Cobra microTALK MT 550 Manual

Cobra electronics manual microtalk two-way radio mt 550
Hide thumbs

Advertisement

Table of Contents

ENGLISH
Antenna
VOLUME CONTROL
Buttons
TALK Button
LIGHT/MAX
RANGE Button
Charger
CALL Button
Speaker/
Microphone
Two-Way Radio Model MT 550
This equipment is intended for use in:
AT
BA
BE
BG
CH
External Speaker/
CS
Microphone Jack
LOCK Button
FI
CY
IE
FR
CZ
IS
GB
DE
IT
GR
DK
LT
HR
EE
LV
HU
ES
LI
POWER Button
CHANNEL SELECT
Buttons
Wrist Strap
Connection
Location
MODE Button
Belt Clip
Battery
Compartment
Lock Tab
PT
LU
MK
RO
SE
MT
SI
NL
SK
NO
TR
PL
Countries of use

Advertisement

Table of Contents
loading

Related Manuals for Cobra microTALK MT 550

Summary of Contents for Cobra microTALK MT 550

  • Page 1 Antenna VOLUME CONTROL Buttons TALK Button LIGHT/MAX RANGE Button Charger CALL Button Speaker/ Microphone Two-Way Radio Model MT 550 This equipment is intended for use in: External Speaker/ Microphone Jack LOCK Button MODE Button Belt Clip Battery Compartment Lock Tab...

  • Page 2: Product Features

    PMR 446 frequencies as authorized. The use of this two-way radio product involves the public airways and its use may be subject to local laws or regulations. Contact your radio licensing authority for more information.

  • Page 3: Operation

    OPERATION Desktop Charger and Rechargeable Batteries To Insert Batteries in Radio: 1. Remove belt clip by releasing belt clip latch and sliding clip up. 2. Pull down on lock tab to remove battery cover. 3. Insert GA-3ANH batteries according to polarity markings. NOTE: Estimated operation time on full charge: 12 hours.

  • Page 4: Call Button

    OPERATION Communicating with Another Person To Talk To Another Person: 1. Press and hold the TALK button. 2. With the microphone about 5 cm (2 inches) from your mouth, speak in a normal voice. 3. Release the button when you have finished talking and listen for a response. You cannot receive incoming calls while pressing the TALK button.

  • Page 5: Display Illumination

    OPERATION Display Illumination To Illuminate Your Display: – Press and release the LIGHT/MAX RANGE button to illuminate the display for ten (10) seconds. Auto Squelch/Maximum Range Extender Your microTALK ® radio is equipped with Auto Squelch, which automatically shuts off weak transmissions and unwanted noise resulting from terrain, conditions, or from reaching your maximum range limit.
  • Page 6 MODE FUNCTIONS OPERATION Scrolling Through the Mode Functions By scrolling through the Mode Functions, you will be able to select or change preferred features of your microTALK through the Mode Functions, your radio features will be displayed in the same predetermined order: Set CTCSS Privacy Codes Set VOX On/Off Set VOX Sensitivity Level...

  • Page 7: Channel Scan

    MODE FUNCTIONS OPERATION Mode Button Select VOX Sensitivity Level Scan Rog Power Saver 3. When your desired VOX sensitivity level is displayed, choose one of the following: a. Press the MODE button to enter the new setting and proceed to other functions. b.

  • Page 8: "Roger Beep" Confirmation Tone

    MODE FUNCTIONS OPERATION Select Channel Mode Button Scan Power Saver Channel Buttons Select Scan Privacy Codes Scan Power Saver While setting CTCSS privacy code scan, if you do not press any buttons for fifteen (15) seconds your radio will automatically return to LISTENING MODE on the channel/privacy code that was displayed before you entered Mode Functions.

  • Page 9: Declaration Of Conformity

    For warranty and customer service information, please contact your local dealer. For use in EU countries, subject to local laws and regulations. CEEL™ is a trademark of Cobra Electronics Corporation, USA. Snake design and microTALK ® are registered trademarks of Cobra Electronics Corporation, USA.
