- Page 1 3D Image Sensor Model No. EKL3104 Display Software User Manual Version 1.00 2010．4．1 1/12...
-
Page 2: Table Of Contents
5.3 Others ………………………………………………… 12 5.4 Precautions ………………………………………….. 12 Notice ○ This manual and the software are copyrighted by Panasonic Electric Works Co., Ltd. ○ Reproduction of this manual in any form without prior approval is strictly prohibited. ○ Windows ® ®... -
Page 3: Introduction
1. Introduction This document explains how to use the program for capturing and displaying images from the 3D image sensor developed by Panasonic Electric Works Co., Ltd. 2. Operating Environment Please use this software in the following environment. *Compatible OS: ®... -
Page 4: Program Contents
3. Program Contents *DigiCapUSB.exe : Main package of this software *Dimagerdll.dll : Program Contents Please place the above two files in the same folder. 4. Functions This program receives and displays grayscale and range image data via USB from the 3D image sensor. Its specific functions are as follows. -
Page 5: Explanation Of Display Screens
5. Explanation of Display Screens 5.1 Explanation of Each Screen - START/STOP button: switches between image capture/stop Clicking the START button: Starts image capture, displays the captured Grayscale Image and Range Image, and switches the button to STOP. When the STOP button is displayed, then clicked, image capture is stopped, and the button switches back to START. - Page 6 - Save Consecutive Images button: Saves the designated number of consecutively received grayscale images or range images. (Check memory when setting. Save processing is performed after securing a buffer for the captured number of images, and a long processing time is required if there are many captured images.) When the button is clicked, the following dialog box is displayed.
- Page 7 <Name of saved data files> ：******_kb.bmp Range Image (BMP) ：******_nb.bmp Grayscale Image (BMP) ：******_kb.csv Range Image Data(CSV) Grayscale Image Data(CSV) ：******_nb.csv *If Save Consecutive Images has been set, the following dialog box will be displayed when the START button is clicked. Click OK. *If Save Consecutive Images has been set, it will automatically stop when the Image Capture Limit is attained.
- Page 8 - Frequency Setting: Switches between and checks the three types of frequencies. (0: Frequency 1 (default); 1: Frequency 2; 2: Frequency 3) *This button cannot be clicked while an image is being output. -Check button for frequency setting: The current frequency setting is displayed to the left side of the Check button.
- Page 9 - Frame rate: Displays the frame rate when running the display program. Updated every 2 seconds. *This is not the frame rate for output from the 3D Image sensor. - Version (V): Displays the 3D image sensor mode and DLL version (xx.xx.xx). - Brightness, Point, Distance: Displays the point coordinates and distance when clicking with the pointer on the grayscale image or range image.
-
Page 10: Error Display
5.2 Error Display - This display will appear in absence of a USB connection. (It will be displayed about seconds after the START button is clicked.) - The following display will appear if the USB connection is lost during image output (approx. seconds). - Page 11 - The following display will appear if the DigiCapUSB.exe display software is started twice. - The following display will appear if a failure occurs during saving with the Save Consecutive Images setting. - The following is displayed if Dimagerdll.dll cannot be found when starting up the software.
-
Page 12: Others
5.3 Others - If the 3D image sensor is in Sleep ON mode and the START button is clicked, it is necessary to stop it by clicking the STOP button. (The second stop due to Image Capture Failure will not occur.) - If the USB is disconnected during image output, the STOP button cannot be clicked. - Page 13 单击下面可查看定价，库存，交付和生命周期等信息 >>Panasonic(松下) Downloaded From Oneyac.com...
