Playback
Playing Discs
+
RW
- RW
- RW
+
R
- R
- R
VR
VR
Video
Video
DVD
RAM
VCD
CD
DATA CD
DATA DVD
Z OPEN/
CLOSE
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
0
0
TOP MENU
MENU
H PLAY
x STOP
1
Press Z OPEN/CLOSE, and place a disc on
the disc tray.
S VIDEO
VIDEO
L(MON
O) AUDIO
R
DV IN
LINE-2
IN
ONE-TOU
CH DUBBING
Playback side facing down
2
Press Z OPEN/CLOSE to close the disc
tray.
Wait until "LOAD" disappears from the front
panel display.
3
Press H PLAY.
Playback starts.
To stop playback
Press x STOP.
Button
Operation
Fast reverses or fast forwards the disc when pressed
(fast reverse/fast
during playback.
forward)
Search speed changes with each press:
fast reverse
FR1 T
*2
T T
FR2
*3
T T T
FR3
Plays in slow motion when pressed in pause mode.
(slow)
Playback speed changes with each press:
reverse slow motion
T
T T
T T T
X PAUSE
Pauses playback.
If you pause playback for more than five minutes,
playback starts automatically.
To resume normal playback after playing at various speeds, press H PLAY.
z Hints
• You can change playback options, such as subtitle,
audio track, angle, etc., using the OPTIONS menu
(page 11).
• During playback or pause mode, you can also use the
./> buttons on the recorder as the remote's m/
M buttons. Hold the buttons down during playback to
fast forward or fast reverse. In pause mode, you can
play in slow motion. Three speeds are available,
depending on the duration of the press.
• See "DVD Audio/Subtitle Language" on page 99 for
the meaning of the language abbreviation.
Notes
• If you pause playback of a CD, or DATA CD/DATA
DVD containing MP3 audio tracks, playback will not
start until you press H PLAY or X PAUSE.
• Sound will be interrupted during Scan Audio
(page 38).
z Hints
• You can play DATA CDs or DATA DVDs with MP3
audio tracks or JPEG image files (pages 41 or 42).
• If you insert a DVD VIDEO, VIDEO CD, or CD,
playback starts automatically depending on the disc.
• When playing a DVD+RW, DVD-RW, DVD+R,
DVD-R, and DVD-RAM, you can select the title from
the Title List menu (page 39).
• When using a DVD-RAM with a cartridge, remove the
disc from the cartridge.
Note
To play a disc recorded with other equipment on this
recorder, finalize the disc on the recording equipment
first.
Using the DVD's Menu
+
RW
- RW
+
+
R
R
- R
DVD
Video
Video
When you play a DVD VIDEO, or a finalized
DVD+RW, DVD-RW (Video mode), DVD+R, or
DVD-R (Video mode), you can display the disc's
menu by pressing TOP MENU or MENU.
Disc
All discs
*1
FF1 with sound
(Scan Audio) is
fast forward
available for DVDs
t FF1
*1
with Dolby Digital
t t FF2
*2
soundtracks.
t t t FF3
*3
*2
FR2 and FF2 are not
available for MP3.
*3
FR3 and FF3 are only
available for DVDs
and VIDEO CDs.
+
- RW
- RW
RW
VR
Video
- R
- R
+
R
VR
Video
*
forward slow motion
VCD
DVD
RAM
t
* Playback direction
t t
only
t t t
All discs
Notes on playing DTS soundtracks on a CD
When playing DTS-encoded CDs, excessive noise
will be heard from the analog stereo jacks. To
avoid possible damage to the audio system, the
consumer should take proper precautions when
the analog stereo jacks of the recorder are
connected to an amplification system. To enjoy
DTS Digital Surround™ playback, an external
5.1-channel decoder system must be connected to
the digital jack of the recorder.
Notes on playing DVDs with a DTS soundtrack
DTS audio signals are output only through the
DIGITAL AUDIO OUT (COAXIAL or
OPTICAL)/HDMI OUT jack.
When you play a DVD with DTS soundtracks, set
"Digital Out" – "DTS" to "On" of "Audio" in the
"Setup" display (page 79).
If you connect the recorder to audio equipment
without a DTS decoder, do not set "DTS" to "On"
in "Audio" setup. A loud noise (or no sound) may
come out from the speakers, which might disturb
your ears or cause damage to the speakers.
,
Playback Options
Z OPEN/CLOSE
Number buttons
O RETURN
REPLAY/
ADVANCE
. PREV
Button
Operation
Z
OPEN/CLOSE
Stops playing and opens the disc tray.
AUDIO
Selects one of the audio tracks recorded on the disc
when pressed repeatedly.
- RW
VR
DVD
VCD
SUBTITLE
Selects a subtitle language when pressed repeatedly.
ANGLE
Selects an angle when pressed repeatedly.
If various angles (multi-angles) for a scene are
recorded on the disc, "
display.
REPLAY/
• Replays or briefly fast forwards a scene when
ADVANCE
pressed during playback.
• Goes to the previous or next frame when pressed
during pause mode.
. PREV/
• Goes to the beginning of the current or next title/
NEXT >
chapter/scene/track and starts playback when
pressed during playback.
• Goes to the beginning of the previous title/chapter/
scene/track when .PREV is pressed within three
seconds after starting a title/chapter/scene/track.
35
36
Playing quickly with sound (Scan
Audio)
(DVDs with Dolby Digital soundtracks
only)
You can play quickly with dialog or sound during
FF1 fast-forward of a DVD with Dolby Digital
soundtracks. Simply press M during playback.
z Hint
To turn off the Scan Audio function, set "Scan Audio" of
"Audio" to "Off" in the "Setup" display (page 80).
Note
Sound will be interrupted during Scan Audio.
Playing VIDEO CDs with PBC
functions
VCD
PBC (Playback Control) allows you to play
VIDEO CDs interactively using a menu on your
TV screen.
When you start playing a VIDEO CD with PBC
functions, a menu appears.
Select an item using the number buttons and press
ENTER. Then follow the instructions in the menu
(press H PLAY when "Press SELECT"
appears).
Operations differ depending on the disc. See the
instructions supplied with the disc.
To cancel PBC Playback
Press MENU to display "Menu: Off." To use the
PBC functions, press MENU again to display
"Menu:On."
Resuming playback from the point
where you stopped the disc (Resume
Play)
Press H PLAY again after stopping a disc to
resume playback from the same point.
To start from the beginning, press x STOP twice,
and press H PLAY.
The point where you stopped playing is cleared
when:
– you open the disc tray.
– you play another title.
– you switch the Title List menu to original or
Playlist (DVD-RW (VR mode)/DVD-R (VR
mode)/DVD-RAM only).
37
38
1-8
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
ANGLE
0
0
SUBTITLE
MENU
AUDIO
M/m/</,,
ENTER
> NEXT
H PLAY
x STOP
X PAUSE
Disc
All discs
- RW
VR
VCD
: Selects the main or sub sound.
- R
VR
: Selects the audio source.
: Selects stereo or monaural audio tracks.
DVD
DVD
" appears in the front panel
+
RW
+
R
DVD
All discs
– you edit the title after stopping playback.
– you make a recording.
Playing restricted DVDs (Parental
Control)
DVD
If you play a restricted DVD, a message appears
asking whether you want to override the
restriction.
1
Select "OK" and press ENTER.
The display for entering your password
appears.
2
Enter your four digit password using the
number buttons.
The recorder starts playback.
To register or change the password, see "Parental
(DVD VIDEOs only)" on page 83.
Locking the recorder (Child Lock)
You can lock all of the buttons on the recorder so
that the settings are not canceled by mistake.
With the recorder turned on and stopped, hold
down x (stop) on the recorder for more than ten
seconds. The recorder turns off and "CHILD
LOCK" appears in the front panel display. The
indicator remains lit if there is a timer setting. The
recorder will not work except for timer recordings.
To unlock the recorder, hold down x on the
recorder until "CHILD LOCK" disappears from
the front panel display. The recorder is unlocked
and turns on.
To stop timer recording while the recorder is
locked, press x twice. The recording stops and the
recorder is unlocked.
Note
The recorder will be unlocked when you stop timer
recording by pressing x.
- R
DVD
VR
.
- RW
- RW
VR
Video
- R
- R
VR
Video
RAM
