the Product and follow the instructions for safety operation. ■ Our company disavows any responsibility for safety if the Product is used for other than the intended use or used with any procedures other than those given in the operating instructions. ■...
  • Page 4: Precautions For Safe Operation

    PRECAUTIONS FOR SAFE OPERATION It is imperative that the user complies with the operating instructions as it contains important safety advice. Items and procedures are described so that you can use this unit correctly and safely. If the precautions advised are followed, this will prevent possible injury to the user and any other person.
  • Page 5 PRECAUTIONS FOR SAFE OPERATION WARNING Do not use the unit outdoors. Current leakage or electric shock may result if the unit is exposed to rain water. The installation by Only qualified engineers or service personnel should install the unit. unqualified personnel may cause electric shock or fire. Install the unit on a sturdy floor and take an adequate precaution to prevent the unit from turning over.
  • Page 6 PRECAUTIONS FOR SAFE OPERATION WARNING Ensure you do not inhale or consume medication or aerosols from around the unit at the time of maintenance. These may be harmful to your health. Never splash water directly onto the unit as this may cause electric shock or short circuit. Never put containers with liquid on the unit as this may cause electric shock or short circuit when the liquid is spilled.
  • Page 7 PRECAUTIONS FOR SAFE OPERATION CAUTION This unit must be plugged into a dedicated circuit protected by branch circuit breaker. Use a dedicated power source as indicated on the rating label attached to the unit. A multiple-tap may cause fire resulting from abnormal heating. Never store corrosive substances such as acid or alkali in this unit if the container cannot be sealed.
  • Page 8: Environmental Conditions

    ENVIRONMENTAL CONDITIONS This equipment is designed to be safe at least under the following conditions (based on the IEC-61010-1): ■ Indoor use; ■ Altitude up to 2000 m; ■ Temperature 5 C to 40 ■ Maximum relative humidity 80% for temperature up to 31 C decreasing linearly to 50% relative humidity at 40 ■...
  • Page 9: Incubator Components

    INCUBATOR COMPONENTS Shelf Outer door 3, 4 (Inside) KEYLOCK For model with CE mark...
  • Page 10 INCUBATOR COMPONENTS 1. Inner door: It is made of tempered glass. However, do not force the door. 2. Control panel: Refer to page 10. 3. Separation plate: Do not place objects directly on the plate. 4. Heater box (inside): The heater is attached under separation plate. 5.
  • Page 11: Control Panel And Keypad

    INCUBATOR COMPONENTS Control panel and keypad 1. Power switch (POWER): Power switch of the control panel. 2. Delay timer key (DELAY): This key is to set a delay timer which controls the time from when the run/stop key (RUN/STOP) is pressed till when the unit starts an operation. Refer to page 14~17. 3.
  • Page 12 INCUBATOR COMPONENTS 10. Timer mode select key (TIMER MODE): This key is to switch a normal mode and a timer mode C. Normal mode: The operation is finished when a set time of operation timer is expired. Timer mode C: The operation continues with a set temperature even when a set time of operation timer is expired.
  • Page 13: Installation Site

    INSTALLATION SITE To operate this unit properly and to obtain maximum performance, install the unit in a location with the following conditions: ■ A location not subjected to direct sunlight Do not install the unit under direct sunlight. Installation in a place with direct sunlight cannot obtain the intended performance.
  • Page 14: Installation

    INSTALLATION 1. Remove the packaging materials and tapes Remove all transportation packaging materials and tapes. Open the doors and ventilate the unit. If the outside panels are dirty, clean them with a neutral detergent and wipe it up with a wet cloth. Note: Remove the cable tie banding the power supply cord.
  • Page 15: Key Operation Flow

    KEY OPERATION FLOW This flow chart shows the key operation from control panel. Present temperature is POWER Press the power switch. displayed. Saved delay time is DELAY Press the delay timer key. displayed. When the delay time is same as last time. Saved delay time is reset.
  • Page 16: Normal Mode And Timer Mode C

    NORMAL MODE AND TIMER MODE C The operation flow of this unit in the normal mode and the timer mode C is shown in Table 2 and Table 3. Table 2 Operation flow in normal mode (Timer mode C lamp: OFF) ●: Lamp ON ○: Lamp OFF Automatic termination*...
  • Page 17: Stable Running

    STABLE RUNNING Table 4 shows the basic procedure for setting the chamber temperature. Perform key operations in the sequence indicated in the table. The example in the table is based on the assumption that the desired temperature is 37 C and the operation status is a continuous running. The initial setting, which are set at factory, Note: are that the delay timer is OFF, the chamber...
  • Page 18: Stable Running With Delay Time

    STABLE RUNNING WITH DELAY TIME Table 5 shows one of applications. Perform key Buzzer operations in the sequence indicated in the table. The example in the table is the delay time that is 30 minutes, the chamber temperature is 50 C, the running time is 1 hour and the timer mode is Timer Mode C.
  • Page 19: Alarms And Safety Functions

    ALARMS AND SAFETY FUNCTIONS The incubator supports the following alarms, safety functions, and self-diagnostic functions. Alarms and safety functions Alarm & Situation Indication Buzzer Safety operation Safety Automatic set Alarm lamp lights. The internal temperature is over temperature All digits on the temp. Intermittent tone ----- +/-2.5...
  • Page 20: Routine Maintenance

    ROUTINE MAINTENANCE WARNING Always disconnect the power supply to the unit prior to any repair or maintenance of the unit in order to prevent electric shock or injury. Ensure you do not inhale or consume medication or aerosols from around the unit at the time of maintenance.
  • Page 21: Troubleshooting

    TROUBLE SHOOTING If the unit malfunctions, check out the following before calling for service. Malfunction Check/Remedy • The unit is not plugged correctly into a power outlet. The unit does not operate • The circuit breaker at the power source is active. at all.
  • Page 22: Disposal Of Unit

    DISPOSAL OF UNIT WARNING If the unit is to be stored unused in an unsupervised area for an extended period ensure that children do not have access and doors cannot be closed completely. The disposal of the unit should be undertaken by appropriate personnel. Always remove doors to prevent accidents such as suffocation.
  • Page 23 Waste Electrical and Electronic Equipment (WEEE) Directive (English) Your Panasonic product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste.
  • Page 24 DISPOSAL OF UNIT (French) Votre produit Panasonic est conçu et fabriqué avec des matèriels et des composants de qualité supérieure qui peuvent être recyclés et réutilisés. Ce symbole signifie que les équipements électriques et électroniques en fin de vie doivent être éliminés séparément des ordures ménagères.
  • Page 25 DISPOSAL OF UNIT (Portuguese) O seu produto Panasonic foi concebido e produzido com materiais e componentes de alta qualidade que podem ser reciclados e reutilizados. Este símbolo significa que o equipamento eléctrico e electrónico no final da sua vida útil deverá ser descartado separadamente do seu lixo doméstico.
  • Page 26 Alstublieft help allen mee om het milieu te beschermen. (Swedish) Din Panasonic produkt är designad och tillverkad av material och komponenter med hög kvalitet som kan återvinnas och återanvändas. Denna symbol betyder att elektriska och elektroniska produkter, efter slutanvändande, skall sorteras och lämnas separat från Ditt hushållsavfall.
  • Page 27: Specifications

    SPECIFICATIONS Product name Heated Incubator MIR-H163 Heated Incubator MIR-H263 External dimensions W580 mm x D595 mm x H820 mm W730 mm x D645 mm x H870 mm Internal dimensions W450 mm x D460 mm x H450 mm W600 mm x D510 mm x H500 mm Effective capacity 93 L 153 L...
  • Page 28: Safety Check Sheet

    CAUTION Please fill in this form before servicing. Hand over this form to the service engineer to keep for his and your safety. Safety check sheet 1. Incubator contents : Risk of infection: □Yes □No Risk of toxicity: □Yes □No Risk from radioactive sources: □Yes □No...
  • Page 29 Printed in Indonesia 1-1-1, Sakata Oizumi-Machi Ora-Gun, Gunma 370-0596, Japan 7FB6P15175600 © Panasonic Healthcare Co., Ltd. 2014 S1014-0...
