ReCare
Recumbent stepper
with removable seat
7.5 S
PTE7500MS
Register your product and get support at
www.philips.com/welcome
User manual
Please read this entire manual carefully
before operating your new recumbent
stepper with removable seat save it for
future use.
2

Advertisement

Table of Contents
loading

Related Manuals for Philips ReCare 7.5 S

Summary of Contents for Philips ReCare 7.5 S

  • Page 1 ReCare User manual Recumbent stepper with removable seat Please read this entire manual carefully before operating your new recumbent 7.5 S stepper with removable seat save it for future use. PTE7500MS Register your product and get support at www.philips.com/welcome...
  • Page 2 Thank you for your recent purchase of the Philips physical recumbent stepper with removable seat, 7.5 S Philips physical therapy and exercise solutions provide simple, reliable products that o er the most relevant feedback to caregivers and users to achieve...

  • Page 3: Table Of Contents

    Contents Important safety instructions Important electrical information Important operation instructions Application speci cation Operating principle Signi cant physical characteristics Signi cant performance characteristic Intended user pro le...
  • Page 4 Operating the 7.5 S Features Operation of your new stepper Data transfer software instructions Using a heart rate transmitter Assembly instructions for 7.5 S Maintenance Speci cations Description of packaging symbols...

  • Page 5: Important Safety Instructions

    Important safety instructions Attention Read all instructions in this manual before using this device. Danger To reduce the risk of electric shock disconnect your from the electrical outlet prior to cleaning and/or service work. Warning • Do not modify this equipment without authorization of the manufacturer.
  • Page 6 • Do not use any after market parts on this device, other than those recommended by philips. • Do not attempt any servicing or adjustments other than those described in this manual.
  • Page 7 • Installation and assembly of this product should be performed by trained personnel only. • To avoid injury please observe all minimum and maximum seat and arm adjustment settings.

  • Page 8: Important Electrical Information

    • The 7.5 s is not protected against the ingress of water or particulate matter. • The 7.5 s is not suitable for use in an oxygen rich environment. • If not stated otherwise philips devices are designed for operation in normal climatic surroundings: - Temperature: + 10° ... + 36° c - Relative humidity: 30 ...

  • Page 9: Important Operation Instructions

    Important operation instructions • Never use the device during an electrical storm. Surges may occur in your facility power supply that could damage the unit’s components. • All users should have medical clearance before starting any rigorous exercise program. This is especially important for persons with a history of heart disease or other high risk factors.

  • Page 10: Application Speci Cation

    Application speci cation Medical purpose • Patient warm up before physical therapy session. • Have the patient pedal to improve range of motion after knee/hip/ankle/shoulder or wrist surgery. • Allow patients to perform cardiovascular exercise Intended patient population • There is no particular restriction on age, gender, height and nationality.
  • Page 11 Intended conditions of use • Environment including hygienic requirements: - General Intended for indoors use. This product is not designed for use out doors, near a pool or spa, or in any other high humidity environment. - Conditions of visibility Ambient luminance: standard ambient room lighting is su cient.

  • Page 12: Operating Principle

    Operating principle The patient pushes the pedals with their feet and the arms with their hands. The operator can increase the workload using the Up and Down Key on the console. When the workload change is requested a gear motor moves permanent magnets closer or further from the aluminum ywheel creating more or less resistance.

  • Page 13: Signi Cant Performance Characteristic

    Signi cant performance characteristic Please refer to “Unique uses for the 7.5 S” in operating the 7.5 S.

  • Page 14: Intended User Pro Le

    Intended user pro le Intended operator • There is no particular restriction on age, gender, height, weight, ability and culture. • Education: university or above • Knowledge: the operator should read the user’s manual before use. • Discipline: the operator should receive training from the manufacturer before use.

  • Page 15: Operating The 7.5 S

    Operating the 7.5 S The recumbent stepper is intended to be used in aiding in the physical rehabilitation process for patients with orthopedic and neurological problems. Also used in sports medicine, wellness and general conditioning programs. Typical applications for this type of product are: •...
  • Page 16 Other features of the 7.5 S • Work range up to 750 watts. • Indexed seat positioning accommodates users from 147 cm to 200 cm (4’ 10” to 6’ 7”) • Heart rate monitoring using the hand grips or optional heart rate chest-strap.

  • Page 17: Features

    Features 7.5 S Recumbent stepper Parts and adjustments 1. Electronic console 2. Upper body rotating handles 3. Quick release lever 4. Cushioned footplates with straps 5. Swivel seat with seat belt 6. Arm supports 7. Seat angle adjustment 8. Seat position adjustment 9.
  • Page 18 The 7.5 S is an easy product to set up and use, from the adjustments to the intuitive interface. This section explains how to set up, adjust and operate your 7.5 S. Leveling the 7.5 S • Once the 7.5 S is assembled, and placed on a at level oor, it may be necessary to adjust the leveling glides on the bottom of the unit to ensure proper stability of the 7.5 S.
  • Page 19 Adjusting the seat back angle • To adjust the seat back angle, squeeze the brake handle located on the right side handle bar and move the seat back to the desired position. There is a numbered scale located just below the seat back cushion for repeatable settings.
  • Page 20 Pedal strap adjustment • Remove the ankle strap from the chrome ring. Loosen the foot strap enough so the patient’s foot can slide under. Once the foot is in the correct position reattach the ankle strap and adjust both straps for a snug t. Seat belt adjustment •...

  • Page 21: Operation Of Your New Stepper

    Operation of your new stepper 7.5 S Electronic console Data displays Graphic display Hr percent pro le Message window Program keys Set up key Function keys Power on When initially powered on the console will perform an internal self-test. During this time all the lights will turn on for a short time. The message window will then show a software version (i.e.
  • Page 22 The odometer will remain displayed for only a few seconds then the console will go to the start up display, also known as idle Mode. The message window will be scrolling the start up message. You may now begin to use the 7.5 S. The console will automatically power down after 20 minutes of inactivity.
  • Page 23 Quick start This is the quickest way to start an exercise session. After the console powers up you just press the Start key to begin; this will initiate the Quick Start mode. In Quick Start, the Time will count up from zero, all workout data will start to accrue and the workload may be adjusted manually by pressing the Up or Down key.
  • Page 24 The bar graph represents the percentage of maximum heart rate. Note: enter the correct age in set up for the bar graph to be accurate. Refer to heart rate section for details about these features. Function keys The stop/reset key provides several functions. •...
  • Page 25 Manual The manual program works as the name implies, manually. This means that you control the workload yourself, not the computer. To start the manual program follow the instructions below or just press the manual button then the enter button and follow the directions in the message window.
  • Page 26 Hill The Hill program simulates going up and down a hill. The resistance in the pedals and upper body arms will steadily increase and then decrease during the program. Plateau The Plateau program provides a steady state exercise with warm up and cool down periods Cardio The Cardio program is designed to increase Cardio vascular function.
  • Page 27 Programming preset programs • Select the desired program button then press the enter key. • The message window will prompt you to enter the age, weight, time and max level for the program. You may enter the age using the up and down keys or the numeric key pad then press the enter key to accept and proceed to the next screen.
  • Page 28 • When you press enter, the message window will show “name – a”, if there is no name saved. If the name “custom workout” had been previously saved the message window will show “name – custom workout” and the c in custom will be blinking. If there is a name saved you can change it or you may press the stop key to keep the name and continue to the next step.
  • Page 29 Running a saved program • Press User key then Enter • Enter Time then press start to begin program. Symmetry The Symmetry program may aid in achieving a more balanced exercise stroke for patients with bi-lateral de ciencies, such as stroke patients and post-op knee patients.
  • Page 30 For best results The Symmetry program starts at level 1 and the resistance needs to be increased manually by pressing the Up arrow. Make sure to set the resistance to a level where the patient is doing enough work to generate a meaningful measurement.

  • Page 31: Data Transfer Software Instructions

    Data transfer software instructions • Works with newer 7.0 T, 7.0 S, 7.5 S, 7.0 R and 7.0 U consoles with USB ports on the back • The software works with Windows 10, 7 and XP series, with .Net • Framework 2.0.
  • Page 32 Step 2. Click "Connect" or "Change" to select the connecting port (left gure). After clicking the "Change", or connecting to the wrong port, the COM port selection window pops up (right gure). Select the correct COM port and click "Connect". Selecting COM port Pop-Up COM Port Selection Window...
  • Page 33 The saved data can be found at the assigned destination. Click record button Philips Data Transfer V1.0 Philips Data Transfer V1.0 7.5S Recording complete Philips Data Transfer V1.0 Philips Data Transfer V1.0...
  • Page 34 The le is saved in .CSV format, which can be opened by Microsoft Excel. Example shown below.

  • Page 35: Using A Heart Rate Transmitter

    Using a heart rate transmitter Note: The chest strap transmitter is not a standard part, but is a separate purchase. Most transmitters that operate at 5kHz frequency will also work. • Attach the transmitter to the elastic strap using the locking parts. •...
  • Page 36 Note: The transmitter is automatically activated when it detects activity from the user’s heart. Additionally, it automatically deacti- vates when it does not receive any activity. Although the transmitter is water resistant, moisture can have the e ect of creating false sig- nals, so you should take precautions to completely dry the transmit- ter after use to prolong battery life (estimated transmitter battery life is 2500 hours).
  • Page 37 • you are now asked to enter your weight. You may adjust the weight number using the up and down keys or the numeric key pad, then press enter to continue. • Next is time. You may adjust the time and press enter to continue. •...

  • Page 38: Assembly Instructions For 7.5 S

    Assembly instructions for 7.5 S Hardware Step 1. #128. M6 × 40L #132. 3/8" × 2" #135. 5/16" × 1-1/4" (2pcs) (4pcs) (1pc) #185. 5/16" × 3/4" #170. 3/8" × 3T #173. 5/16" × 1" (4pcs) (8pcs) (2pcs) #181. M5 × 15L #140.
  • Page 39 #181. M5 × 15L #140. 3/8" × 3-1/4" (12pcs) (2pcs) #190. 3/8" × 7T #193. 5/16" × 6T #187. M6 × 6T (6pcs) (1pcs) (2pcs) #216. 3/8" × 5/8" #206. 3/8" × 3-3/4" (2pcs) (2pcs) #217. 3/8" × 2T #218. 3/8" × 3T #255.
  • Page 40 Hardware Step 2. #152. 5/16" × 1-3/4" #153. M8 × 16L (2pcs) (2pcs) #154. 3/8" × 2-1/2" (2pcs) #170. 3/8" × 3T #184. 3/8" × 7/8" (2pcs) (2pcs) #160. M8 ×6.5T #190. 3/8" ×7T #193. 5/16" ×6T (6pcs) (2pcs) (2pcs) #194.
  • Page 41 Hardware Step 3. #122. M6 × 25L #167. 3/8" × 1" #190. 3/8" × 7T (4pcs) (2pcs) (2pcs) #197. 3/8" × 1-3/4" (2pcs) Step 4. #143. M5 × 12L #216. 3/8" × 5/8" #217. 3/8" × 3/4" (4pcs) (8pcs) (4pcs) #218.
  • Page 42 Assembly Read each step’s instructions and study the drawing carefully to become familiar with all the parts and procedures before beginning each step. Step 1. Pedals, seat latch handle and handle bar assembly • Slide the handle bar assembly (17) onto the receiving tubes of the seat frame.
  • Page 43 1 78 1 81 1 81 21 6 1 28 21 7 1 85 1 28 1 08 21 8 1 87 1 85 1 93 1 73 1 87 1 35 21 8 1 78 21 6 1 40 21 7 21 7 1 32...
  • Page 44 Step 2. Console mast & transport wheels assembly • Install the transport wheels (77) using the 5/16” x 1-3/4” bolts (152) and 5/16” nylon nuts (193). • Slide the console mast cover (74) onto the console mast (2); be sure the cover orientation on the mast is correct otherwise it won’t clip in place later.
  • Page 45 Step 3. Seat back and bottom cushion assembly • Slide the seat back assembly (94) into the seat back angle adjustment bracket and secure with the two 3/8” x 1-3/4” bolts (197), 3/8” washers (167) and 3/8” nuts (190). • Assemble the seat cushion (93) onto the seat frame with four M6 bolts (122).
  • Page 46 Step 4. Console and arm assembly • Connect the computer cable into the back of the console and install the console (29) onto the console mast and secure with the four 5mm x 12mm screws (143). • Install the left and right arms (3&4) and secure with the 3/8” x 5/8” bolts (216) and use the 3/8”...
  • Page 47 7.5 S Exploded view drawing...
  • Page 48 #243. 3/8" #178. 3/8" × 2-1/2" #258. M10 × 30L 7.5 S Parts list (8pcs) (2pcs) (2pcs) Item Description Main frame Console mast Swing arm (r) Swing arm (l) Pedal plate (r) Pedal plate (l) Handle slider (r) Handle slider (l) Drive pulley axle Idler bracket Brake motor bracket...
  • Page 49 Item Description Ø84 × 32l_cable drive pulley Belt (8pj), 584mm Belt (8pj), 1032mm Adjustable idler wheel axle Drive pulley Lower linkage Slider sleeve Flywheel mass Gear motor Braking magnet Roller Cable spring(ø15.5 ×26.5l) Gear motor spring(ø13 ×20l) Steel cable roller(ø6 ×Ø24×7l) Wfm -2528-16_plastic bushing Rubber pad Flywheel axle set collar (r)
  • Page 50 Item Description End cap Shroud (r) Shroud (l) Top cover Console mast cover Ø75_foot leveler Slide end cap spacer Ø65_transportation wh Eel Shroud bracket Sensor bracket Shroud xing plate Pedal isolation rubber Fixing belt Seat position latch Seat slide rail Rack, seat position Rubber foot pad Ø32(1.8t)_button head plug...
  • Page 51 M10 × P1.5 × 40l_hex head bolt M5 × P0.8 × 12l_socket head cap bolt 3/8" × Ucn16 × 3-1/4"_hex head bolt,20l Philips head self-tapping screw, ø3.5x12 × M6 × 10l _button head socket bolt M5 × P0.8 × 12l_phillips head screw M5 ×...
  • Page 52 Item Description Ø17_wave washer M4 × P0.7 × 10l_phillips head screw 5/16" × Unc18 × 3/4"_hex hea D bolt M8 × P1.25 × 20l_button head socket bolt M8 × P1.25 × 25l_button head socket bolt 5/16" × Unc18 × 1-3/4"_button head socket bolt M8 ×...
  • Page 53 Item Description M5 × P0.8 × 10l_slotted set screw Ø8 × 23 × 1.5t_curved washer Ø5/16" × 19 × 1.5t_curved washer M6 × P1.0 × 6t_nyloc nut M5 × P0.8 × 5.0t_nyloc nut 3/8" × Unc16 × 7t_nyloc nut M8 × P1.25 × 6t_nyloc nut M10 ×...
  • Page 54 Item Description Ø3/8" × Ø23 × 3.0t_curved washer Optical sensor Board(cs63008 -00) Optical sensor board(cs63008-10) 1550m/m_computer console cable 250m/m_encoder cable 100m/m_dc power cord 650m/m_hall sensor cable Set collar Ø18 × Ø32 × 1.5t_nylon washer Power ada Pter, 12vdc Foot strap, narrow Foot strap, wide Seat belt 32 ×...
  • Page 55 Item Description Ø5/16" × 20 × 3.0t_ at washer M8 × 10 × 30l_bolt M10 × P1.5 × 30l_button head socket bolt Ø10 × 14 × 25.4l_sleeve Power adapter line cord Powder metallurgy s Leeve Ø3/8" × Ø20 × 2t_ at washer Snap connector, male(4.7x14x16) Snap connector, female(5.5x20x11.9)

  • Page 56: Maintenance

    Maintenance • Wipe down all areas in the sweat path with a damp cloth after each use to prevent rust. • Check hand grips, seat cushions and foot pedals for signs of wear (once a month). • If a squeak, thump, clicking or rough feeling develops the main cause is most likely one of two reasons: - The hardware was not su ciently tightened during assembly.
  • Page 57 • Key Test • LCD test • Functions - Sleep mode – on - Pause mode - on (If pause mode is o then console will remained Paused inde nitely, unless Stop or Start is pressed again). - Odometer reset - Units –...
  • Page 58 Error messages • EEPROM Error – Solution for this is to replace the console (Note: this is the only error message) • Motor Error – Press stop to enter idle mode – This error means the motor that controls resistance did not respond a s expected. If the error occurs press stop.
  • Page 59 Console programs do not start • Perform Keypad test in Maintenance mode • If you cannot access the test, and the keys seem to have no a ect when pressed, then the keypad has malfunctioned. Program starts but no data registers when 7.5 S is pedaled •...

  • Page 60: Speci Cations

    Speci cations 7.5 S Dimensions Patient weight capacity Length : 80.3” (204cm) 440 lb. (200 kg) Width : 33.1” (84cm) Input power Height : 46.9” (119cm) 12 VDC, 2.74 Amps Weight Fuse rating 305.8 lbs. (139 kg) No user replaceable fuse. Resistance Readouts Isokinetic with 20 levels of e ort.
  • Page 61 Guidance and manufacturer’s declaration – electromagnetic compatibility The 7.5 S is intended for use in the electromagnetic environment speci ed below. The customer or the user of the 7.5 S should assure that it is used in such an environment. Electromagnetic environment –...
  • Page 62 Immunity test IEC 60601 Compliance level – Electromagnetic environment test level guidance Electrical fast +/-2 kV for power +/-2 kV for power Mains power quality should be that transient/burst supply lines supply lines of a typical commercial or hospital environment. IEC 61000-4-4 +/-1 kV for +/-1 kV for...

  • Page 63: Description Of Packaging Symbols

    Description of packaging symbols Indicates that the package is heavy and two or more people are required to lift. Package contains fragile electronic equipment. Care should be used when handling. The product inside the packaging could be easily damaged if dropped or handled without care and attention.
  • Page 64 Indicates that an object is capable of being recycled - not that the object has been recycled or will be accepted in all recycling collection systems. Top. This side up.
  • Page 65 Product warranty Dyaco Commercial & Medical North America LLC (hereinafter “Dyaco”), the manufacturer of the Philips Professional Series Physical Therapy Products (hereinafter “Products”) warrants all of the Prod- ucts and their components listed below for the periods of time set...
  • Page 66 • Proper connection to a grounded power supply of su cient voltage, replacement of blown fuses, repair of loose connections or defects in house or facility wiring. • Expenses for making the tness equipment accessible for servicing, including any item that was not part of the tness equipment at the time it was shipped from the factory.
  • Page 67 • Manufacturer, distributor, or the Licensor shall not be responsible or liable of any direct, indirect, general, special, punitive, incidental or consequential damages; loss of or damage to property; claims of third parties; loss of life; personal injury (including further injury, or re-injury), and any other losses or damages of any kind or character, arising out of or in connection with the use of Biophysical Agents by the facilities or clinicians.
  • Page 68 Service Keep your bill of sale. Twenty four (24) months from the date on the bill of sale or eighteen (18) months from the date of factory shipping as determined by the serial number establishes the warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
  • Page 69 2019© Dyaco Commercial & Medical North America LLC. All right reserved. The Philips trademark and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used under license. This product has been manufactured by and is sold under the responsibility of Dyaco Commercial & Medical North America LLC,...
