Makita 6910 Instruction Manual

Hide thumbs Also See for 6910:
Table of Contents

Advertisement

Quick Links

Download this manual
Impact Wrench
25.4 mm (1")
MODEL 6910
002293
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading

Related Manuals for Makita 6910

Summary of Contents for Makita 6910

  • Page 1 Impact Wrench 25.4 mm (1”) MODEL 6910 002293 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model 6910 Capacities Bolt size M22 - M24 (7/8” - 1”) Square drive 25.4 mm (1”) No load speed (RPM) 1,400/min. Impacts per minute 1,500 Max. fastening torque 980 N.m (722 ft.lbs) Overall length 389 mm (15-1/4”) Net weight 9 kg (19.8 lbs)

  • Page 3: Personal Safety

    qualified electrician if you are in doubt as 13. Do not overreach. Keep proper footing whether outlet properly and balance at all times. Proper footing and grounded. If the tools should electrically mal- balance enables better control of the tool in function or break down, grounding provides a unexpected situations.
  • Page 4 22. Use only accessories that are recom- tenance performed by unqualified personnel mended by the manufacturer for your could result in a risk of injury. model. Accessories that may be suitable for 24. When servicing a tool, use only identical one tool, may become hazardous when used replacement parts.

  • Page 5: Specific Safety Rules

    An adapter Fig. “B” and “C” is available for connecting Fig. “A” type plugs to two- prong receptacles. The green-colored rigid ear, lug, etc., extending from the adapter must be con- nected to a permanent ground, such as a properly grounded outlet box. Adapter Grounding Means Cover of Grounded...
  • Page 6 SAVE THESE INSTRUCTIONS WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury.

  • Page 7: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Switch action 002315 CAUTION: • Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released.

  • Page 8: Operation

    Installing or removing socket 002340 To install the socket, push it onto the anvil of the tool until it locks into place. To remove the socket, simply pull it off. 1. Socket 2. Anvil OPERATION The proper fastening torque may differ depending upon the kind or size of the bolt, the material of the workpiece to be fastened, etc.
  • Page 9 NOTE: • Hold the tool pointed straight at the bolt or nut. • Excessive fastening torque may damage the bolt/nut or socket. Before starting your job, always perform a test operation to determine the proper fastening time for your bolt or nut. The fastening torque is affected by a wide variety of factors including the following.

  • Page 10: Maintenance

    CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 11 Memo...
  • Page 12 Memo...
  • Page 13 Stamp Timbre Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold...
  • Page 14 Your answers to the following questions are appreciated. 1. This product was purchased from? 3. How did you first learn of Makita Power Tools? Hardware/lumber Store Industrial Supply Magazine/Newspaper Catalog Tool Distributor Other ( From dealer Other ( Store display 2.
  • Page 15 When you need service... DATE • Explain the problem in a letter PURCHASED: • Enclose the letter with the tool DEALER’S NAME • Package carefully and send prepaid & ADDRESS: to the nearest Makita factory or authorized service centre MODEL NO.: SERIAL NO.:...
  • Page 16 WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
