GE
Grid Solutions
MiCOM P40 Agile
Px4x
Technical Manual
Redundant Ethernet Boards
Publication Reference: Px4x-REB-TM-EN-6

Advertisement

Table of Contents
loading

Related Manuals for GE MiCOM P40 Agile

Summary of Contents for GE MiCOM P40 Agile

  • Page 1 Grid Solutions MiCOM P40 Agile Px4x Technical Manual Redundant Ethernet Boards Publication Reference: Px4x-REB-TM-EN-6...

  • Page 3: Table Of Contents

    Contents Chapter 1 Introduction Chapter Overview Foreword Target Audience Typographical Conventions Nomenclature Product Scope Features and Functions Compliance Chapter 2 Safety Information Chapter Overview Health and Safety Symbols Installation, Commissioning and Servicing Lifting Hazards Electrical Hazards UL/CSA/CUL Requirements Fusing Requirements Equipment Connections Protection Class 1 Equipment Requirements Pre-energisation Checklist...
  • Page 4 Contents IP Address Configuration SNTP IP Address Configuration 3.10 Check MAC Table for Connected Equipment 3.11 PRP Configuration 3.12 HSR Configuration 3.13 RSTP Configuration 3.14 Bridge parameters 3.15 Port Parameters 3.16 Port States 3.17 Failover Configuration 3.18 Filtering Database 3.19 End of Session PRP/HSR Configurator Connecting the IED to a PC...
  • Page 5 Contents High-Availability Seamless Redundancy (HSR) 3.2.1 HSR Multicast Topology 3.2.2 HSR Unicast Topology 3.2.3 HSR Application in the Substation Rapid Spanning Tree Protocol (RSTP) Self-Healing Protocol (SHP) Dual-Homing Protocol (DHP) Failover General Functions for Redundant Ethernet Boards Forwarding Simple Network Management Protocol (SNMP) SNMP MIB Structure for RSTP, DHP and SHP SNMP MIB Structure for PRP and HSR Simple Network Time Protocol (SNTP)
  • Page 6 Contents Electrical Fast Transient or Burst Requirements Surge Withstand Capability Surge Immunity Test Immunity to Radiated Electromagnetic Energy Radiated Immunity from Digital Communications Radiated Immunity from Digital Radio Telephones 7.10 Immunity to Conducted Disturbances Induced by Radio Frequency Fields 7.11 Magnetic Field Immunity 7.12 Conducted Emissions...

  • Page 7: Chapter 1 Introduction

    CHAPTER 1 INTRODUCTION...
  • Page 8 Chapter 1 - Introduction Px4x-REB-TM-EN-6...

  • Page 9: Chapter Overview

    Chapter 1 - Introduction CHAPTER OVERVIEW This chapter provides some general information about the technical manual and an introduction to the device(s) described in this technical manual. This chapter contains the following sections: Chapter Overview Foreword Features and Functions Compliance Px4x-REB-TM-EN-6...

  • Page 10: Foreword

    The description of principles and theory is limited to that which is necessary to understand the product. For further details on general protection engineering theory, we refer you to GE's publication NPAG, which is available online or from our contact centre.

  • Page 11: Nomenclature

    GE provides a range of REBs for its IED products. A REB is usually fitted as an option before the IED is shipped, but can be ordered retrospectively if required.

  • Page 12: Features And Functions

    Based on open standards so is compatible with other Manufacturers’ IEDs that use the RSTP protocol. SHP (Self-Healing Protocol) Used on double-ring network topologies ● ● GE proprietary standard Responds to the constraints of critical time applications ● When a fibre is broken, both end stations detect and repair the break. ●...
  • Page 13 Chapter 1 - Introduction Failover Simple form of redundancy ● ● Can be used on any underlying topology One port is active at a time. The inactive port is functionally down. ● Slow switch over time. Can be up to a few seconds and depends on how long the backup port takes to ●...

  • Page 14: Compliance

    Chapter 1 - Introduction COMPLIANCE The device has undergone a range of extensive testing and certification processes to ensure and prove compatibility with all target markets. A detailed description of these criteria can be found in the Technical Specifications chapter. Px4x-REB-TM-EN-6...

  • Page 15: Chapter 2 Safety Information

    CHAPTER 2 SAFETY INFORMATION...
  • Page 16 Chapter 2 - Safety Information Px4x-REB-TM-EN-6...

  • Page 17: Chapter Overview

    Chapter 2 - Safety Information CHAPTER OVERVIEW This chapter provides information about the safe handling of the equipment. The equipment must be properly installed and handled in order to maintain it in a safe condition and to keep personnel safe at all times. You must be familiar with information contained in this chapter before unpacking, installing, commissioning, or servicing the equipment.

  • Page 18: Health And Safety

    Chapter 2 - Safety Information HEALTH AND SAFETY Personnel associated with the equipment must be familiar with the contents of this Safety Information. When electrical equipment is in operation, dangerous voltages are present in certain parts of the equipment. Improper use of the equipment and failure to observe warning notices will endanger personnel. Only qualified personnel may work on or operate the equipment.

  • Page 19: Symbols

    Chapter 2 - Safety Information SYMBOLS Throughout this manual you will come across the following symbols. You will also see these symbols on parts of the equipment. Caution: Refer to equipment documentation. Failure to do so could result in damage to the equipment Warning: Risk of electric shock...

  • Page 20: Installation, Commissioning And Servicing

    Chapter 2 - Safety Information INSTALLATION, COMMISSIONING AND SERVICING LIFTING HAZARDS Many injuries are caused by: Lifting heavy objects ● Lifting things incorrectly ● ● Pushing or pulling heavy objects Using the same muscles repetitively ● Plan carefully, identify any possible hazards and determine how best to move the product. Look at other ways of moving the load to avoid manual handling.

  • Page 21: Ul/Csa/Cul Requirements

    Chapter 2 - Safety Information Warning: NEVER look into optical fibres or optical output connections. Always use optical power meters to determine operation or signal level. Warning: Testing may leave capacitors charged to dangerous voltage levels. Discharge capacitors by reducing test voltages to zero before disconnecting test leads. Caution: Operate the equipment within the specified electrical and environmental limits.

  • Page 22: Equipment Connections

    Chapter 2 - Safety Information Caution: Digital input circuits should be protected by a high rupture capacity NIT or TIA fuse with maximum rating of 16 A. for safety reasons, current transformer circuits must never be fused. Other circuits should be appropriately fused to protect the wire used. Caution: CTs must NOT be fused since open circuiting them may produce lethal hazardous voltages...

  • Page 23: Pre-Energisation Checklist

    Chapter 2 - Safety Information Caution: Use a locknut or similar mechanism to ensure the integrity of stud-connected PCTs. Caution: The recommended minimum PCT wire size is 2.5 mm² for countries whose mains supply is 230 V (e.g. Europe) and 3.3 mm² for countries whose mains supply is 110 V (e.g. North America).
  • Page 24 Chapter 2 - Safety Information Note: For most GE equipment with ring-terminal connections, the threaded terminal block for current transformer termination is automatically shorted if the module is removed. Therefore external shorting of the CTs may not be required. Check the equipment documentation and wiring diagrams first to see if this applies.

  • Page 25: Upgrading/Servicing

    Chapter 2 - Safety Information UPGRADING/SERVICING Warning: Do not insert or withdraw modules, PCBs or expansion boards from the equipment while energised, as this may result in damage to the equipment. Hazardous live voltages would also be exposed, endangering personnel. Caution: Internal modules and assemblies can be heavy and may have sharp edges.

  • Page 26: Decommissioning And Disposal

    Chapter 2 - Safety Information DECOMMISSIONING AND DISPOSAL Caution: Before decommissioning, completely isolate the equipment power supplies (both poles of any dc supply). The auxiliary supply input may have capacitors in parallel, which may still be charged. To avoid electric shock, discharge the capacitors using the external terminals before decommissioning.

  • Page 27: Regulatory Compliance

    Chapter 2 - Safety Information REGULATORY COMPLIANCE Compliance with the European Commission Directive on EMC and LVD is demonstrated using a technical file. EMC COMPLIANCE: 2014/30/EU The product specific Declaration of Conformity (DoC) lists the relevant harmonised standard(s) or conformity assessment used to demonstrate compliance with the EMC directive.
  • Page 28 Chapter 2 - Safety Information Px4x-REB-TM-EN-6...

  • Page 29: Chapter 3 Hardware Design

    CHAPTER 3 HARDWARE DESIGN...
  • Page 30 Chapter 3 - Hardware Design Px4x-REB-TM-EN-6...

  • Page 31: Chapter Overview

    Chapter 3 - Hardware Design CHAPTER OVERVIEW This chapter provides information about the product's hardware design. This chapter contains the following sections: Chapter Overview Board Versions Board Connections Px4x-REB-TM-EN-6...

  • Page 32: Board Versions

    Chapter 3 - Hardware Design BOARD VERSIONS Each board combines Ethernet communications, with IRIG-B timing functionality. There is a choice of embedded protocols for the Ethernet communications, and two types of IRIG-B. Board variants Board Part No. Compatible With Proprietary Self-Healing Protocol Redundant Ethernet SHP, 2 multi-mode fibre ports + modulated IRIG-B ZN0071 001 C264-SWR212 and MiCOM H35x...

  • Page 33: Board Connections

    Chapter 3 - Hardware Design BOARD CONNECTIONS IRIG-B Link Fail Pin3 connector Pin 2 Pin 1 Link channel B Link channel A (green LED) (green LED) Activity channel Activity channel B A (yellow LED) (yellow LED) V01009 Figure 1: Board connectors IRIG-B Connector Available as a modulated or demodulated input.
  • Page 34 Chapter 3 - Hardware Design Px4x-REB-TM-EN-6...

  • Page 35: Chapter 4 Configuration

    CHAPTER 4 CONFIGURATION...
  • Page 36 Chapter 4 - Configuration Px4x-REB-TM-EN-6...

  • Page 37: Chapter Overview

    Chapter 4 - Configuration CHAPTER OVERVIEW Each product has different configuration parameters according to the functions it has been designed to perform. There is, however, a common methodology used across the entire product series to set these parameters. Some of the communications setup can only be carried out using the HMI, and cannot be carried out using settings applications software.

  • Page 38: Configuring Ip Addresses

    Chapter 4 - Configuration CONFIGURING IP ADDRESSES An IP address is a logical address assigned to devices in a computer network that uses the Internet Protocol (IP) for communication between nodes. IP addresses are stored as binary numbers but they are represented using Decimal Dot Notation, where four sets of decimal numbers are separated by dots as follows: XXX.XXX.XXX.XXX For example:...
  • Page 39 Chapter 4 - Configuration PRP/HSR/RSTP/Failover From S1 Agile 2.0.1. onwards cards that support the PRP/HSR/RSTP/Failover protocols in any of the combinations are configured using the Redundant Ethernet Configurator software tool. If you are using a ZN008700X card only this tool supports it. If using S1 Agile 1.4.2 or older you will need to use the PRP/HSR Configurator for PRP and/or HSR, and the RSTP Configurator for RSTP cards.

  • Page 40: Configuring The Last Octet (Shp, Dhp, Rstp)

    Chapter 4 - Configuration Board Part No. Compatible With Redundant Ethernet PRP/HSR/RSTP/Failover, 2 copper ports RJ45 + Redundant Ethernet Configurator ZN0087 002 Modulated/Un-Modulated IRIG-B (S1 Agile 2.0.1 onwards) Redundant Ethernet PRP/HSR/RSTP/Failover, 1 copper port RJ45 + 1 multi-mode Redundant Ethernet Configurator ZN0087 003 fibre port + Modulated/Un-Modulated IRIG-B (S1 Agile 2.0.1 onwards)
  • Page 41 Chapter 4 - Configuration Lift the upper and lower flaps. Remove the six screws securing the front panel and pull the front panel outwards. E01020 Px4x-REB-TM-EN-6...
  • Page 42 Chapter 4 - Configuration Press the levers either side of the connector to disconnect the ribbon cable from the front panel. E01021 Remove the redundant Ethernet board. Set the last octet of IP address using the DIP switches. The available range is 1 to 127.

  • Page 43: Redundant Ethernet Configurator

    Chapter 4 - Configuration REDUNDANT ETHERNET CONFIGURATOR The Redundant Ethernet Configurator tool is intended for MiCOM Px4x IEDs with redundant Ethernet using PRP (Parallel Redundancy Protocol), HSR (High-availability Seamless Redundancy), RSTP (Rapid Spanning Tree Protocol) or Failover. This tool is used to identify IEDs, switch between PRP, HSR, RSTP and Failover, configure their parameters, configure the redundancy IP address, or configure the SNTP IP address.

  • Page 44: Starting The Configurator

    Chapter 4 - Configuration STARTING THE CONFIGURATOR To start the configurator: Go to S1 Agile and select the Ethernet Configuration tile, then select the Redundant Ethernet Configurator tile. The Login screen appears. For user mode login, enter the Login name as User and click OK with no password.

  • Page 45: Sntp Ip Address Configuration

    Chapter 4 - Configuration SNTP IP ADDRESS CONFIGURATION If using SNMP to poll information from the REB an SNTP server can be used to synchronise the time of the reported messages. To configure the SNTP server IP address: From the main window click the SNTP Config button. The Device setup screen appears. Enter the required MAC SNTP address and server IP SNTP Address.

  • Page 46: Rstp Configuration

    Chapter 4 - Configuration Proxy Node Table Max Entries: This is the maximum number of entries in the ProxyTable ● Entry Forget Time: This is the time after which an entry is removed from the duplicates ● Node Reboot Interval: This is the minimum time during which a node that reboots remains silent ●...

  • Page 47: Port States

    Chapter 4 - Configuration 3.16 PORT STATES This is used to see which ports of the board are enabled or disabled. From the main window, click the device address to select the device. The RSTP Configuration window appears. Select the Port States tab then click the Get Port States button. This lists the ports of the Ethernet board. A tick shows they are enabled.

  • Page 48: End Of Session

    Chapter 4 - Configuration To delete an entry from the forwarding database, select the entry and click the Delete Entry button. Goose Filtering tab This page configures the source MACs from which GOOSE messages will be allowed or blocked. The filtering can be configured by either the MAC address range boxes or by selecting or unselecting the individual MAC addresses in the MAC table.

  • Page 49: Prp/Hsr Configurator

    Chapter 4 - Configuration PRP/HSR CONFIGURATOR The PRP/HSR Configurator tool is intended for MiCOM Px4x IEDs with redundant Ethernet using PRP (Parallel Redundancy Protocol), or HSR (High-availability Seamless Redundancy). This tool is used to identify IEDs, switch between PRP and HSR or configure their parameters, configure the redundancy IP address, or configure the SNTP IP address.

  • Page 50: Prp/Hsr Device Identification

    Chapter 4 - Configuration If the login screen does not appear, check all network connections. The main window appears. In the bottom right-hand corner of the main window, click the Language button to select the language. The Network Board drop-down list shows the Network Board, IP Address and MAC Address of the PC in which the Configurator is running PRP/HSR DEVICE IDENTIFICATION To configure the redundant Ethernet board, go to the main window and click the Identify Device button.

  • Page 51: Prp Configuration

    Chapter 4 - Configuration PRP CONFIGURATION To view or configure the PRP Parameters: Ensure that you have set the device mode to PRP. Click the PRP/HSR Configuration button. The PRP Configuration Parameters screen appears. To view the available parameters, click the Get PRP Parameters button. To change the parameters, click the Set Parameters button and modify their values.

  • Page 52: Rstp Configurator

    Chapter 4 - Configuration RSTP CONFIGURATOR The RSTP Configurator tool is intended for MiCOM Px4x IEDs with redundant Ethernet using RSTP (Rapid Spanning Tree Protocol). This tool is used to identify IEDs, configure the redundancy IP address, configure the SNTP IP address and configure the RSTP parameters.

  • Page 53: Rstp Device Identification

    Chapter 4 - Configuration If the login screen does not appear, check all network connections. The main window appears. In the bottom right-hand corner of the main window, click the Language button to select the language. The Network Board drop-down list shows the Network Board, IP Address and MAC Address of the PC in which the Configurator is running RSTP DEVICE IDENTIFICATION To configure the redundant Ethernet board, go to the main window and click Identify Device.

  • Page 54: Rstp Configuration

    Chapter 4 - Configuration RSTP CONFIGURATION To view or configure the RSTP Bridge Parameters, from the main window, click the device address to select the device. The selected device MAC address appears highlighted. Click the RSTP Configuration button. The RSTP Configuration screen appears. To view the available parameters in the board that is connected, click the Get RSTP Parameters button.

  • Page 55: End Of Session

    Chapter 4 - Configuration END OF SESSION To finish the session: In the main window, click the Quit button, a new screen appears. If a database backup is required, click Yes, a new screen appears. Click the ... button to browse the path. Enter the name in the text box. Px4x-REB-TM-EN-6...

  • Page 56: Switch Manager

    The Switch Manager tool is also intended for MiCOM Px4x IEDs with redundant Ethernet using Self Healing Protocol (SHP) and Dual Homing Protocol (DHP). This tool is used to identify IEDs and GE Switches, and to configure the redundancy IP address for the GE proprietary Self Healing Protocol and Dual Homing Protocol.

  • Page 57: Setup

    Chapter 4 - Configuration Switch Manager is used to define IP addresses of GE switches. These addresses must be in the range of the system IP, depending on the IP mask of the engineering PC for substation maintenance. GE switches have a default multicast so the 3rd word of the IP address is always 254.

  • Page 58: Check For Connected Equipment

    Chapter 4 - Configuration CHECK FOR CONNECTED EQUIPMENT To check what devices are connected to the device being monitored: From the main window, select the device. Click the Equipment button. At the bottom of the main window, a box shows the ports where devices are connected and their MAC addresses.

  • Page 59: End Of Session

    Chapter 4 - Configuration 6.10 END OF SESSION To finish the session: In the main window, click the Quit button, a new screen appears. If a database backup is required, click Yes, a new screen appears. Click the ... button to browse the path. Enter the name in the text box. Px4x-REB-TM-EN-6...
  • Page 60 Chapter 4 - Configuration Px4x-REB-TM-EN-6...

  • Page 61: Chapter 5 Operation

    CHAPTER 5 OPERATION...
  • Page 62 Chapter 5 - Operation Px4x-REB-TM-EN-6...

  • Page 63: Chapter Overview

    Chapter 5 - Operation CHAPTER OVERVIEW This chapter provides details of how the product functions. This chapter contains the following sections: Chapter Overview Redundant Ethernet Communication Redundancy Protocols General Functions for Redundant Ethernet Boards Px4x-REB-TM-EN-6...

  • Page 64: Redundant Ethernet Communication

    Chapter 5 - Operation REDUNDANT ETHERNET COMMUNICATION Redundancy is transparent backup. It is required where a single point of failure cannot be tolerated, and required in critical applications such as substation automation. Redundancy acts as an insurance policy, providing an alternative route if one route fails.

  • Page 65: Redundancy Protocols

    PRP provides "bumpless" redundancy. RSTP is also an open standard, so its implementation is compatible with any standard RSTP devices. RSTP provides redundancy, however, it is not "bumpless". SHP and DHP are proprietary protocols intended for use with specific GE products: SHP is compatible with the C264-SWR212 as well as H35x multimode switches.

  • Page 66: Network Elements

    There are two ways of handling this: Duplicate Accept and Duplicate Discard. The GE RedBox is the H382 switch. This is compatible with any other vendor's PRP device. HIGH-AVAILABILITY SEAMLESS REDUNDANCY (HSR) HSR is standardized in IEC 62439-3 (clause 5) for use in ring topology networks.

  • Page 67: Hsr Multicast Topology

    Chapter 5 - Operation 3.2.1 HSR MULTICAST TOPOLOGY When a DANH is sending a multicast frame, the frame (C frame) is duplicated (A frame and B frame), and each duplicate frame A/B is tagged with the destination MAC address and the sequence number. The frames A and B differ only in their sequence number, which is used to identify one frame from the other.

  • Page 68: Hsr Application In The Substation

    Chapter 5 - Operation Source DANH DANH Redbox Switch C frame A frame B frame Singly Attached Nodes D frame DANH DANH DANH Destination V01031 Figure 8: HSR unicast topology For unicast frames, the whole bandwidth is available as both frames A & B stop at the destination node. 3.2.3 HSR APPLICATION IN THE SUBSTATION Px4x-REB-TM-EN-6...

  • Page 69: Rapid Spanning Tree Protocol (Rstp)

    Chapter 5 - Operation T1000 switch PC SCADA LINK reset LINK DS Agile gateways Px4x Px4x Px4x Px4x Px4x Px4x Px4x Px4x Bay 1 Bay 2 Bay 3 E01066 Figure 9: HSR application in the substation RAPID SPANNING TREE PROTOCOL (RSTP) RSTP is a standard used to quickly reconnect a network fault by finding an alternative path, allowing loop-free network topology.

  • Page 70: Self-Healing Protocol (Shp)

    SELF-HEALING PROTOCOL (SHP) Unlike RSTP, the GE SHP solution responds to the constraints of critical time applications such as the GOOSE messaging of IEC 61850. SHP in MiCOM Px4x is fully compatible with SHP used in the MiCOM C264 and MiCOM H series of switches that are components of the PACiS Substation Automation System.
  • Page 71 Chapter 5 - Operation Px4x IED bus Embedded Flash Managed Switch Memory Port MII Failsafe Self Healing Address Output Manager (SHM) Switch Relays 100 base FX Ethernet Primary Ring Primary Ring Rx primary (Rp) Tx primary (Ep) Tx secondary (Es) Rx secondary (Rs) Secondary Ring Secondary Ring...

  • Page 72: Dual-Homing Protocol (Dhp)

    If one link is down, the frame is sent through the link, received by the device, and passed to upper layers for processing. GE’s DHM fulfils automation requirements by delivering a very fast recovery time for the entire network (less than 1 ms).
  • Page 73 Chapter 5 - Operation Network 1 Network 2 Optical star Optical star H63x H63x Dual homing Dual homing Dual homing SWD21x SWD21x SWD21x Modified frames from network 1 Modified frames from network 2 No modified frames V01073 Figure 15: Dual homing mechanism The H36x is a repeater with a standard 802.3 Ethernet switch, plus the DHM.

  • Page 74: Failover

    Chapter 5 - Operation MiCOM H382 SCADA or PACiS OI DS Agile gateways H600 switch H600 switch Ethernet Up to 6 links C264 * Px4x ** C264 H368 Ethernet Up to 4 links RS485 Bay level Bay level Bay level Type 1 Type 2 Type 3...

  • Page 75: General Functions For Redundant Ethernet Boards

    Chapter 5 - Operation GENERAL FUNCTIONS FOR REDUNDANT ETHERNET BOARDS The following functions apply to all redundant Ethernet protocols. FORWARDING The MiCOM Ethernet switch products support store and forward mode. The switch forwards messages with known addresses to the appropriate port. The messages with unknown addresses, the broadcast messages and the multicast messages are forwarded out to all ports except the source port.

  • Page 76: Snmp Mib Structure For Rstp, Dhp And Shp

    The private branch of the MIB tree contains branches for large organizations, organized under the enterprises branch. This is not applicable to GE. SNMP MIB STRUCTURE FOR RSTP, DHP AND SHP...

  • Page 77: Snmp Mib Structure For Prp And Hsr

    Chapter 5 - Operation Address Name Internet mgmt Mib-2 sysDescr sysUpTime sysName Remote Monitoring RMON statistics etherstat etherStatsEntry etherStatsUndersizePkts etherStatsOversizePkts etherStatsJabbers etherStatsCollisions etherStatsPkts64Octets etherStatsPkts65to127Octets etherStatsPkts128to255Octets etherStatsPkts256to511Octets etherStatsPkts512to1023Octets Various SNMP client software tools can be used. We recommend using an SNMP MIB browser, which can perform the basic SNMP operations such as GET, GETNEXT and RESPONSE.
  • Page 78 Chapter 5 - Operation Address Name lreConfigurationInterfaces lreInterfaceConfigTable lreInterfaceConfigEntry lreInterfaceConfigIndex lreRowStatus lreNodeType lreNodeName lreVersionName lreMacAddressA lreMacAddressB lreAdapterAdminStateA lreAdapterAdminStateB lreLinkStatusA lreLinkStatusB lreDuplicateDiscard lreTransparentReception lreHsrLREMode lreSwitchingEndNode lreRedBoxIdentity lreSanA lreSanB lreEvaluateSupervision lreNodesTableClear lreProxyNodeTableClear lreStatistics lreStatisticsInterfaceGroup lreStatisticsInterfaces lreInterfaceStatsTable lreInterfaceStatsIndex lreCntTotalSentA lreCntTotalSentB lreCntErrWrongLANA lreCntErrWrongLANB lreCntReceivedA lreCntReceivedB lreCntErrorsA lreCntErrorsB...
  • Page 79 Chapter 5 - Operation Address Name reProxyNodeMacAddress Internet mgmt mib-2 System sysDescr sysUpTime sysName sysServices interfaces ifTable ifEntry ifIndex ifDescr ifType ifMtu ifSpeed ifPhysAddress ifAdminStatus ifOpenStatus ifLastChange ifInOctets ifInUcastPkts ifInNUcastPkts ifInDiscards ifInErrors ifInUnknownProtos ifOutOctets ifOutUcastPkts ifOutNUcastPkts ifOutDiscards ifOutErrors ifOutQLen ifSpecific rmon statistics etherStatsTable...

  • Page 80: Simple Network Time Protocol (Sntp)

    Various SNMP client software tools can be used. GE recommends using an SNMP MIB browser, which can perform the basic SNMP operations such as GET, GETNEXT and RESPONSE. Note: When communicating with the Redundant Ethernet Card, there are two IP addresses visible: one for the IED and one for the Ethernet switch on the redundant Ethernet board.

  • Page 81: Chapter 6 Commissioning Instructions

    CHAPTER 6 COMMISSIONING INSTRUCTIONS...
  • Page 82 Chapter 6 - Commissioning Instructions Px4x-REB-TM-EN-6...

  • Page 83: Chapter Overview

    Chapter 6 - Commissioning Instructions CHAPTER OVERVIEW This chapter contains the following sections: Chapter Overview Visual Inspection Test Ethernet Communication SHP Ring Connection PRP Star Connection PRP Star Connection DHP Star Connection RSTP Ring Connection RSTP Star Connection Large RSTP Networks Combining Star and Ring Px4x-REB-TM-EN-6...

  • Page 84: Visual Inspection

    Chapter 6 - Commissioning Instructions VISUAL INSPECTION Warning: Check the rating information under the top access cover on the front of the IED. Warning: Check that the IED being tested is correct for the line or circuit. Warning: Record the circuit reference and system details. Warning: Check the CT secondary current rating and record the CT tap which is in use.

  • Page 85: Test Ethernet Communication

    Chapter 6 - Commissioning Instructions TEST ETHERNET COMMUNICATION For products that employ Ethernet communications, we recommend that testing be limited to a visual check that the correct ports are fitted and that there is no sign of physical damage. If there is no board fitted or the board is faulty, a NIC link alarm will be raised (providing this option has been set in the NIC Link Report cell in the COMMUNICATIONS column).

  • Page 86: Shp Ring Connection

    Chapter 6 - Commissioning Instructions SHP RING CONNECTION Connect Es to Rs and Ep to Rp on each device until it makes a ring. MiCOM H35 or IED MiCOM H35 or IED MiCOM H35 or IED Rp Es Rs Ep Rp Es Rs Ep Rp Es Rs Ep V01023...

  • Page 87: Prp Star Connection

    Chapter 6 - Commissioning Instructions PRP STAR CONNECTION Connect TX to RX and RX to TX on each device. When connecting to a C264-SRP20X PRP card or an H368 RedBox, an LC Fibre connector patch filter is needed. Link A Link B Link A Link B...

  • Page 88: Prp Star Connection

    Chapter 6 - Commissioning Instructions PRP STAR CONNECTION Connect TX to RX and RX to TX on each device. When connecting to other devices such as a RedBox, LC Fibre connector patch filters may be needed. DAN IED DAN IED Redbox Switch Link A...

  • Page 89: Dhp Star Connection

    Chapter 6 - Commissioning Instructions DHP STAR CONNECTION Connect TX to RX and RX to TX on each device. Link A Link B Link A Link B Optical switch B Optical switch A V01046 Figure 21: DHP star connections Px4x-REB-TM-EN-6...

  • Page 90: Rstp Ring Connection

    Chapter 6 - Commissioning Instructions RSTP RING CONNECTION The following diagram shows the Px4x IEDs (Px4x – IED 1 to IED N) using RSTP redundant Ethernet boards connected in a ring topology. This topology can have one or more RSTP-enabled Ethernet switches to interface with another network or control centre.

  • Page 91: Rstp Star Connection

    Chapter 6 - Commissioning Instructions RSTP STAR CONNECTION The following diagram shows the Px4x IEDs (Px4x – IED 1 to IED N) using RSTP redundant Ethernet boards connected in a star topology. This topology can have one or more RSTP-enabled Ethernet switches to interface with other networks, control centers, or Px4x IEDs.

  • Page 92: Large Rstp Networks Combining Star And Ring

    Chapter 6 - Commissioning Instructions LARGE RSTP NETWORKS COMBINING STAR AND RING The following diagram shows a star of four rings. Each ring is connected to the root bridge. The root bridge is a high-end RSTP-enabled bridge with the maximum number of ports as required. The devices A1, A2…Anmax, B1, B2…Bnmax, C1, C2…Cnmax, D1, D2…Dnmax, represent the RSTP redundant Ethernet boards.
  • Page 93 Chapter 6 - Commissioning Instructions Cnmax -2 Dnmax -2 Cnmax -1 Dnmax -1 Dnmax Cnmax Root Bridge Anmax Bnmax Anmax -1 Bnmax -1 Anmax -2 Bnmax -2 V01027 Figure 24: Combined RSTP star and ring topology Px4x-REB-TM-EN-6...
  • Page 94 Chapter 6 - Commissioning Instructions Px4x-REB-TM-EN-6...

  • Page 95: Chapter 7 Technical Specifications

    CHAPTER 7 TECHNICAL SPECIFICATIONS...
  • Page 96 Chapter 7 - Technical Specifications Px4x-REB-TM-EN-6...

  • Page 97: Chapter Overview

    Chapter 7 - Technical Specifications CHAPTER OVERVIEW This chapter describes the technical specifications of the product. This chapter contains the following sections: Chapter Overview Interfaces Mechanical Specifications Standards Compliance Environmental Conditions Type Tests Electromagnetic Compatibility Px4x-REB-TM-EN-6...

  • Page 98: Interfaces

    Chapter 7 - Technical Specifications INTERFACES IRIG-B (MODULATED) IRIG-B Interface (Modulated) External clock synchronisation signal Standard IRIG 200-98 format B12X Connector Cable type 50 ohm coaxial Isolation Isolation to SELV level Input signal peak to peak, 200 mV to 20 mV Input impedance 6 k ohm at 1000 Hz Accuracy...

  • Page 99: Fibre Defect Connector (Watchdog Relay)

    Chapter 7 - Technical Specifications Parameter Min. Typ. Max. Unit Input Optical Power Maximum PIN Max. -11.8 dBm avg. Conditions: TA = 0°C to 70°C FIBRE DEFECT CONNECTOR (WATCHDOG RELAY) Connector (3 Terminals) 2 NC Contacts Potential Free Rated voltage 250 VAC Rated continuous current Make current...

  • Page 100: Mechanical Specifications

    Chapter 7 - Technical Specifications MECHANICAL SPECIFICATIONS MECHANICAL ROBUSTNESS Vibration test per EN 60255-21-1:1998 Response: class 2, Endurance: class 2 Shock response: class 2, Shock withstand: class 1, Bump withstand: Shock and bump immunity per EN 60255-21-2:1988 class 1 Seismic test per EN 60255-21-3: 1993 Class 2 Px4x-REB-TM-EN-6...

  • Page 101: Standards Compliance

    Chapter 7 - Technical Specifications STANDARDS COMPLIANCE Compliance with the European Commission Directive on EMC and LVD is demonstrated by self certification against international standards. EMC COMPLIANCE: 2004/108/EC Compliance with EN60255-26:2009 was used to establish conformity. PRODUCT SAFETY: 2006/95/EC Compliance with EN60255-27:2005 was used to establish conformity. Protective Class IEC 60255-27: 2005 Class 1 (unless otherwise specified in equipment documentation).

  • Page 102: Environmental Conditions

    Chapter 7 - Technical Specifications ENVIRONMENTAL CONDITIONS AMBIENT TEMPERATURE RANGE Compliance IEC 60255-27: 2013 Test Method IEC 60068-2-1:2007 and IEC 60068-2-2 2007 Operating temperature range -25°C to +55°C (continuous) Storage and transit temperature range -25°C to +70°C (continuous) AMBIENT HUMIDITY RANGE Compliance IEC 60068-2-78: 2013 and IEC 60068-2-30: 2005 Durability...

  • Page 103: Type Tests

    Chapter 7 - Technical Specifications TYPE TESTS INSULATION Compliance IEC 60255-27: 2013 Insulation resistance > 100 M ohm at 500 V DC (Using only electronic/brushless insulation tester) CREEPAGE DISTANCES AND CLEARANCES Compliance IEC 60255-27: 2013 Pollution degree Overvoltage category Impulse test voltage (not RJ45) 5 kV Impulse test voltage (RJ45) 1 kV...

  • Page 104: Electromagnetic Compatibility

    Chapter 7 - Technical Specifications ELECTROMAGNETIC COMPATIBILITY 1 MHZ BURST HIGH FREQUENCY DISTURBANCE TEST Compliance IEC 60255-22-1: 2008, Class III, IEC 60255-26:2013 Common-mode test voltage (level 3) 2.5 kV Differential test voltage (level 3) 1.0 kV DAMPED OSCILLATORY TEST EN61000-4-18: 2011: Level 3, 100 kHz and 1 MHz. Level 4: 3 MHz, Compliance 10 MHz and 30 MHz, IEC 60255-26:2013 Common-mode test voltage (level 3)
  • Page 105 Chapter 7 - Technical Specifications SURGE IMMUNITY TEST Compliance IEC 60255-26:2013, IEC 61000-4-5:2014+AMD1:2017 Pulse duration Time to half-value: 1.2/50 µs Between all groups and protective earth conductor terminal Amplitude 4 kV Between terminals of each group (excluding communications ports, Amplitude 2 kV where applicable) IMMUNITY TO RADIATED ELECTROMAGNETIC ENERGY Compliance...
  • Page 106 Chapter 7 - Technical Specifications Test disturbance voltage 10 V rms Test using AM 1 kHz @ 80% Spot tests 27 MHz and 68 MHz 7.11 MAGNETIC FIELD IMMUNITY IEC 61000-4-8:2009 Level 5 Compliance IEC 61000-4-9:2016 Level 5 IEC 61000-4-10:2016 Level 5 IEC 61000-4-8 test 100 A/m applied continuously, 1000 A/m applied for 3 s IEC 61000-4-9 test...
  • Page 108 Stafford, ST16 1WT, UK +44 (0) 1785 250 070 contact.centre@ge.com © 2022 General Electric. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances.
