Philips EZTrac Installation Manual

Now that you've purchased your EZTrac™ and successfully installed your hardware on your
trailer or chassis, you are ready for the next step!
1. Navigate to the app store on your smart device (Apple or Android) and search for Phillips Connect. Once you fi nd the app,
start the download process.
2. After you have the app on your smart device, open it and scan the IMEI barcode on your EZTrac™ device. You will
then be prompted to fi ll out your email information.
3. Next, you will need to fi ll out some account information about your Asset and Company name. This will create a shell account
on the web portal.
4. Navigate to your email and you will see an email from Phillips Connect Technologies. Open the email and click the link to
validate your email address.
5. Once your email has been validated, you will be directed to the login page on the Web Portal.
a. Accept EULA, SLA, and Warranty to proceed
6. Now, you will need to create your Web Portal account. You will need to add your fi rst and last name, phone number,
username (email), create a password, and select the appropriate time zone.
7. After you've logged in, you will then select a subscription for the IMEI(s) that you have purchased and input your
payment information.
8. Once your credit card information is entered and processed you will have immediate visibility to all your installed assets
on the User Interface.
9. Confi rm the EZTrac has powered up and shows the current location on the map before assigning the trailer or chassis ID.
Customer Care: 833-213-5839
UI: pct.phillips-connect.com
LIMITED PRODUCT WARRANTY - Company hereby warrants ("Limited Warranty") only to the purchaser that fi rst activates the Product, that the
Product will be free from defects in workmanship and materials for a period ("Limited Warranty Period") of one (1) calendar year after the date that
the product reports to the PCT server. The Limited Warranty does not apply to normal wear and tear and does not cover repair or replacement if the
Product is damaged by tampering, misuse, accident, abuse, neglect, improper installation, misapplication, alteration of any kind, disaster, defects due
to repairs or modifi cations made by anyone other than Company or an authorized service representative of Company, or reception problems caused
by signal conditions or cable or antenna systems outside the Product. Further, the Limited Warranty does not apply to physical damage of any nature
whatsoever to the Product, including any opening or attempted opening of the Product, and any such opening or attempted opening of the Product
shall render the Limited Warranty invalid. REPAIR OR REPLACEMENT OF A DEFECTIVE PRODUCT IS YOUR SOLE AND EXCLUSIVE REMEDY UNDER
THE LIMITED WARRANTY. SOFTWARE LOADED ON THE PRODUCT IS PROVIDED "AS IS" WITHOUT WARRANTY. COMPANY SHALL NOT BE LIABLE
FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES FOR BREACH OF THE LIMITED WARRANTY. TO
THE MAXIMUM EXTENT PERMITTED BY LAW, COMPANY EXPRESSLY DISCLAIMS, AND YOU EXPRESSLY WAIVE, ALL OTHER WARRANTIES, WHETHER
EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PAR-
TICULAR PURPOSE OR USE, OR ANY WARRANTY ARISING OUT OF ANY PROPOSAL, SPECIFICATION, OR SAMPLE. THE TERM OF ANY IMPLIED
WARRANTIES THAT CANNOT BE DISCLAIMED UNDER APPLICABLE LAW SHALL BE LIMITED TO THE DURATION OF THE FOREGOING EXPRESS
WARRANTY PERIOD. SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES AND/OR DO NOT ALLOW LIMITATIONS ON THE
AMOUNT OF TIME AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. THIS LIMITED WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE. You agree that neither Company nor any other
party has made any representations or warranties, nor have you relied on any representations or warranties, express or implied, including any implied
warranty of merchantability or fi tness for any particular purpose with respect to the Products. You acknowledge that no affi rmation of fact or statement
(whether written or oral) made by Company, its representatives, or any other party outside of this Agreement with respect to the Products shall be
deemed to create any express or implied warranty on the part of Company or its representatives. To obtain warranty service Contact the Customer
Service Department using the support number located on the website you were provided when you purchased the product. Provide them with the IMEI
(International Mobile Equipment Identity) for each product for warranty coverage verifi cation. Upon verifi cation of coverage, an RA# will be issued
and provided to you by email, or over the phone. Package product(s) and send to Company with the RA# clearly written on the outside of each pack-
age (returns without an RA# will be rejected) and ship to: PCT Returns at the address provided to you. Note: You are responsible for shipping charges
to the returns department.) Company will test all properly returned products to determine if they are defective. If the product is defective Company will
provide replacement of the defective product(s) and Company is responsible for shipping charges back to you. If the product is not defective, then you
will be charged $49.95 to cover the cost of testing the product and you are responsible for the shipping charges back to you.
Page 4
PHILLIPS CONNECT TECHNOLOGIES
1 2 0 1 2 B U R K E S T R E E T, S A N T A F E S P R I N G S , C A 9 0 6 7 0
PHILLIPS CONNECT TECHNOLOGIES
T R A N S P O R T A T I O N T E C H N O L O G I E S R E I M A G I N E D
PCT-EZTIG REV3_8-21-19
T E L : 8 8 8 . 8 8 0 . 6 8 9 0
W W W . P H I L L I P S - C O N N E C T. C O M
EZTrac GPS Installation Guide
TM
Kit Includes:
EZTrac™
GPS Device
Split Loom
The EZTrac™ GPS Device is installed inline between the main harness and the ABS ECU.
1. Locate the ABS TTMA 5 pin connector near the rear of the trailer/chassis.
PCT-EZTIG REV3_8-21-19
PHILLIPS CONNECT TECHNOLOGIES
1 2 0 1 2 B U R K E S T R E E T, S A N T A F E S P R I N G S , C A 9 0 6 7 0
PHILLIPS CONNECT TECHNOLOGIES
T R A N S P O R T A T I O N T E C H N O L O G I E S R E I M A G I N E D
SCAN FOR MORE
INFORMATION
Four (4) Cable Ties
T E L : 8 8 8 . 8 8 0 . 6 8 9 0
W W W . P H I L L I P S - C O N N E C T. C O M
Page 1
