SPECIAL WARNING
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE THIS INSTALLATION MANUAL FOR LOCAL ELECTRICAL
INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CLEARANCES & DIMENSIONS
For SAFETY CONSIDERATIONS do not install a range in any combustible cabinetry which is not in
accord with the stated clearances and dimensions on page 2. See Figures 1 and 2.
RANGE MEASUREMENTS ......................................2
CLEARANCES AND DIMENSIONS ..............................2
IMPORTANT NOTES .............................................3
UNPACKING AND EXAMINING YOUR RANGE .................3
IMPORTANT SAFETY INSTRUCTIONS .........................3
30" Slide-in Range
INSTALLATION MANUAL
ELECTRICAL CONNECTIONS ................................ 4-6
ANTI-TIP .................................................... 6-7
MODEL AND SERIAL NUMBER LOCATION ....................8
CARE, CLEANING AND MAINTENANCE ......................8
