6.2 EMC and Environmental Type Tests
Test
61000-4-8
61000-4-11
61000-4-12
61000-4-16
61000-4-17
61000-4-29
IEC 60255-5
EMC Immunity Type Tests per IEEE 1613
Note
The RUGGEDCOM RS900F meets Class 2 requirements for an all-fiber configuration
and Class 1 requirements for copper ports. Class 1 allows for temporary communica-
tion loss, while Class 2 requires error-free and interrupted communications.
36
All manuals and user guides at all-guides.com
Description
IEC
Magnetic Field
IEC
Voltage Dips and Interrupts
IEC
Damped Oscillatory
IEC
Mains Frequency Voltage
IEC
Ripple on DC Power Supply
IEC
Voltage Dips and Interrupts
Dielectric Strength
HV Impulse
Test Levels
Enclo-
40 A/m Continuous
sure Ports
1000 A/m for 1 s
AC Pow-
100% for 5 Periods
er Ports
100% for 50 Periods
Signal Ports
2.5 kV Common
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
DC Pow-
2.5 kV Common
er Ports
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
AC Pow-
2.5 kV Common
er Ports
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
Signal Ports
30 V Continuous
300 V for 1 s
DC Pow-
30 V Continuous
er Ports
300 V for 1 s
DC Pow-
10%
er Ports
DC Pow-
30% for 0.1 s
er Ports
60% for 0.1 s
100% for 0.05 s
Signal Ports
2 kV (Failsafe Relay Output)
DC Pow-
1.5 kV
er Ports
AC Pow-
2 kV
er Ports
Signal Ports
5 kV (Failsafe Relay Output)
DC Pow-
5 kV
er Ports
AC Pow-
5 kV
er Ports
