T
ECHNICAL INFORMATION
Model No.
Description
C
ONCEPT AND MAIN APPLICATIONS
Model DFL083F series are LXT 14.4V Cordless Angle Screwdriver,
developed on DFL651F and designed to meet homologation
requirements of VDI/VDE2647.
Their main features and benefits are:
•
High torque accuracy in accordance with VDI/VDE2647
• Programmable speed control via USB connection
• Poka-yoke device can be externally attached.
• Maintenance alarm:LED indicator indicates when to carry out maintenance
S
pecifications
Specifications
Voltage: V
Capacity: Ah
Energy capacity: Wh
Battery
Cell
Charging time
(approx): min
Max output: W
No load speed: min -ı = rpm
Torque range:
N·m (in·lbs)
Torque shut-off
Programmable speed control
Program entry
Number of steps
Forward/reverse setting
LED job light
Buzzer
Soft start
LED indicator light color
OK/NOK judgment
of each tightening
Auto battery shut-off system
Battery capacity warning
Maintenance alarm
Poka-yoke (mistake-proofing)
Driving shank
Weight according to
EPTA-Procedure 01/2014: kg (lbs)
S
tandard equipment
Torque adjust tool (Country-
specific)
Protector (Country-specific)
USB cable
Note:
The standard equipment
may vary by country or
model variation.
DFL083F/ DFL125F/ DFL204F/ DFL302F/ DFL403F
Cordless Angle Screwdriver
Model
Hard joint
Soft joint
BL1415N:
With
BL1460A:
With
O
ptional accessories
Spindle C complete
(6.35mm C form bit)
Spindle F complete
(6.35 square drive)
Spindle H complete
(9.5 square drive)
Protectors (red, blue, yellow, transparent)
Anti-kickback head set, Hook (Hanging loop),
HH
Length (L)
Width (W)
Height (H)
Head height (HH)
Center height (CH)
*1 For DFL083F/ DFL125F/ DFL204F
*2 For DFL302F/ DFL403F
DFL083F/ DFL125F/ DFL204F/ DFL302F/ DFL403F
14.4
1.5, 3.0, 4.0, 5.0, 6.0
22, 44, 58, 72, 87
Li-ion
15, 22, 36, 45, 55
with DC18RC
390
150 - 700/ 100 - 700/ 100 - 440/ 70 - 230/ 50 - 220
2 - 8 (18 - 71)/ 5 - 12 (44 - 106)/ 8 - 20 (71 - 177)/
16 -30 (142 -266)/ 25 -40 (221 - 354)
Mechanical clutch
USB connection
Yes
6
Availablein at every one of 6 steps
Yes
Yes
Yes
3 colors (green, red, yellow)
Yes
(solid green/solid red)
Yes
Yes (blinking red)
Yes (blinking yellow)
Yes (externally attachable)
9.5mm (3/8") Square
1.7 - 1.9 (3.8 - 4.2) 2.0 - 2.1 (4.3 - 4.6)
*
1,
1.9 - 2.1 (4.3 - 4.7) 2.2 - 2.3 (4.9 - 5.1)
*
1,
Battery BL1415N/NA/NAP
Battery BL1430/A/AP/B
Battery BL1440
Battery BL1450
Battery BL1460A/AP/B
Torque adjust tool
1 / 6
CONFIDENTIAL
January 2018
L
W
CH
Dimensions: mm (")
BL1415N 464 (18-1/4)*1, 503 (19-3/4)*2
BL1430B 481 (19)*1, 520 (20-1/2)*2
74 (2-15/16)
98 (3-7/8)
31.5 (1-1/4)*1,
16 (5/8)*1, 18.5 (3/4)*2
*3
*
2
*
2
Fast charger DC18RC/ DC18RE
Charger DC18SD/DC24SC
Automotive charger DC18SE
Four port multi charger DC18SF
Two port multi fast charger DC18RD
(For torque adjustment)
H
35 (1-3/8)*2
