Repeat
Step 9
This completes the VIP6-80 installation.
If you experience other problems that you are unable to solve, contact TAC (see the
Assistance" section on page
To configure the new interface, use the configuration section of the specific port adapter installation and
configuration guide, or the Cisco IOS software configuration documentation listed in the
Documentation" section on page
Documentation CD-ROM.
Using show Commands to Verify the VIP6-80 Status
The following steps use show commands to verify that the new interfaces are configured and operating
correctly.
Use the show version command to display the system hardware configuration. Ensure that the list
Step 1
includes the new interfaces.
Display all the current interface processors and their interfaces with the show controllers command.
Step 2
Verify that the new VIP6-80 appears in the correct interface processor slot.
Step 3
Specify one of the new interfaces with the show interfaces type interface-processor-slot-
number/port-adapter-slot-number/interface-port-number command and verify that the first line of the
display specifies the interface with the correct slot number. Also verify that the interface and line
protocol are in the correct state: up or down.
Display the protocols configured for the entire system and specific interfaces with the show protocols
Step 4
command. If necessary, return to configuration mode to add or remove protocol routing on the system
or specific interfaces.
Display the running configuration file with the show running-config command. Display the
Step 5
configuration stored in the RSP NVRAM using the show startup-config command. Verify that the
configuration is accurate for the system and each interface.
If the interface is down and you configured it as up, or if the displays indicate that the hardware is not
functioning properly, ensure that the network interface is properly connected and terminated. If you still
have problems bringing the interface up, contact a service representative for assistance.
This completes the procedure to verify that the new interfaces are properly configured, using the show
commands.
Note
The outputs that appear in this document may not match the output you receive when running these
commands. The outputs in this document are examples only.
Versatile Interface Processor (VIP6-80) Installation and Configuration Guide
28
Step 1
through
Step 8
to verify that any additional VIP6-80s are properly installed.
38), or a service representative for assistance.
2. The documentation is available online on Cisco.com, and on the
"Obtaining Technical
"Related
OL-5078-01
