Replace the fuse
If there is no power, check the fuse and replace
it if it is damaged.
1
Check the electric connection.
2
Remove the damaged fuse from the rear
panel.
3
Insert a new fuse with the same
specifications (15 A).
L
REAR
R
Note
•
If the fuse gets damaged immediately after it is
replaced, an internal malfunction may occur. In such
case, consult your Philips retailer.
EN
18
10 Product
Information
Note
•
Specifications are subject to change without prior
notice.
General
Power supply
Fuse
Suitable speaker
impedance
Maximum power
output
Continuous power
output
Pre-Amp output
voltage
Aux-in level
Radio
Frequency range
- FM
Usable sensitivity -
FM (S/N = 20 dB)
Frequency range -
AM(MW)
Usable sensitivity -
AM(MW) (S/N =
20 dB)
12 V DC (11 V - 16 V),
negative ground
15 A
4 - 8
50 W x 4 channels
22 W x 4 RMS
(4
10% T.H.D.)
2.5 V
500 mV
87.5 - 108.0 MHz,
65.0 - 74.0 MHz (100
kHz per step in auto
search and 50 kHz per
step in manual search)
8 µV
522 - 1,620 KHz
(9 kHz)
30 µV
