Removing a Gateway from a DIN Rail

Figure 17: Attaching a Gateway to a DIN Rail (IG21R Shown)
1. Position the gateway so that the lower edge and spring of the DIN rail bracket engages with the bottom
section of the DIN rail, then push up on the gateway so that DIN rail bracket spring compresses against
the DIN rail
2. Rotate the gateway so that the top hook of the bracket clamps to the top section of DIN rail.
Removing a Gateway from a DIN Rail
To remove a gateway from a DIN rail, see
on page 25
Cisco IG21 IoT Gateways, Cisco IG21R Rugged IoT Gateways, and Cisco IG31R Rugged IoT Gateways Hardware Installation Guide
24
and perform the steps that follow.
Figure 18: Removing a Gateway from a DIN Rail (IG21R Shown),
