Summary of Contents for NETGEAR FA310TX
-
Page 2: Start Here
Start Here Instructions in this guide are for users of Windows are installing the Model FA310TX Network Card. For instructions on installing and verifying the Windows network driver, refer to “Install the Windows Network Driver” on the other side of this guide. -
Page 3: Verify Package Contents
Model FA310TXC Network Card) Verify PC Requirements The instructions given in this guide are for using the NETGEAR™ Model FA310TX Network Card in a PC that has a Microsoft system. You must have a PC with a PCI expansion slot that has bus mastering capability. - Page 4 5. Fasten the network card to the rear of the computer chassis by tightening the screw that is on the PC. 6. Replace the PC cover and reconnect the power cord to the PC. Network card Back plate removed Model FA310TX Network Card Installation Guide 7983FB...
-
Page 5: Connect The Network Cables
Note: One of the ports on NETGEAR hubs is switchable between Normal (MDI-X) and Uplink (MDI) with a Normal/Uplink push button. If you are using this switchable port on a NETGEAR hub to connect to a PC or the network card, make sure the Normal/Uplink push button is set to Normal. - Page 6 Note: You must install the network card (instructions on other side of this guide) before installing the network driver. You need to have the Windows CD-ROM and the FA310TX Drivers and Diagnostics Disk ready to use in the installation process.
- Page 7 It is recommended that you let Windows search for an updated driver. To do this, click Next to continue. Insert the FA310TX Drivers and Diagnostics Disk in Drive A, and then click on “Next.” Model FA310TX Network Card Installation Guide...
- Page 8 Windows found the following updated driver for this device: NETGEAR FA310TX Fast Ethernet PCI Adapter If you want to use this driver, click Finish. If this is not the correct driver and you want to search for a different driver manually, click Other Locations.
-
Page 9: Verify Installation
Verify Installation Double-click on “My Computer” on the desktop, double-click on “Control Panel,” and then double-click on “System.” Click on “Device Manager.” Model FA310TX Network Card Installation Guide... - Page 10 Double-click on “Network adapters.” If there is a problem with the installation of the driver, an exclamation point appears next to “NETGEAR FA310TX Fast Ethernet PCI Adapter.” If there is an exclamation point, double-click on “NETGEAR FA310TX Fast Ethernet PCI Adapter.” The “Properties” window opens, and a message regarding the status of the device is displayed in the window.
-
Page 11: Technical Specifications
10% to 90% noncondensing Agency Compliance CE mark, commercial FCC, Part 15, Class B EN 55 022 (CISPR 22), Class B Canada ICES-003, Class B Interface Options RJ-45 connector for 10BASE-T or 100BASE-T Ethernet interface Model FA310TX Network Card Installation Guide ®... - Page 12 Registration Cards which accompanied the products when shipped, (2) return the failed product to NETGEAR designated repair facility with shipping charge prepaid, and (3) provide NETGEAR with proof of the original date of purchase. Repaired or replacement products will be returned to you with shipping charges prepaid.
- Page 13 If you do not have access to the World Wide Web, you can print a registration card and mail it to NETGEAR customer service. The card is included on your Drivers and Diagnostics disk as a Microsoft Word document file called register.doc.
-
Page 14: Compliance Information
NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. - Page 15 FOR HOME OR OFFICE USE EN 55 022 Statement This is to certify that the Model FA310TX Network Card is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class B (CISPR 22).
- Page 16 Internet/World Wide Web To get product support, to register your product online, or to obtain product information and NETGEAR product documentation, direct your Web browser to: http://www.NETGEAR.com Customer Support You can contact Customer Support at the following toll free numbers:...
