- Page 1 INSTRUCTION MANUAL Rotary Hammer HR3530 DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model HR3530 Capacities Concrete 35 mm Core bit 105 mm No load speed (min Blows per minute 3,100 Overall length 374 mm Net weight 5.8 kg Safety class • Due to our continuing programme of research and development, the specifications herein are subject to change without notice. - Page 3 Use personal protective equipment. Always Service wear eye protection. Protective equipment such Have your power tool serviced by a qualified as a dust mask, non-skid safety shoes, hard hat or repair person using only identical replacement hearing protection used for appropriate conditions parts.
-
Page 4: Functional Description
For maximum control and safer operation, always use FUNCTIONAL the side grip with this tool. The side grip can be locked at four positions, horizontally and perpendicularly when DESCRIPTION the protrusion on the side grip base fits in the notch in the barrel(tool). -
Page 5: Operation
After drilling the hole, use the blow-out bulb to clean the NOTE: dust out of the hole. • The depth gauge cannot be used at the position where the depth gauge strikes against the gear housing. Chipping/Scaling/Demolition OPERATION CAUTION: Always use the side grip (auxiliary handle) and firmly hold the tool by both side grip and switch handle during operations. -
Page 6: Optional Accessories
CAUTION: • These accessories or attachments are recom- mended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 8 Makita Corporation 884739A1 20160913 www.makita.com...
