Makita 6911HD Instruction Manual

Cordless impact wrench equipped with electric brake 12.7 mm (1/2”)
Hide thumbs Also See for 6911HD:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
Cordless Impact
Wrench
Equipped with Electric Brake
12.7 mm (1/2")
MODEL 6911HD
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
w w w . m a k i t a t o o l s . c o m

Advertisement

Table of Contents
loading

Related Manuals for Makita 6911HD

Summary of Contents for Makita 6911HD

  • Page 1 Cordless Impact Wrench Equipped with Electric Brake 12.7 mm (1/2”) MODEL 6911HD I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SAVE THESE INSTRUCTIONS Work Area 1. Keep your work area clean and well lit. Cluttered benches and dark areas invite acci- dents. 6911HD M8 - M14 (5/16” - 9/16”) M6 - M12 (1/4” - 1/2”) 12.7 mm (1/2”) 0 - 1,800/min.
  • Page 3 3. Keep bystanders, children, and visitors away while operating a power tool. Distrac- tions can cause you to lose control. Electrical Safety 4. A battery operated tool with integral bat- teries or a separate battery pack must be recharged only with the specified charger for the battery.

  • Page 4: Specific Safety Rules

    SERVICE 21. Tool service must be performed only by qualified repair personnel. Service or main- tenance performed by unqualified personnel may result in a risk of injury. SPECIFIC SAFETY RULES DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to cordless impact wrench safety rules.
  • Page 5 (1) battery charger, (2) battery, and (3) product using battery. 3. CAUTION - To reduce risk of injury, charge only MAKITA rechargeable marked on the charger label. Other types of batteries may burst causing personal injury and damage.
  • Page 6 11. Do not disassemble charger or battery cartridge; take it to a qualified serviceman when service or repair is required, Incor- rect reassembly may result in a risk of electric shock or fire. 12. To reduce risk of electric shock, unplug charger from outlet before attempting any maintenance or cleaning.

  • Page 7: Functional Description

    FUNCTIONAL DESCRIPTION 002302 1. Set plate 2. Battery cartridge 004545 1. Battery cartridge 2. Charging light 3. Battery charger CAUTION: • Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge •...
  • Page 8 NOTE: • The battery charger is for charging Makita battery cartridge. Never use it for other purposes or for other manufacturer’s batteries. • When you charge a new battery cartridge or a battery cartridge which has not been used for a long period of time, it may not accept a full charge.

  • Page 9: Electric Brake

    This tool is equipped with an electric brake. If the tool consis- tently fails to quickly stop after switch trigger release, have tool serviced at a Makita service center. Reversing switch action This tool has a reversing switch to change the direction of rotation.

  • Page 10: Operation

    002341 1. Socket 2. Anvil OPERATION 002357 Standard bolt N.m (ft.lbs) M12 (1/2”) (72) M14 (9/16”) (58) (43) M10 (3/8”) (29) (14) 002358 High tensile bolt N.m (ft.lbs) M12 (1/2”) (87) (72) (58) M10 (3/8”) (43) M8 (5/16”) (29) (14) Installing or removing socket To install the socket, push it onto the anvil of the tool until it locks into place.

  • Page 11: Maintenance

    Makita Authorized or Factory Service Centers, always using Makita replacement parts. Recycling the Battery The only way to dispose of a Makita battery is to recycle it. The law prohibits any other method of disposal. To recycle the battery: 1. Remove the battery from the tool.
  • Page 12 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 13 First-Class Postage Required Post Office will not deliver without proper postage. Makita U.S.A., Inc. 14930 Northam Street La Mirada, CA 90638-5753 Fold...
  • Page 14 Paste 3. How did you learn about this product: Magazine From Dealer Newspaper Store Display Catalog 4. Most favored points are: Design Features Size Price Makita Brand MODEL NO. YEAR SERIAL NO. PHONE 20-29 30-39 40-49 Paste Paste Radio Exhibition...

  • Page 15: Factory Service Centers

    Date Purchased When you need service: Send complete tool (prepaid) to one Dealer’s Name & Address of the Makita Factory Service Centers listed, or to an Authorized Makita Service Center. Be sure to attach a letter to the outside of Model No.
  • Page 16 MAKITA LIMITED ONE YEAR WARRANTY Warranty Policy Every Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase.
