Quick Links

MODEL T32717
ELECTRIC PIPE AND TUBE
NOTCHER w/STAND
OWNER'S MANUAL
(For models manufactured since 07/21)
COPYRIGHT © JULY, 2021 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
V1.07.21
#CS21936 PRINTED IN CHINA

Advertisement

Table of Contents
loading

Summary of Contents for Grizzly T32717

  • Page 1 (For models manufactured since 07/21) COPYRIGHT © JULY, 2021 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. V1.07.21 #CS21936 PRINTED IN CHINA...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.
  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ..........................2 Contact Info ..........................2 Manual Accuracy ........................2 Identification ..........................3 Controls & Components ......................4 Machine Data Sheet ........................5 SECTION 1: SAFETY ........................6 Safety Instructions for Machinery ....................6 Additional Safety for Electric Pipe and Tube Notchers .............. 8 SECTION 2: POWER SUPPLY ......................
  • Page 4: Introduction

    ID label (see below). This information is required for us to provide proper tech support, and it helps us determine if updated documentation is available for your machine. Manufacture Date Serial Number Model T32717 (Mfd. Since 07/21)
  • Page 5: Identification

    Viewing Viewing ON/OFF Motor Window Window Buttons Notching Hole (1 of 8) Chip Drawer (1 of 2) To reduce your risk of serious injury, read this entire manual BEFORE using machine. Model T32717 (Mfd. Since 07/21)
  • Page 6: Controls & Components

    " Figure 1. Controls. wall thickness (1" schedule 40). A. ON/OFF Buttons: Turns notcher ON and OFF when pressed. B. Chip Drawer: Catches notching chips and cut off pieces and is removable for easy emptying. Model T32717 (Mfd. Since 07/21)
  • Page 7: Machine Data Sheet

    Speed..................................1650.RPM Type................................TEFC.Capacitor-Start Power.Transfer..................................Gear Bearings..........................Shielded.&.Permanently.Lubricated Centrifugal.Switch/Contacts.Type............................Internal Main Specifications: Operation Information Nominal.Diameter.Capacity..................1/4,.3/8,.1/2,.3/4,.1,.1-1/4,.2,.2-1/4.in. Maximum.Notch.Size............................2-1/4.in. Maximum.Wall.Thickness......................1/8.in..(1".Schedule.40) Suitable.Materials....................Carbon.Steel,.Non-Ferrous.Materials Notch.Angle................................90.deg. Gear.Oil.Capacity..............................2.1.qt. Model T32717 (Mfd. Since 07/21) Model T32717 Page 1 of 2...
  • Page 8: Section 1: Safety

    Never operate under the influence of drugs or injury or blindness from flying particles. Everyday alcohol, when tired, or when distracted. eyeglasses are NOT approved safety glasses. Model T32717 (Mfd. Since 07/21)
  • Page 9 Make sure they are properly installed, you experience difficulties performing the intend- undamaged, and working correctly BEFORE ed operation, stop using the machine! Contact our operating machine. Technical Support at (570) 546-9663. Model T32717 (Mfd. Since 07/21)
  • Page 10: Additional Safety For Electric Pipe And Tube Notchers

    If normal safety pre- respect. Failure to do so could result in cautions are overlooked or ignored, seri- serious personal injury, damage to equip- ous personal injury may occur. ment, or poor work results. Model T32717 (Mfd. Since 07/21)
  • Page 11: Section 2: Power Supply

    To reduce the risk of these hazards, avoid over- loading the machine during operation and make sure it is connected to a power supply circuit that meets the specified circuit requirements. Model T32717 (Mfd. Since 07/21)
  • Page 12 Minimum Gauge Size ......14 AWG all local codes and ordinances. Maximum Length (Shorter is Better)..50 ft. -10- Model T32717 (Mfd. Since 07/21)
  • Page 13: Section 3: Setup

    Grizzly or the shipping agent. You MUST have the original pack- Box Contents (Figure 4) aging to file a freight claim.
  • Page 14: Site Considerations

    Only install in an Shadows, glare, or strobe effects that may distract access restricted location. or impede the operator must be eliminated. Electrical Connection 22½" 33" Figure 5. Minimum working clearances. -12- Model T32717 (Mfd. Since 07/21)
  • Page 15: Assembly

    With help from assistants, move machine off of pallet and onto crate top, and orient it so ON/OFF buttons face up (see Figure 6). Figure 6. Machine positioned for assembly. -13- Model T32717 (Mfd. Since 07/21)
  • Page 16: Anchoring To Floor

    OFF Concrete (O) button to turn machine OFF. Drilled Hole The motor should run smoothly and without unusual problems or noises. Figure 8. Popular method for anchoring machinery to a concrete floor. -14- Model T32717 (Mfd. Since 07/21)
  • Page 17: Section 4: Operations

    Regardless of the content in this sec- in this manual are easier to understand. tion, Grizzly Industrial will not be held liable for accidents caused by lack of training. Due to the generic nature of this overview, it is not intended to be an instructional guide.
  • Page 18: Notching Tips

    • Empty the chip drawer periodically to keep ⁄ " cut off pieces from accumulating and lodging ⁄ " in notching mechanisms. ⁄ " ⁄ " Figure 11. Location and size of notching holes. -16- Model T32717 (Mfd. Since 07/21)
  • Page 19 — If all edges of notch are not even, repeat notching operation until they are, then turn machine OFF. Turn machine ON and allow machine to run for a few minutes to distribute lubricant from Step 4 over and inside dies. -17- Model T32717 (Mfd. Since 07/21)
  • Page 20: Section 5: Accessories

    To reduce this risk, only install accessories terials including steel, copper, and aluminum. recommended for this machine by Grizzly. NOTICE Refer to our website or latest catalog for additional recommended accessories.
  • Page 21: Section 6: Maintenance

    To reduce risk of shock or accidental startup, always Lubricate these components weekly to keep the disconnect machine from Model T32717 notching smoothly. See below for power before adjustments, a recommended lubrication product. maintenance, or service. T26419—Syn-O-Gen Synthetic NLGI#2 Grease...
  • Page 22 Figure 18. Apply a few dabs of NLGI#2 grease to both ends of eccentric shaft (see Figure 21). Figure 19. Area to clean. Figure 21. Location of eccentric shaft ends. -20- Model T32717 (Mfd. Since 07/21)
  • Page 23: Section 7: Service

    9. Electronic start switch at fault. 9. Test/replace if at fault. 10. Centrifugal switch/contact points at fault. 10. Adjust centrifugal switch/clean contact points. Replace either if at fault. 11. Motor or motor bearings at fault. 11. Replace motor. -21- Model T32717 (Mfd. Since 07/21)
  • Page 24 2. Dies need lubrication. 3. Dies are dull or have burrs. 3. Carefully remove and hone or replace dies. If honing, avoid changing die diameter and creating larger space for cut off pieces to get caught in. -22- Model T32717 (Mfd. Since 07/21)
  • Page 25: Section 8: Wiring

    Technical Support at (570) 546-9663. The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com. -23- Model T32717 (Mfd. Since 07/21)
  • Page 26: Wiring Diagram

    Wiring Diagram MOTOR ENCLOSURE MAG ON/OFF Switch KEDU KJD17B Ground 220V Motor Run Capacitor 40uF 450VAC Start Capacitor 400uF 275VAC Electronic Start Switch ESS1-41 Ground 6-15 Plug READ ELECTRICAL SAFETY -24- Model T32717 (Mfd. Since 07/21) ON PAGE 23!
  • Page 27: Electrical Component Photos

    Electrical Component Photos Figure 22. ON/OFF switch. Figure 23. Run capacitor. Figure 24. Motor junction box and start capacitor. READ ELECTRICAL SAFETY -25- Model T32717 (Mfd. Since 07/21) ON PAGE 23!
  • Page 28: Section 9: Parts

    SECTION 9: PARTS We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability. Main 56 57 6-10 6-11 6-12 BUY PARTS ONLINE AT GRIZZLY.COM!
  • Page 29 POWER CORD 16G 3W 90" 6-15P PT32717026 BOTTOM PLATE PT32717066 FLAT WASHER 10MM PT32717027 SET SCREW M10-1.5 X 25 DOG-PT PT32717067 HEX NUT M10-1.5 BUY PARTS ONLINE AT GRIZZLY.COM! -27- Model T32717 (Mfd. Since 07/21) Scan QR code to visit our Parts Store.
  • Page 30: Labels & Cosmetics

    Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes off or becomes unreadable, the owner of this machine MUST replace it in the original location before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com. BUY PARTS ONLINE AT GRIZZLY.COM! -28- Model T32717 (Mfd.
  • Page 31: Warranty & Returns

    WARRANTY & RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
