Makita TW141DWME Instruction Manual

Cordless impact wrench
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Cordless Impact Wrench
EN
Boulonneuse sans Fil
FR
Akku-Schlagschrauber
DE
Avvitatrice ad impulso a
IT
batteria
Accuslagmoersleutel
NL
ES
Llave de Impacto Inalámbrica
PT
Chave de Impacto a Bateria
DA
Elektronisk akku slagnøgle
EL
Κρουστικό κλειδί μπαταρίας
TR
Akülü Darbeli Somun Sıkma
TW141D
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
BETRIEBSANLEITUNG
ISTRUZIONI PER L'USO
GEBRUIKSAANWIJZING
MANUAL DE
INSTRUCCIONES
MANUAL DE INSTRUÇÕES
BRUGSANVISNING
ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ
KULLANMA KILAVUZU
4
10
16
23
30
37
44
50
56
63

Advertisement

Table of Contents
loading

Related Manuals for Makita TW141DWME

Summary of Contents for Makita TW141DWME

  • Page 1 Cordless Impact Wrench INSTRUCTION MANUAL Boulonneuse sans Fil MANUEL D’INSTRUCTIONS Akku-Schlagschrauber BETRIEBSANLEITUNG Avvitatrice ad impulso a ISTRUZIONI PER L’USO batteria Accuslagmoersleutel GEBRUIKSAANWIJZING MANUAL DE Llave de Impacto Inalámbrica INSTRUCCIONES Chave de Impacto a Bateria MANUAL DE INSTRUÇÕES Elektronisk akku slagnøgle BRUGSANVISNING Κρουστικό...
  • Page 2 Fig.1 Fig.5 Fig.6 Fig.2 Fig.7 Fig.3 Fig.8 Fig.4...
  • Page 3 Fig.9 Fig.10 Fig.11...

  • Page 4: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model: TW141D Fastening capacities Standard bolt M8 - M16 High tensile bolt M6 - M12 Square drive 12.7 mm No load speed 0 - 2,600 min Impacts per minute 0 - 3,200 min Overall length 168 mm Rated voltage D.C.

  • Page 5: Safety Warnings

    Make sure there are no electrical cables, water WARNING: The vibration emission during pipes, gas pipes etc. that could cause a hazard actual use of the power tool can differ from the if damaged by use of the tool. declared value(s) depending on the ways in which SAVE THESE INSTRUCTIONS.

  • Page 6: Functional Description

    SAVE THESE INSTRUCTIONS. shown in the figure, it is not locked completely. CAUTION: Always install the battery cartridge CAUTION: Only use genuine Makita batteries. fully until the red indicator cannot be seen. If not, Use of non-genuine Makita batteries, or batteries that it may accidentally fall out of the tool, causing injury to have been altered, may result in the battery bursting you or someone around you. causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and CAUTION: Do not install the battery cartridge charger.
  • Page 7 Battery protection system ASSEMBLY The tool is equipped with a battery protection system. This system automatically cuts off power to the motor to extend battery life. CAUTION: Always be sure that the tool is The tool will automatically stop during operation if the tool and/ switched off and the battery cartridge is removed or battery are placed under one of the following conditions: before carrying out any work on the tool. Overloaded: Selecting correct impact socket The tool is operated in a manner that causes it to draw an abnormally high current.

  • Page 8: Installing Hook

    The proper fastening torque may differ depending upon Installing hook the kind or size of the bolt, the material of the workpiece to be fastened, etc. The relation between fastening WARNING: torque and fastening time is shown in the figures. Use the hanging/mounting parts for their intended purposes only, e.g., hanging the Proper fastening torque for standard bolt tool on a tool belt between jobs or work intervals.

  • Page 9: Optional Accessories

    NOTE: Excessive fastening torque may damage the ACCESSORIES bolt/nut or impact socket. Before starting your job, always perform a test operation to determine the proper fastening time for your bolt or nut. CAUTION: These accessories or attachments NOTE: If the tool is operated continuously until the are recommended for use with your Makita tool battery cartridge has discharged, allow the tool to rest specified in this manual. The use of any other for 15 minutes before proceeding with a fresh battery accessories or attachments might present a risk of cartridge. injury to persons. Only use accessory or attachment for its stated purpose. The fastening torque is affected by a wide variety of factors including the following. After fastening, always...
