Page 43
Table of Contents 8 One-touch Playback Mode 9 Video Mode 9.1 Video Playback 1 Welcome 1.1Product highlights 10 Camera Mode 2 Important 11 Voice Mode 2.1 Safety 11.1 Voice Playback 2.2 Hearing safety 12 Remote Control 2.3 Legal restrictions on recording 12.1 Remote Control Enable/Disable 3 Your Video &...
Page 44
16 Changing the battery 16.1 Battery loading 16.2 Battery unloading 17 How to use the back clip of the device 17.1 Back clip installment 17.2 Back clip uninstallment 18 How to wear the back clip 19 FAQs 20 Technical Parameters...
Automatic partitioning and saving of video files against loss • by erroneous operation. VTR8100 support up to 64 G TF card.DSJ-1J does not • 1.1 Product Highlights support external memory. HQ vibrating speaker giving you a live effect while playing •...
2 Important Adjust to a desired volume; do not use headphones for a • long period of time. Please remember not to turn the volume up beyond your • tolerance. 2.1 Safety Do not turn up the volume so high that you can’t hear •...
3 Your digital recorder 3.1.2 DSJ-1J, What’s in the box? 3.1.1 VTR8100, What’s in the box? Note TF card already inserted in the product (battery • compartment).
USB interface Remote control indicator Working status indicator Battery cover latch 3.3 Remote control overview: Power on/off Remote indicator Voice recording Photo taking Video recording...
Power On/Off button for 3 Sec. If the device doesn’t work normally, please make sure the • device is not out of power. VTR8100,When the device is working, do not unplug the • external card directly, or it may damage files or cause a malfunction.
The Voice Tracer or case recharger. can be linked to a computer with a USB cable. VTR8100, The device can be connected to a PC using the USB The Voice Tracer can automatically be recognized as a mass cable.
5 Video Recording goes out, and the device returns to the preview interface. The state indicator turns green. Recording Interface Reference: Please note the instructions in this section when you make the first video recording with your Voice Tracer! (1)On the Preview interface, press the “Video Record” button to start recording.
Page 53
Resolution Current recording time Note Current system date Battery Time watermark Current system time Prior to video recording please set the desired recording • ID Number watermark Remain video parameters. ID Number TF card Please delete any unnecessary files before recording. •...
6 Camera Please note the instructions in this section when you take the first photo with your Voice Tracer! On the preview interface, press the Camera button to take a photo. While taking a photo, a red light appears with a “click” sound.
7 Voice Recording Note Prior to recording, please preset the type of recording • you need. Please note the instructions in this section when you make Please delete any unnecessary files before recording. • the first voice recording with your Voice Tracer! Make a test recording to make sure that the Voice Tracer •...
8 One-touch Playback Mode Please note the instructions in this section when you take the first photo with your Voice Tracer! On the Preview interface, press the Stop button quickly after the video recording file is saved, the Voice Tracer will directly play the file.
9 Video Mode Illustration of Video Playback Interface: On the preview interface, you can enter the playback review interface through the Play button; press the “ ” or “ ” button to select Video Playback, and then press the Play button quickly to enter the video file list interface.
Page 58
playing. 5 When playing, press “ ” or “ ” to choose 2x, 4x, 8x, 16x, 32x, 64x,128x to fast forward or backward. Note If the headphones are plugged in, the speaker of the • recorder is disabled.
10 Camera Mode On the preview interface, you can enter the playback review interface through the Play button; press the “ ” or “ ” button to select Photo Playback, and then press the Play button quickly to enter the photo file list interface. The photo file list interface is shown in the following figure: On this interface, press the sensitivity button to mark the current file as important.
11 Voice Mode Illustration of Voice Playback Interface: On the Preview interface, you can enter the playback review interface through the Play button; press the “ ” or “ ” button to select Voice Playback, and then press the Play button quickly to enter the voice file list interface.
11.1 Voice Playback 1 Press the “ ” or “ ” button to select a file for play back. 2 Press the “Play” button to start playing, and the status indicator turns green. 3 Press “ ” or “ ” to adjust volume. 4 Press the “Stop”...
12 Remote Control Note before using for the first time! If the red indicator is flickering all the time when the • Remote control allows the user to control the device remote control is working after the code is matched, remotely.
13 HDMI On the preview interface of recording, connect the device to a HD display devices with a Micro HDMI switch HDMI cable (cthis cable is available as an accesories), all the operations are still available. Note When connecting HDMI, there are some inconsistencies •...
14 Settings Mode Record type On the preview interface, press the Menu button to enter the Settings interface. See the Settings interface reference. It is comprised of Voice Settings, Video Settings, Camera Settings and System Settings. HQ: WAV format, high quality, bit rate 1536kbps. SLP: WAV format, average quality, bit rate 385kbps.
14.2 Video Settings 14.2.2 Video Quality The Video Settings menu includes Resolution, Video Quality, The Video Quality menu has three options: “S. Fine, Fine, Pre-record, and Delay Record. Press the “ ” or “ ” Normal.” Different quality can be selected for different button to select the Video Settings menu icon, press the “...
Photo size 14.3 Camera Settings 1.2M The Camera Settings menu includes Photo Size, Photo Quality, Photo Rate, and Auto Shooting. Press the “ ” or “ ” button to select the Camera Settings menu icon, press the “ ” or “ ”...
14.4 System Settings 14.3.3 Photo Rate The System Settings menu comprises Language, TV Mode, Photo Rate means that the device can take photos continuously by pressing the Camera button once in the Default Settings, LCD Brightness, System Time, Auto Off, LCD Auto Off, Volume, In-car Model, Video Loop, In-car preview mode or in the course of video recording.
Page 68
14.4.6 Auto Off If the user does not perform an operation on the device over 14.4.5.1 VTR8100, System Time a pre-set time, the system automatically shuts down. See the The System Time interface is illustrated below: auto off setting interface reference below:...
Page 69
14.4.9 In-car mode Auto off Auto off The device can be used as car driving recorder which defaults 5 Min to “Off”, and “Video loop” and “Video loop” are unavailable 1 Min at this time. When the “In-car mode” is on, “Video loop” and 2 Min “Video loop”...
Page 70
14.4.12 Duration 14.4.14 Indicator light Video recording has five time periods: 5 Min, 10 Min, 15 Min, Turn on/off indicator according to needs. 20 Min and 30 Min. In the course of video recording, this function can automatically save a video file periodically at the selected time interval, and enter the recording for the next 14.4.15 Infrared Switch time period without any delay.
Page 71
Press the Menu button to confirm after selection. The System Information menu includes Total Space, Available Space, Remain Video, Remain Sound, Battery Power and 14.4.18.1 ID VTR8100,Number Firmware Version; Total Space: This allows the user to check the amount of The PID setting interface is illustrated below: memory space in the device.
15 Installation and Application of File Management System(FMS) 15.1 Introduction to File Management System The connection between PC and the device is managed by FMS. The FMS is highly confidential, tamper-proof and well interactive. User can change the password, synchronize system time, log management, files upload and so on via FMS on Windows 10/8/7/Vista/XP/2000, Mac OS X, Linux.
Page 73
(3) Choose the path to install the system or choose a default (5) Click“Next”to install the driver. patch, and then click“Next”. (6) Choose the patch and then click “Next”to install the (4) Click“Next”to continue. driver.
Page 74
(7) Choose the path to install and click Next”. (9) Click“Finish”to finish the installation. (8) Click“Install”to continue the installation. (10) The File Management System has been installed on the Note If the FMS is installed on PC with win8, win8.1, win10 •...
“ 用户类型 ”choose“ 管理员 ”or“ 普通用户 ”,“ 普通用 15.3 The Application of FMS 户 ”is only able to access to 的权限只能是进入 removable disc mode. Choose 管理员 ”, and then input password. The default password is:123456. Then click“ 连接设备 ”and“ 登 15.3.1 Connect to PC 陆...
Page 76
15.3.3 Settings 15.3.4 Set numbering Click“ 读取 ”to choose to set“ 分辨率 ”,“ 照片大小 ”,“ 连 The numbering of user or device can be set on the device 拍 ”, “ 视频质量 ”, “ 照片质量 ”, “ 视频分段 ”, “ 自动关屏 ”, and the numbering can also be add to the video or picture “...
Page 77
Choose“ 路径选择 ”from“ 文件管理 ”to choose the upload path;Click“ 搜索 ”to star the file search bar as below: Note On removable disk mode, FMS can not configure the • device. User need disconnect USB cable and reconnect. 15.3.8 Files Management Click“...
Page 78
User can also click “ 删除日志 ” to delete the log form the device. Choose the file need be uploaded or “ 选择全部 ”and click“ 上传文件 ”the files to assigned path. 15.3.9 Log Management Click 查看日志 ”to check the log created by the device:...
16 Changing the battery 16.2 Battery unloading 1 Push the battery cover latch to “OPEN” direction to open 16.1 Battery loading the lid. 2 Take out the battery. 3 Recover the battery cover to the original position. 1 Push the battery cover latch to “OPEN” direction to open the lid.
17 How to use the back clip 18 How to wear the back clip 17.1 Back clip installment (1) Open the clip by pressing the finger position, then nip the epeulet and make the clip hook hookup the bottom of the Match the back clip with the slot 1 on the device, and install epaulet.
My Voice Tracer does not play recordings: www.philips.com/support The battery is out of power, please recharge. My Voice Tracer cannot power on: My Voice Tracer crashes: The battery is out of power, please recharge promptly.
20 Technical Parameters Voice Record HQ REC: bit rate 1536kbps, WAV format Storage SLP REC: bit rate 385kbps, WAV format Internal Storage Estimated Recording Time (32GB): around 44 hours with HQ Operating Conditions recording mode, around 180 hours with SLP Recording mode Type of Internal Storage: C10 TF card Temperature: -30–55°C Humidity: 10–90%, no condensation...
