Cobra MicroTalk MT 615 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ENGLISH
1
10
9
8
7
6
Two-Way Radio Model MT 615
2
3
4
1. Antenna
2. External Speaker/Charge
Microphone Jack
3. Mode/Power Button
4. Lock Button
5. Channel Select Buttons
6. Speaker/Microphone
7. Light/Max Range Button
8. Volume Control Buttons
9. Talk Button
10. Call Button
11. Belt Clip
12. Battery Compartment
13. Lock Tab
5
11
12
13

Advertisement

Table of Contents
loading

Related Manuals for Cobra MicroTalk MT 615

Summary of Contents for Cobra MicroTalk MT 615

  • Page 1 Two-Way Radio Model MT 615 ENGLISH 1. Antenna 2. External Speaker/Charge Microphone Jack 3. Mode/Power Button 4. Lock Button 5. Channel Select Buttons 6. Speaker/Microphone 7. Light/Max Range Button 8. Volume Control Buttons 9. Talk Button 10. Call Button 11. Belt Clip 12.

  • Page 2: Product Features

    PRODUCT FEATURES English Features • Two-Way Radio with up to a 5 km (3 mile) range • 8 Channels* • 38 CTCSS Privacy Codes • 83 DCS Privacy Codes • Backlit LCD Display • Battery Saver Circuitry • Maximum Range Extender •...

  • Page 3: Operation

    OPERATION English Charger and Rechargeable Batteries Remove Belt Clip Lock Tab Insert Batteries To Insert Batteries in Radio: 1. Remove belt clip by releasing belt clip latch and sliding clip up. 2. Push up on lock tab to remove battery cover. 3.
  • Page 4 OPERATION English Communicating with Another Person Talk Button 5 cm (2 Inches) From Mouth 1. Press and hold the TALK button. 2. With the microphone about 5 cm (2 inches) from your mouth, speak in a normal voice. 3. Release the button when you have finished talking and listen for a response. You cannot receive incoming calls while pressing the TALK button.

  • Page 5: Microtalk ® Range

    OPERATION English To Illuminate Display Light/Max Range Button – Press and release the LIGHT/MAX RANGE button to illuminate the display for 10 seconds. Auto Squelch/Maximum Range Extender Your microTALK radio is equipped with Auto Squelch, which automatically shuts off weak transmissions and unwanted noise ®...
  • Page 6 MODE FUNCTIONS OPERATION English Scrolling Through the Mode Functions By scrolling through the Mode Functions, you will be able to select or change preferred features of your microTALK radio. While you are scrolling ® through the Mode Functions, your radio features will be displayed in the same predetermined order: Set CTCSS Privacy Codes Set DCS Privacy Codes Set VOX On/Off...
  • Page 7 MODE FUNCTIONS OPERATION English DCS Privacy Codes Mode Button DCS OFF DCS (Digital Coded Squelch) is an advanced digital coding system allowing you to select one of 83 privacy codes to reduce incoming transmissions from other users on the channel. NOTE: If you are using a DCS code, both radios must be turned to the same channel and DCS privacy code to communicate.

  • Page 8: Channel Scan

    MODE FUNCTIONS OPERATION English To Set the VOX Sensitivity Level: Mode Button Channel Buttons Select VOX Sensitivity Level 1. Press the MODE button until the VOX icon flashes and the current sensitivity level is displayed. The current sensitivity level is displayed with the letter “L” and a number 1 to 5, 5 being the most sensitive level and 1 being the least sensitive level.
  • Page 9 MODE FUNCTIONS OPERATION English CTCSS Privacy Code Scan Select Channel Mode Button Your microTALK radio can automatically scan the CTCSS privacy codes (01 to 38) within ® one (1) channel. To Scan Privacy Codes: 1. While in LISTENING MODE, press the CHANNEL UP or CHANNEL DOWN button to choose the channel on which you wish to scan the CTCSS privacy codes.
  • Page 10 MODE FUNCTIONS OPERATION English DCS Privacy Code Scan Mode Button Select Channel You can automatically scan the DCS privacy codes (01 to 83) within one channel. NOTE: The radio must be in the CTCSS OFF MODE when scrolling through mode functions or DCS mode will be skipped.

  • Page 11: "Roger Beep" Confirmation Tone

    MODE FUNCTIONS OPERATION English Set Call Tones Mode Button Select Call Tones You can choose between five (5) different call tones to transmit a unique call alert. To Change a Call Tone Setting: 1. Press the MODE button until the letter “C” is displayed. The current call tone number will be flashing on the display next to the “C.”...

  • Page 12: Warranty And Customer Service

    R&TTE Declaration of Conformity (DoC)/, English Warranty & Customer Ser vice We, Cobra Electronics Europe Limited of Warranty & Customer Service Dungar House, Northumberland Avenue For warranty and customer service information, Dun Laoghaire, County Dublin, Ireland please contact your local dealer.
