- Page 1 36" SLIP ROLL 22 GAUGE OWNER'S MANUAL Copyright © May, 2008 By grizzly industrial, inC. WARNING: NO PORtION Of thIS MANUAL MAy bE REPRODUcED IN ANy ShAPE OR fORM WIthOUt thE WRIttEN APPROvAL Of GRIzzLy INDUStRIAL, INc. #JB10753 printed in China...
-
Page 3: Table Of Contents
INtRODUctION ... 2 Foreword ... 2 Contact info ... 2 Functional overview ... 2 identification ... 3 Machine data sheet ... 4 SEctION 1: SAfEty ... 5 safety instructions for Machinery ... 5 additional safety for slip rolls ... 7 SEctION 2: SEtUP ... -
Page 4: Introduction
INtRODUctION foreword We are proud to offer the Model g5770 36" slip roll. this machine is part of a growing grizzly family of fine metalworking machinery. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of grizzly’s com-... -
Page 5: Identification
Identification List (figures 1 and 2) A. gear assembly Cover b. top roller c. rear roller D. top roller release lever E. Crank radius adjustment Knob G. thickness adjustment Knob h. Bottom roller top roller lift lever Sample Illustration (figure 2) throughout this manual, diagrams are used to illustrate how the components of the machine are used during the various steps of operation. -
Page 6: Machine Data Sheet
Machine Data Sheet Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G5770 36" SLIP ROLL Design Type ...Bench Model Overall Dimensions: Height (with Handle in Center Position) ...13 Overall Depth...17'' Overall Length ...49''... -
Page 7: Section 1: Safety
Safety Instructions for Machinery g5770 36" slip roll 22 gauge... - Page 8 g5770 36" slip roll 22 gauge...
-
Page 9: Additional Safety For Slip Rolls
Additional Safety for Slip Rolls MEtAL EDGES. always de-burr sharp metal edges before inserting them into the slip roll. sharp edges on sheet metal can cause severe cuts. hAND PROtEctION. always wear leather gloves when using this tool. PINchING hAzARD. Keep fingers out of roller path during operation. -
Page 10: Section 2: Setup
SEctION 2: SEtUP Setup Safety this machine presents serious injury hazards to untrained users. Read through this entire manu- al to become familiar with the controls and opera- tions before starting the machine! Wear safety glasses dur- ing the entire setup pro- cess! this machine and its com- ponents are very heavy. -
Page 11: Inventory
Inventory the following is a description of the main compo- nents shipped with your machine. lay the compo- nents out to inventory them. Note: If you can't find an item on this list, check the mounting location on the machine or examine the packaging materials carefully. -
Page 12: Hardware Recognition Chart
hardware Recognition chart -10- g5770 36" slip roll 22 gauge... -
Page 13: Clean Up
G2544—Solvent cleaner & Degreaser a great product for removing the waxy shipping grease from your machine during clean up. figure 4. Cleaner/degreaser available from grizzly. g5770 36" slip roll 22 gauge Site considerations floor Load refer to the Machine Data Sheet for the weight and footprint specifications of your machine. -
Page 14: Assembly
Assembly the Model g5770 comes from the factory almost fully assembled. all that is required to assemble are the crank and handle. to assemble your machine: thread the crank handle into the small end of the crank and tighten, as shown in figure 6. Crank handle Crank figure 6. -
Page 15: Section 3: Operations
OMMEND that you read books, trade maga- zines, or get formal training before begin- ning any projects. Regardless of the con- tent in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training. g5770 36" slip roll 22 gauge... -
Page 16: Preparation
Preparation Before every use, follow these procedures to set up your slip roll for safe, accurate, and efficient use. to prepare the slip roll for use: turn the thickness adjust knob to lower the bottom roller to approximately top roller. use calipers or a spacer to set the distance between the rollers evenly at each end (figure 11). -
Page 17: Creating Bends
remove the workpiece from between the rollers, then raise the bottom roller slightly by rotating each thickness adjust knob approxi- mately ⁄ turn. also, make sure the rear roller is lowered completely and will not interfere with the workpiece as it exits the machine (figure 14). - Page 18 turn the crank clockwise to feed the workpiece until its front edge is directly above the rear roller, as shown in figure 17. figure 17. Feeding the workpiece. turn the radius adjust knobs to lift the rear roller until the desired radius bend is reached (figure 18).
-
Page 19: Creating Cylinders
creating cylinders the Model g5770 slip roll can be used to easily and accurately create cylinders. if you know the diameter of the cylinder you want to create, use the formula below to calculate the length of material needed. c=πD C=Circumference (length of Material needed) π=pi (approximately 3.142) - Page 20 turn the crank clockwise to feed the workpiece until it is approximately half way through the rollers. turn the radius adjust knobs to lift the rear roller until the desired radius bend is reached (figure 22). Make sure to turn the knobs equal amounts so the rear roller is always parallel with the other rollers.
-
Page 21: Bending Wire
Continue to process the workpiece until the cylinder is formed, as shown in figure 26. —if the ends of the cylinder do not meet, lift the rear roller equally at both ends, then process the entire cylinder through the slip roll again. -
Page 22: Removing Workpiece
Removing Workpiece to remove cylindrical workpieces: loosen the jam nut and hex bolt until the top roller release lever can be lifted (figure 28). top roller release lever Jam nut hex Bolt figure 28. Hex bolt and jam nut. lift the top roller release lever, then open the upper bushing assembly (figure 29). -
Page 23: Section 4: Accessories
aCCessories SEctION 4: AccESSORIES G5618—Deburring tool with two blades the quickest tool for smoothing freshly sheared metal edges. Comes with two blades, one for steel and aluminum and one for brass and cast iron. figure 32. Model g5618 deburring tool. G2871—boeshield t-9 12 oz Spray ®... - Page 24 G4956—Super Nibbler the super nibbler is just the ticket for cutting sheet metal up to ⁄ " thick. extremely narrow headed design allows cuts in hard-to-reach areas, yet still features a safety guard to prevent flying splinters. ⁄ " overall. figure 36.
-
Page 25: Section 5: Maintenance
SEctION 5: MAINtENANcE Schedule For optimum performance from your machine, follow this maintenance schedule and refer to any specific instructions given in this section. Daily check: • loose mounting bolts. • any other unsafe condition. Weekly Maintenance: • Clean machine. •... -
Page 26: Section 6: Service
SEctION 6: SERvIcE review the troubleshooting and procedures in this section to fix or adjust your machine if a problem devel- ops. if you need replacement parts or you are unsure of your repair skills, then feel free to call our technical support at (570) 546-9663. -
Page 27: Parts Breakdown
Parts breakdown -25- g5770 36" slip roll 22 gauge... -
Page 28: Parts List
REF PART # DESCRIPTION P5770001 LEFT FRAME P5770002 RIGHT FRAME P5770003 BASE P5770004 ROLLER BASE P5770005 TOP ROLLER P5770006 BOTTOM ROLLER P5770007 LOCK KNOB P5770008 COVER P5770009 CLEVIS PIN 10 X 50 P5770010 CRANK HANDLE P5770011 RADIUS ADJUST SCREW P5770012 SPECIAL SCREW P5770013 DRAW BAR... -
Page 31: Warranty And Returns
