Cobra MT 220 Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
MT 220 2-Way Radio
Features of This Product
• Two-way static-free
radio with a range of
up to 3 km (2 miles)
• 6 channels*
• SuperFlex™ antenna
• Holster belt clip
• Roger beep confirma-
tion tone
• Backlit LCD
• Microphone/Speaker
jacks
Product Information
This Cobra microTALK
radio has been manu-
factured to meet all
required standards for
radio equipment using
PMR 446 frequencies as
authorized. The use of
this 2-way radio product
involves the public air-
ways and its use may be
subject to local laws or
regulations. Contact
your radio licensing
authority for more
information.
Installing Batteries
-
+
-
+
+
-
+
-
10
11
8
9
Install Batteries
Pull lock tab down to remove
1
Insert four "AAA" batteries. Position batteries according to
2
polarity markings.
* The French version of the Cobra microTALK radios include only 6 channels,
which have been approved by the Autorité de Régulation des
Télécommunications (ART).
© 2000 Cobra Electronics Corp., 6500 West Cortland Street
Chicago, Illinois 60707 USA
1
2
3
5
4
6
7
battery cover.
8
www.cobraelectronics.com
English
1
12
13
10
12
13
11

Advertisement

loading

Related Manuals for Cobra MT 220

Summary of Contents for Cobra MT 220

  • Page 1 Insert four “AAA” batteries. Position batteries according to polarity markings. * The French version of the Cobra microTALK radios include only 6 channels, which have been approved by the Autorité de Régulation des Télécommunications (ART). © 2000 Cobra Electronics Corp., 6500 West Cortland Street Chicago, Illinois 60707 USA www.cobraelectronics.com...
  • Page 2 Operation The Private Mobile Radio Story Turning On Your Turning On Your microTALK microTALK Push and hold the POWER button for 2 seconds. An audible tone will indicate that the unit is on. Illuminating the Display Push and release LIGHT/MAX RANGE button to illuminate display for 10 seconds.

  • Page 3: Auto Battery Save

    Select Channel Auto Battery Save Your MT 220 has a unique circuit designed to extend battery life. If there are no transmissions within 10 seconds, the unit will automatically switch to battery save mode and will be shown in the display.
  • Page 4 Select Channel Auto Battery Save Your MT 220 has a unique circuit designed to extend battery life. If there are no transmissions within 10 seconds, the unit will automatically switch to battery save mode and will be shown in the display.
  • Page 5 Roger Beep Confirmation Tone Roger Beep Confirmation Tone Your listener will hear an audible tone when you release the TALK button. This alerts the other party that you have finished talking and that they can begin talking. Listening For Another Party When finished talking: Listening For Release...
  • Page 6 Caring for Your microTALK Radio The microTALK 2-Way Radio will give you years of service if cared for properly. Here are some suggestions: 1. Handle unit gently. 2. Keep away from dust. 3. Never place the unit in water or in a damp place. 4.
