Samsung SP-LSP9TGA E-Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E-MANUAL
Thank you for purchasing this Samsung product.
To receive more complete service, please register your
product at
www.samsung.com
Model
Serial No.
To directly go to the page that provides instructions on
how to use the manual for visually impaired users, select
the Menu Learning Screen link below.
"Menu Learning Screen" Link

Advertisement

Table of Contents
loading

Related Manuals for Samsung SP-LSP9TGA

Summary of Contents for Samsung SP-LSP9TGA

  • Page 1 E-MANUAL Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com Model Serial No. To directly go to the page that provides instructions on how to use the manual for visually impaired users, select the Menu Learning Screen link below.

  • Page 2: Table Of Contents

    Connection Notes System and Support Peripherals 86 Using the Time Functions and the Timers 24 Controlling External Devices with a Samsung Remote 88 Using the Auto Protection Time and Energy Saving Control - Using the Universal Remote Functions Using Anynet+ (HDMI-CEC)
  • Page 3 Troubleshooting 114 Read Before Connecting a Computer (Supported Resolutions) Picture Issues 117 Supported Resolutions for Video Signals 122 Testing the picture 119 Read Before Using Bluetooth Devices 120 Suffix : Parental Rating - Thailand only Sound and Noise Issues 121 Licences 126 Testing the sound Channel and Broadcast Issues External Device Connectivity Issues...
  • Page 4 Accessibility Guidance Menu Learning Screen 141 Using the accessibility menu 145 Using the Projector with Voice Guide on 147 Using the guide 149 Using Schedule Viewing 150 Using the Channel List 152 Using Smart Hub 155 Launching the e-Manual 156 Using Bixby...

  • Page 5: Projector Screen Adjustment

    Guide Learn how to use various features. Projector Screen Adjustment Move the projector to adjust the size of the projected screen. Guide to screen adjustment When the screen looks skewed or blurry, adjust the screen. Move the projector to the left or right to adjust its angle. Or use the angle adjuster to make the screen rectangular.
  • Page 6 Move the projector back and forth to adjust the screen size. When the screen looks skewed or distorted, use the, Screen Adjustment Settings General Projector Settings Screen Adjustment) function. Try Now When the screen looks blurry, use the Focus Settings General Projector Settings Focus) function.

  • Page 7: Connections

    Connections You can watch live broadcasts by connecting an antenna cable to your Projector and can get access to the Internet by using a LAN cable or wireless access point. Using various connectors, you can also connect external devices. Connection Guide You can view detailed information about external devices that can be connected to the Projector.

  • Page 8: Connecting An Antenna (Aerial)

    Connecting an Antenna (Aerial) You can connect an antenna cable to your Projector. An antenna connection is not necessary if you connect a cable box or satellite box. Depending on the model or geographical area. - 8 -...

  • Page 9: Connecting To The Internet

    Connecting to the Internet You can get access to the Internet through your Projector. Settings General Network Open Network Settings Try Now Configure network settings to connect to an available network. Establishing a wired Internet connection Settings General Network Open Network Settings Wired If you connect a LAN cable, the Projector automatically accesses the Internet.
  • Page 10 Establishing a wireless Internet connection Settings General Network Open Network Settings Wireless Make sure that you have the wireless access point's SSID (name) and password settings before attempting to connect. The network name (SSID) and security key are available on the wireless access point's configuration screen.
  • Page 11 Turning this feature on may allow other IP control devices to control your Projector. We recommend turning this feature on only if an authorised third-party custom controller is installed and configured specifically for a Samsung Projector and if your Wi-Fi network is password protected.

  • Page 12: Screen Sharing (Smart View) With Your Mobile Device

    Screen Sharing (Smart View) with your Mobile Device You can watch the screen of your mobile device on the Projector screen through Smart View or Tap View. For information on how to share the screen with your mobile device, refer to Source Connection Guide Smartphone...
  • Page 13 Projector screen. This function may not be supported depending on the model. This function is available in Samsung mobile devices with Android 8.1 or higher. Enable Tap View on your mobile device. For more information about configuration, refer to 'Enabling the Tap View' below for how to set.
  • Page 14 Using the Multi View While watching the TV, you can see content from your mobile device through mirroring (Smart View). To start Multi View, run the screen sharing (Smart View) for your mobile device. This function can be started or stopped by pressing the button on the remote control.

  • Page 15: Connecting To A Network Via A Mobile Dongle (For India Only)

    Connecting to a Network via a Mobile Dongle (For India Only) Make network connection by connecting a mobile dongle to the Projector. You can make the Projector to connect to a network via a mobile device by connecting a mobile dongle to the Projector.

  • Page 16: Connection Cables For External Devices

    Connection Cables for External Devices You can view detailed information about the connection cables for external devices that can be connected to the Projector. Cable name Image Description Each cable simultaneously transmits digital video and audio signals from an external device to the HDMI port on the Projector. HDMI Cables are divided into various types according to the types of input/ output ports on external devices.
  • Page 17 Cable name Image Description DVI to HDMI cables can transmit only digital video signals and not audio signals. We recommend that you use HDMI to HDMI cables. HDMI Optical cables are used to transmit audio signals to external speakers with low signal loss. Optical Optical cables do not transmit video signals.

  • Page 18: Adb (Auto Data Backup) Functions (For India Only)

    USB storage device or an external hard disk drive connected to the Projector. You can also transfer files from the ADB (Auto Data Backup) folder to a Samsung mobile device over Wi-Fi Direct.

  • Page 19: Switching Between External Devices Connected To The Projector

    HDMI port on the Projector, and then turn on the device. The output displayed on the Projector is automatically switched to the output of the device or you can configure universal remote control for the device automatically. For more information, refer to "Controlling External Devices with a Samsung Remote Control - Using the Universal Remote".
  • Page 20 Universal Remote You can control external devices connected to the Projector using a Samsung remote control. To control external devices, register them by following the instructions on the screen. This function may not be supported depending on the model or geographical area.

  • Page 21: Connection Notes

    Connection Notes When connecting an external device, note the following. The number of connectors and their names and locations may differ with the model. Refer to the external device's operating manual when connecting it to the Projector. The number of external device connectors and their names and locations may differ with the manufacturer.
  • Page 22 Connection notes for audio devices • For better audio quality, it is a good idea to use an AV receiver. • If you connect an external audio device using an optical cable, the Sound Output setting is automatically changed to the connected device. However, to make this happen, you must turn on the external audio device before connecting the optical cable.
  • Page 23 Connection notes for mobile devices • To use the Smart View function, the mobile device must support a mirroring function such as Screen Mirroring or Smart View. To check whether your mobile device supports the mirroring function, refer to the mobile device's user manual.

  • Page 24: Peripherals

    Source Universal Remote You can control external devices connected to the Projector using a Samsung remote control. To control external devices, register them by following the instructions on the screen. This function may not be supported depending on the model or geographical area.

  • Page 25: Using Anynet+ (Hdmi-Cec)

    You can configure the Projector's Universal Remote to control third-party cable boxes, Blu-ray players and home theatres that do not support HDMI-CEC. For more information, refer to "Controlling External Devices with a Samsung Remote Control - Using the Universal Remote".

  • Page 26: Controlling The Projector With A Keyboard, Mouse Or Gamepad

    Controlling the Projector with a Keyboard, Mouse or Gamepad Connecting a keyboard, mouse or gamepad to make it easier to control the Projector. Settings General External Device Manager Input Device Manager Try Now You can connect a keyboard, mouse or gamepad to make it easier to control the Projector. Connecting a USB keyboard, mouse or gamepad Plug the keyboard, mouse or gamepad cable into the USB port.
  • Page 27 Using the keyboard and mouse Button Description Directional keys Moves the focus Windows key Displays the Projector settings Enter key Selects or runs a focused item ESC key Returns to the previous screen F1 / F2 / F3 / F4 key Colour buttons ―...

  • Page 28: Entering Text Using The On-Screen Virtual Keyboard

    Setting up the input devices Settings General External Device Manager Input Device Manager • Keyboard Settings You can set up the keyboard with the Keyboard Language Keyboard type functions. • Mouse Settings You can set up the mouse with the Primary Button Pointer Speed functions.
  • Page 29 Options Select on the virtual keyboard screen. The following options are available: The options available may differ depending on the function running currently. • Recommend text • Reset Recommended Text Memory • Accented Character Preview • Predict Next Character (when using direction buttons) •...

  • Page 30: Smart Features

    Smart Features You can enjoy various apps with Smart Hub. Using Smart Hub View descriptions of Smart Hub's basic functions. From Smart Hub, you can use the Internet search function, install and use various apps, view photos and videos or listen to music stored on external storage devices, and perform more functions.
  • Page 31 Displaying the Home Screen Press the button. Sources HDMI 1 Remote Access Connection Guide Universal Remote Source The image on your Projector may differ from the image above depending on the model and geographical area. On the Home Screen, you can easily run the apps you have used previously or frequently. The apps can also be moved or deleted from the screen.
  • Page 32 • Picture Mode You can select the picture mode that provides the best viewing experience. To change the picture mode, press the Select button. To make fine adjustments, press the up directional button, and then select Picture Setup. • Sound Mode You can select a sound mode to optimise your listening experience.
  • Page 33 • Sleep Timer You can automatically shut off the Projector after a pre-set period of time. To set the sleep time to up to 180 minutes, press the Select button. To make detail off timer, press the up directional button, and then select Set Up Off Timer.
  • Page 34 • Device Care You can run Device Care to diagnose and optimise your Projector. Device Care can also check and optimise the Projector's storage. If any trouble found, it can call for technical support. • All Settings Display the Settings menu.
  • Page 35 Universal Guide can recommend content tailored to your preferences. You can use this feature on your mobile device with the Samsung SmartThings app. To enjoy the content from these apps on your Projector, they must be installed on the Projector.
  • Page 36 Move Remove The image on your Projector may differ from the image above depending on the model and geographical area. Moving an item on the Home Screen Move the focus to the app you want to move, press and hold the Select button on the remote control, and then select Move in option menu.
  • Page 37 Launching Smart Hub automatically Settings General Smart Features Autorun Smart Hub Try Now When you set Autorun Smart Hub to On, the Projector displays the Home Screen automatically when you turn the Projector on. You can also turn this function on or off. Press the Select button at the current menu. Launching the last used app automatically Settings General...

  • Page 38: Using A Samsung Account

    Terms & Conditions, Privacy Policy after logging in to your Samsung account. You can create a Samsung account at http://account.samsung.com. Once you have an account, you can use the same ID on both the Projector and the Samsung website. Signing in to a Samsung account...
  • Page 39 You can view or manage your payment information. • Back up You can back up the Projector settings to your Samsung Cloud storage. When resetting or replacing the Projector, you can also restore its settings with the backed-up settings. •...

  • Page 40: Using Remote Access

    Using Remote Access Use the Projector to access your PC via Remote PC, Screen Sharing (Wireless) or Cloud Service. Source Remote Access You can use the Projector to access your PC via Remote PC, Screen Sharing (Wireless) or Cloud Service. For smooth use as in a computer, connect a keyboard and a mouse to your Projector in advance.
  • Page 41 Connecting a Remote PC Provides Remote Desktop Connection (RDP) for remotely connecting to a PC running on Windows and Virtual Network Computing (VNC) for a PC running on Mac. To remotely connect to a PC, you must enter the IP address of the remote PC or select a saved profile.
  • Page 42 Playing Multimedia Content on a Remote PC When you move the mouse cursor to the top of the screen after accessing a remote computer, the top bar appears. When the sharing folder icon is clicked in the top bar, the folders shared on Windows or Mac OS appear. You can play back any media content in a folder.
  • Page 43 ID and password without biometric authentication on mobile devices. For this purpose, you must be signed in to your Samsung account. The password is encrypted to be safely stored on your Projector.

  • Page 44: Using The Apps Service

    If you are signed out of your Samsung account, select Sign In to sign in. If you want to download new apps using Apps, first sign in to your Samsung account. App Search You can search for available apps. Settings You can manage the installed apps.
  • Page 45 Installing an app Move to the app you want to install, and then press the Select button. The detailed information screen appears. Select Install. When the installation is complete, the Open menu appears. Select Open to run the app immediately. You can view installed apps on the Settings screen.
  • Page 46 Managing installed apps Select Settings on Apps. You can manage installed apps. Settings Copyright Auto update : ON Delete Add to Home Lock Move Reinstall View Details The image on your Projector may differ from the image above depending on the model and geographical area. Removing an app 1.
  • Page 47 Locking and unlocking apps 1. Select an app to lock or unlock. 2. Select Lock/Unlock. The selected app is locked or unlocked. To lock or unlock an app, enter the PIN. The default PIN is "0000". You can set the PIN in Settings General System Manager...

  • Page 48: Using The Gallery App

    The image on your Projector may differ from the image above depending on the model and geographical area. You can enjoy various content synchronised with a mobile device that supports the Samsung Cloud. The available content types are photos, videos, stories and other content shared through your groups.

  • Page 49: Using The Smartthings App

    SmartThings app installed on them. You can receive notifications about the statuses of your connected devices. To use this function, you must be logged in to your Samsung account. This function may not be supported depending on the model or geographical area.

  • Page 50: Using The E-Manual

    Open e-Manual You can view the embedded e-Manual that contains information about your Projector's key features. You can download a copy of the e-Manual from Samsung's website to view or print on your PC or mobile device (http:// www.samsung.com). Some menu screens cannot be accessed from the e-Manual.
  • Page 51 Using the buttons in the e-Manual e-Manual Guide Troubleshooting First Time Use Recently Viewed e-Manual Topics The image on your Projector may differ from the image above depending on the model and geographical area. (Search) Select an item from the search results to load the corresponding page. (Site Map) It displays the lists for each item in e-Manual.
  • Page 52 e-Manual Internet Surf the Internet on your Projector. Before using the Internet, refer to "Read Before Using the Internet Function". Words in blue (e.g., Internet) indicate a menu item. The image on your Projector may differ from the image above depending on the model and geographical area. (Try Now) Allows you to access the corresponding menu item and try out the feature right away.

  • Page 53: Using The Internet

    Internet function more easily after connecting a keyboard and mouse. You can scroll web pages with the directional button on the Samsung Smart Remote. The web pages may differ from those on a PC. Before using the Internet, refer to "Read Before Using the Internet Function".

  • Page 54: Playing Pictures/Video/Music

    "Read Before Playing Photo, Video or Music Files". Backup important files before connecting a USB device. Samsung is not responsible for damaged or lost files. You can use the following functions on the media content list screen of a storage device.
  • Page 55 Playing multimedia content on a PC or mobile device Select a device with media content in Source. The media content list in the device appears. Select a media content item from the list. The selected content is played. The content may not be played depending on the encoding method or file format. Furthermore, several functions may be restricted.
  • Page 56 Tune Station (MusicTV) functions Tune Station is an all-purpose dashboard to simplify the entire musical experience when user wants to play music file from USB source. It provides feature to user like themes, concert mode control, external speakers indicator - all from single display interface.
  • Page 57 Buttons and functions available while playing multimedia content Press the Select button while playing any video, photo or recorded content. The following buttons appear. The provided buttons and functions may not be supported depending on the model or geographical area. The available buttons and functions may differ with the content you are viewing or playing.
  • Page 58 • Repeat Plays the current multimedia content repeatedly or all multimedia content files in the same folder repeatedly. • Shuffle Plays music files in random order. • Picture Off Plays music files with the screen off. • Fit to Screen Fits a photo to the screen.
  • Page 59 • Options The available options may differ with the model and content. Function Description Sets the slideshow speed. Slideshow Speed If there is only one image file in the USB device, the slide show is not played. Applies transition effects to the slide show. Slideshow Effect If there is only one image file in the USB device, the slide show is not played.

  • Page 60: Using Bixby

    Bixby is available only when the Projector is connected to the Internet. To use Bixby, you must register and sign in to your Samsung account. Some functions may not be supported if you are not signed in to your Samsung account.
  • Page 61 Bixby generated for your voice. You can delete a voice ID after selecting Profile. When the voice ID is deleted, its icon also disappears. If you are signed out of your Samsung account, select My Profile to sign in.
  • Page 62 • Voice response You can change or turn off Bixby's voice. This function may not be supported depending on the language selected for Bixby. • Sound feedback Play a sound when Bixby starts and stops listening. This function may not be supported depending on the model or geographical area. •...
  • Page 63 • The existing functional specifications may be changed if Bixby is updated. • Bixby is available only on Projectors that support it and come with remote controls that have a microphone. • Symbols including "-" and special characters are not supported. Consequently, if a word or sentence contains numeric values or symbols, the function may not operate properly.

  • Page 64: Projector Viewing

    Guide while watching Projector, press the (Channel) on the Samsung Smart Remote or press the GUIDE button on the standard remote control. To see information about analogue channels and use the analogue channel functions of the Guide, you must finish the service provider settings in initial setup.
  • Page 65 Move the focus to the programme you want in the Guide, and then press and hold the Select button. You can use the following functions: • Schedule Viewing You can schedule the viewing of a broadcast scheduled programme. • Cancel Scheduled Viewing You can cancel scheduled viewings.

  • Page 66: Setting Up A Schedule Viewing

    Setting Up a Schedule Viewing Configure the Projector to show a specific channel or programme at a specific time and date. appears next to programmes that have been configured for a scheduled viewing. To set up a schedule viewing, you must first set the Projector's clock ( Settings General System Manager...
  • Page 67 Setting the schedule Viewing Time Live TV Schedule Manager You can change scheduled viewing information or cancel scheduled viewings. You can set up a maximum total of 30 Schedule Viewing entries. The menus may not appear depending on the model or geographical area. •...

  • Page 68: Using The Channel List

    This function may differ depending on the model or geographical area. • Samsung TV Plus While the Projector is connected to the Internet, you can watch popular programmes or highlights for each theme through a virtual channel at any time. As with regular channels, the Projector provides the daily...

  • Page 69: Editing Channels

    This function may not be supported depending on the model or geographical area. When a channel number is changed, its channel information is not updated automatically. • Restore Samsung TV Plus You can restore the deleted Samsung TV Plus channels.

  • Page 70: Using A Personal Favourites List

    Using a Personal Favourites List Designate frequently watched channels as favourite channels. Favourite channels are highlighted in the Edit Channels Channel List screens with the symbol. You can create up to five favourites lists so that your family members can create their own personal favourites list. Create a favourites list Live TV Channel List...

  • Page 71: Projector-Viewing Support Functions

    Projector-Viewing Support Functions Use the functions that are available while watching Projector. Changing the broadcast signal Live TV Channel List Press the directional button on your remote control, move the focus to Terrestrial, Cable or Satellite, and then press the Select button. You do not need to use this function if your Projector is connected to a cable box or satellite box.
  • Page 72 Scanning for available channels on standby mode Settings Broadcasting (Auto Tuning Settings) Standby Auto Tuning Automatically scan for channels while your Projector is in standby mode. This function may not be supported depending on the model or geographical area. Auto Tuning Settings may not appear depending on the model or geographical area.
  • Page 73 Restricting Viewing to Specific Channels Settings Broadcasting Apply Channel Lock Try Now By selecting the menu, you can turn on or off the Apply Channel Lock function. Lock specific channels to prevent children from watching adult content. To use this function, the PIN number is required. Selecting the broadcasting audio option Settings Broadcasting...
  • Page 74 Tuning broadcast signals manually Settings Broadcasting Expert Settings Manual Tuning Try Now You can scan for all the channels manually and store the scanned channels in the Projector. This function may not be supported depending on the model or geographical area. Tuning digital channels Settings Broadcasting...
  • Page 75 Fine-tuning analogue broadcasts Settings Broadcasting Expert Settings Fine Tune Try Now This function is only available for analogue broadcasts. Transferring channel list Settings Broadcasting Expert Settings Transfer Channel List You can import or export the channel list to a USB storage. To use this function, the PIN number is required. •...
  • Page 76 Selecting the broadcast audio language Settings Broadcasting Expert Settings Audio Options Try Now Configure your preferred audio options for viewing broadcasted content. Audio Options functions differently for analogue and digital channels. This function may not be supported depending on the model or geographical area. This function may not be supported depending on the incoming broadcast signal.

  • Page 77: Picture And Sound

    Picture and Sound You can change the settings for the picture and the sound according to your preference. Setting the Viewing Environment for Projector Adjust the Projector's mode options and installation settings for your viewing environment. Guide to screen adjustment Settings General Projector Settings...

  • Page 78: Adjusting The Picture Quality

    Adjusting the Picture Quality Change the Picture Mode and adjust Expert Settings. Choosing a picture mode Settings Picture Picture Mode Try Now You can select the Picture Mode that provides the best viewing experience. • Dynamic Makes the picture brighter and clearer in bright viewing environments. •...
  • Page 79 Configuring advanced picture settings Settings Picture Expert Settings Try Now Configure the screen settings to your taste by using the following functions: • Contrast Try Now • Sharpness Try Now • Colour Try Now • Tint (G/R) Try Now • Apply Picture Settings Try Now •...

  • Page 80: Setting The Viewing Environment For External Devices

    Setting the Viewing Environment for External Devices You can optimise the Projector for viewing specific video formats. Playing games on an optimised screen Settings General External Device Manager Game Mode You can enable game mode to optimise the Projector's settings for playing video games with a gaming console, such as a PlayStation™, Xbox™...

  • Page 81: Picture Support Functions

    This function is available only if Picture Size is set to Custom. To change the picture position on analogue channels, first enlarge the picture and then change the position. These functions may not be available on Samsung TV Plus and some applications. - 81 -...

  • Page 82: Configuring A Sound Mode And Expert Settings

    Configuring a Sound Mode and Expert Settings Change the Sound Mode and adjust Expert Settings. Choosing a sound mode Settings Sound Sound Mode Try Now You can select the available sound mode that you prefer for a content type or your listening environment. When an external device is connected, Sound Mode may change accordingly.
  • Page 83 Digital Output Audio Delay Try Now • This feature is only available when the external device is connected via HDMI (eARC) and SPDIF (Sony Philips Digital Interface). HDMI (ARC) is supported by some models. Check the HDMI port name of the purchased product's model. •...

  • Page 84: Using The Sound Support Functions

    Try Now You can select which speakers the Projector uses for audio output. External speakers may not be controlled with the Samsung remote control. When an external speaker is enabled, some sound menus are not supported. Refer to the sound bar's user manual when connecting it to the Projector.
  • Page 85 Listening to the Projector through a Samsung audio device that supports the Wi-Fi function For more information about how to connect and use a Samsung audio device that supports the Wi-Fi function, refer to its user manual. Settings Sound Wi-Fi Speaker Surround Setup...

  • Page 86: System And Support

    System and Support You can configure system and support settings such as clock, timers, energy usage and software updates. Using the Time Functions and the Timers Set the current time and use the timer function. Settings General System Manager Time Try Now You can set the Clock...
  • Page 87 Changing the current time Settings General System Manager Time Clock Time Offset Time Offset adjusts the time through a network connection. This function is available only when Clock Mode is set to Auto, the Projector fails to receive time information through normal broadcast signals, and the Projector is connected to the Internet through a local area network.

  • Page 88: Using The Auto Protection Time And Energy Saving Functions

    Using the Auto Protection Time and Energy Saving Functions Set the Auto Protection Time and reduce the Projector's energy consumption. Setting the Auto Protection Time Settings General System Manager Auto Protection Time Try Now Activate a screensaver when your Projector displays a still image for two hours or more. This function may not be supported in some viewing modes.

  • Page 89: Updating The Projector's Software

    Software Update Update Now After downloading the update file from the Samsung website and storing it on a USB device, connect the USB device to the Projector to update. To update using a USB device, download the update package from Samsung.com to your computer. Then, save the update package in the USB device's top-level folder.

  • Page 90: Audio And Video Functions For The Visually Or Hearing Impaired

    Audio and Video Functions for the Visually or Hearing Impaired You can configure the functions for the visually or hearing impaired. Running the accessibility functions Settings General Accessibility Try Now Running Accessibility Shortcuts Accessibility Shortcuts provide easy access to the accessibility functions. To display the Accessibility Shortcuts, press and hold the Volume button for 1 second or more.
  • Page 91 Changing the volume, speed, pitch and the Projector background volume of the Voice Guide You can configure the volume, speed pitch and the Projector background volume of the voice guide. Audio Description Settings General Accessibility Audio Description Settings You can activate an audio guide that provides an audio description of video scenes for the visually impaired. This function is only available with broadcasts that provide this service.
  • Page 92 Enlarging the font (for the visually impaired) Settings General Accessibility Enlarge Try Now You can enlarge the size of the font on the screen. To activate, set Enlarge to On. Learning about the remote control (for the visually impaired) Settings General Accessibility Learn Remote...
  • Page 93 Watching TV broadcasts with subtitles Settings General Accessibility Subtitle Settings Try Now Subtitle to On. Then you can watch the programme with the subtitle displayed. This function may not be supported depending on the model or geographical area. This function has no relationship with the features for controlling sub-titles of DVD or Blu-ray players. To control DVD or Blu-ray subtitles, use the sub-title feature of the DVD or Blu-ray player and the player's remote control.
  • Page 94 Listening to the Projector through Bluetooth devices (for the hearing impaired) Settings General Accessibility Multi-output Audio You can turn on both the Projector speaker and Bluetooth headphone at the same time. When this function is active, you can set the volume of the Bluetooth headphone higher than the volume of the Projector speaker. This function may not be supported depending on the model or geographical area.

  • Page 95: Using Voice Assistant On Projector

    Using Voice Assistant on Projector You can change the settings of a Voice Assistant after selecting it. Select the Voice Assistant Settings General Voice Voice Assistant Select which Voice Assistant you would like to help control your Projector. To use this function, the Projector must be connected to the Internet. This function may not be supported depending on the model or geographical area.

  • Page 96: Using Other Functions

    If you forget your PIN, you can reset it with your remote control. With the Projector turned on, press the following buttons on the remote control in the order shown to reset the PIN to "0000". On the Samsung Smart Remote: Press (Volume) button.
  • Page 97 Using AirPlay Settings General Apple AirPlay Settings You can use AirPlay to view content from your iPhone, iPad or Mac on the Projector screen. This function may not be supported depending on the model or geographical area. Restoring the Projector to the factory settings Settings General Reset...

  • Page 98: Hbbtv

    HbbTV Access services from entertainment providers, online providers and CE manufactures through HbbTV. This function may not be supported depending on the model or geographical area. Some channels may not include the HbbTV service. In some countries, HbbTV is disabled by default. In this case, HbbTV can be used by installing the HbbTV application (the HbbTV Installer Application) in Apps.

  • Page 99: Teletext Feature

    To exit from the Teletext feature, On the Samsung Smart Remote: Press the TTX/MIX button on the pop-up list until a live TV programme appears. On the standard remote control: Press the / TTX/MIX button on the remote control until live TV appears.
  • Page 100 6 Index: Displays the index (contents) page at any time while you are viewing Teletext. 1 Sub Page: Displays the available sub-page. 0 List/Flof: Selects the Teletext mode. If pressed during LIST mode, switches the mode to List save mode. In List save mode, you can save a Teletext page into a list using the 8 (Store) button.
  • Page 101 6 SETTINGS Index: Displays the index (contents) page at any time while you are viewing Teletext. 1 PRE-CH Sub Page: Displays the available sub-page. 0 SOURCE List/Flof: Selects the Teletext mode. If pressed during LIST mode, switches the mode to List save mode. In List save mode, you can save a Teletext page into a list using the 8 (CH LIST) button.
  • Page 102 4 AD/SUBT. Depending on the model or geographical area. Size: Displays the teletext on the upper half of the screen in double-size. To move the text to the lower half of the screen, press it again. For normal display, press it once again. 9 RETURN Hold: Holds the display at the current page, in the case that there are several secondary pages that follow automatically.

  • Page 103: Precautions And Notes

    Precautions and Notes You can get instructions and information that you must read after installation. Supported broadcasting audio options Check the supported broadcasting audio options. Audio Type Dual Sound Default Mono Mono Automatic change A2 Stereo Stereo Stereo, Mono Automatic change Dual Dual Dual II...

  • Page 104: Read Before Using Apps

    • If you want to download new apps using Apps, first sign in to your Samsung account. • Due to the product characteristics featured on Samsung Smart Hub, as well as limitations in available content, certain features, applications and services may not be available on all devices or in all territories. Visit http:// www.samsung.com for more information on specific device information and content availability.

  • Page 105: Read Before Using The Internet Function

    Read Before Using the Internet Function Read this information before using the Internet function. • File download is not supported. • The Internet function may not be able to access certain websites, including websites operated by certain companies. • The Projector does not support playback of flash videos. •...
  • Page 106 Precautions for wireless Internet • This Projector supports the IEEE 802.11 a /b /g /n /ac communication protocols. Samsung recommends using IEEE 802.11n. Video files stored on a device connected to the Projector via a Home Network may not play back smoothly.

  • Page 107: Read Before Playing Photo, Video Or Music Files

    • Certain files, depending on how they are encoded, may not play on the Projector. • Certain files are not supported on all models. • The DivX and DTS codecs are not supported by the Samsung Projector models released in 2020. - 107 -...
  • Page 108 Supported subtitles Subtitle formats Name Format MPEG-4 Timed text .ttxt SAMI .smi SubRip .srt SubViewer .sub Micro DVD .sub or .txt SubStation Alpha .ssa Advanced SubStation Alpha .ass SMPTE-TT Text .xml Video formats with subtitles Name Container Xsub SubStation Alpha Advanced SubStation Alpha SubRip VobSub...
  • Page 109 Supported image formats and resolutions File extension Format Resolution *.jpg JPEG 15360 x 9024 *.jpeg *.png 4096 x 4096 *.bmp 4096 x 4096 *.mpo 15360 x 8640 The MPO format is supported partly. Supported music formats and codecs File extension Format Codec Note...
  • Page 110 Supported video codecs File Bitrate Container Video codecs Resolution Frame rate (fps) Audio codecs format (Mbps) *.avi 3840 x 2160: 30 H.264 BP/MP/HP *.mkv 1920 x 1080: 60 3840 x 2160 *.asf HEVC (H.265 - Main, Main10) *.wmv Dolby Digital Motion JPEG *.mp4 LPCM...
  • Page 111 Other restrictions • Codecs may not function properly if there is a problem with the content. • Video content does not play or does not play correctly if there is an error in the content or container. • Sound or video may not work if they have standard bit rates/frame rates above the Projector’s compatibility ratings.

  • Page 112: Read After Installing The Projector

    Read After Installing the Projector Read this information after installing the Projector. Picture sizes and input signals Picture Size is applied to the current source. The applied Picture Size will remain in effect whenever you select that source unless you change them. Input signal Picture size Component...

  • Page 113: Supported Resolutions For Uhd Input Signals

    Supported Resolutions for UHD Input Signals Check the supported resolution for UHD input signals. • Resolution: 3840 x 2160p, 4096 x 2160p If Input Signal Plus is set to Off Colour Depth / Frame rate (fps) Chroma RGB 4:4:4 YCbCr 4:4:4 YCbCr 4:2:2 YCbCr 4:2:0 Sampling...

  • Page 114: Read Before Connecting A Computer (Supported Resolutions)

    Read Before Connecting a Computer (Supported Resolutions) Check the resolutions supported for PC input signals. When you connect your Projector to a computer, set the computer's video card to one of the standard resolutions listed in the tables below or on the next pages. The Projector will automatically adjust to the resolution you choose. Note that the optimal and recommended resolution is 3840 x 2160 at 60 Hz.
  • Page 115 VESA DMT Horizontal Vertical Polarity Resolution Clock frequency frequency frequency Display format (horizontal / (Dots x lines) (MHz) vertical) (KHz) (Hz) 640 x 480 60 Hz 31.469 59.940 25.175 - / - 640 x 480 72 Hz 37.861 72.809 31.500 - / - 640 x 480 75 Hz...
  • Page 116 VESA CVT Horizontal Vertical Polarity Resolution Clock frequency frequency frequency Display format (horizontal / (Dots x lines) (MHz) vertical) (KHz) (Hz) 2560 x 1440 60 Hz 88.787 59.951 241.500 + / - CTA-861 Horizontal Vertical Polarity Resolution Clock frequency frequency frequency Display format (horizontal /...

  • Page 117: Supported Resolutions For Video Signals

    Supported Resolutions for Video Signals Check the resolutions supported for video signals. CTA-861 Horizontal Vertical Polarity Resolution Clock frequency frequency frequency Display format (horizontal / (Dots x lines) (MHz) vertical) (KHz) (Hz) 720 (1440) x 576i 50 Hz 15.625 50.000 27.000 - / - 720 (1440) x 480i...
  • Page 118 Horizontal Vertical Polarity Resolution Clock frequency frequency frequency Display format (horizontal / (Dots x lines) (MHz) vertical) (KHz) (Hz) 4096 x 2160 24 Hz 54.000 24.000 297.000 + / + 4096 x 2160 25 Hz 56.250 25.000 297.000 + / + 4096 x 2160 30 Hz 67.500...

  • Page 119: Read Before Using Bluetooth Devices

    Read Before Using Bluetooth Devices Read this information before using a Bluetooth device. Restrictions on using Bluetooth • You can't use Bluetooth devices and the Wi-Fi Speaker Surround Setup feature simultaneously. • Compatibility issues may occur, depending on the Bluetooth device. (A Mobile exclusive headphone may not be available, depending on the environment.) •...

  • Page 120: Suffix : Parental Rating - Thailand Only

    Suffix : Parental Rating - Thailand only Alphabet Icon Description Allow All The broadcated rating value is not classified Preschool Content suitable for preschool aged children 3-5 years old Children Content suitable for children between 6–12 years old General Content suitable for general audiences PG 13 Content suitable for people aged 13 and above, but can be watched by those who are under the recommended age if parental guidance is provided...

  • Page 121: Licences

    HDMI Licensing LLC in the United States and other countries. Open Source License Notice Open Source used in this product can be found on the following webpage. (http://opensource.samsung.com) This licence may not be supported depending on the model or geographical area.

  • Page 122: Troubleshooting

    Troubleshooting If you have a problem with your Projector, you can access various solutions while watching Projector. If your problem is not addressed in the Troubleshooting section, contact the Samsung Service Centre. Picture Issues When the Projector has trouble with the picture, these steps may help resolve the problem.
  • Page 123 The problem Try this! If your Projector appears to turn off by itself, try disabling some of the Projector's energy efficiency functions. See if Sleep Timer has been enabled. The Sleep Timer automatically turns the Projector off after a specified period of time. •...
  • Page 124 UHD and set the resolution. For more information, contact your service provider. When using a Samsung TV Plus channel, check the network connection. When the network speed is slow, the app may not work or the image quality may be poor.
  • Page 125 External Device Manager Input Signal Plus If the test picture does not appear or there is noise or distortion, the Projector may have a problem. Contact Samsung’s Call Centre for assistance. If the test picture is displayed properly, there may be a problem with an external device. Please check the connections.

  • Page 126: Sound And Noise Issues

    Sound and Noise Issues When the Projector has difficulties with sound, these steps may help resolve the problem. Testing the sound Settings Support Device Care Self Diagnosis Sound Test Try Now If the Projector plays the Sound Test melody without distortion, there may be a problem with an external device or the broadcast signal's strength.
  • Page 127 The problem Try this! Check whether Digital Output Audio Format is set to Pass-through. If you select the Pass-through option to use an AV receiver that does not support Dolby Digital+, no sound is output with Dolby Digital+ content. No sound is heard. It is recommended to set Digital Output Audio Format Auto...
  • Page 128 When you connect the Samsung Soundbar to the Projector via Bluetooth, the power turns off and on together. It may not be supported depending on the Samsung Soundbar model. I want to turn off and on the...

  • Page 129: Channel And Broadcast Issues

    Channel and Broadcast Issues When the Projector has difficulties receiving broadcasts, these steps may help resolve the problem. The problem Try this! Make sure that the external device is connected securely and turned on. Move Sources to switch to other input sources. “Weak or No Signal”...

  • Page 130: External Device Connectivity Issues

    External Device Connectivity Issues When the Projector has difficulties connecting to external devices such as a PC, game console or mobile device, these steps may help resolve the problem. The problem Try this! The "Mode Not Supported" message Adjust the output resolution of the external device to a resolution supported by appears.
  • Page 131 The problem Try this! When the PC screen does not appear or the PC is not recognised, check the power supply of the PC and then reconnect the HDMI cable between the PC and Projector. When the symptom persists, check that the PC is in Sleep mode. The PC screen does not appear or it flickers.

  • Page 132: Network Issues

    Network Issues When the Projector has difficulties connecting to the Internet, these steps may help resolve the problem. Settings Support Device Care Self Diagnosis Smart Hub Connection Test Try Now Try Now If the Projector has trouble with network connection or Projector services, check the Smart Hub connection status. The problem Try this! Make sure that no items that can generate electromagnetic interferences are...

  • Page 133: Anynet+ (Hdmi-Cec) Issues

    Anynet+ (HDMI-CEC) Issues When Anynet+ (HDMI-CEC) isn't working, these steps may help resolve the problem. The problem Try this! You can use the Projector's remote control to control external devices that support Anynet+ (HDMI-CEC) and that are connected to the Projector via an HDMI cable. For What is Anynet+? example, if a connected external device supports Anynet+, you can have the connected device turn on or off when you turn the Projector on or off.

  • Page 134: Remote Control Issues

    Try this! The connection between the Samsung Smart Remote and the Projector may be lost. Point the Samsung Smart Remote at the front of the Projector, and then press and hold the buttons simultaneously for 3 seconds or more. The remote control does not work.

  • Page 135: Media Files

    Apps When apps aren't working, these steps may help resolve the problem. The problem Try this! Languages supported by an app may be different from the Projector Language I launched an app, but it's in a different set in the menu. language.

  • Page 136: Voice Assistant Issues

    Assistant: Settings General Voice Google Assistant Settings With Samsung Smart Remote, the following features are available except for voice recognition. Try pairing the remote control with the Projector. There is no response even if the voice entry button is pressed.

  • Page 137: Other Issues

    Other issues Use these procedures to resolve other issues that may occur in relation to the product. The problem Try this! Watching Projector for an extended period of time causes the panel to generate heat. The heat from the panel is dissipated through internal vents running along the top of the Projector.
  • Page 138 Guide. To Accessibility Shortcuts, see the following: • Press and hold the (Volume) button on your Samsung Smart Remote. The Projector narrates the screen events • Press the AD/SUBT. button on the standard remote control or press and in voice-over.

  • Page 139: Diagnosing Projector Operational Issues

    Device Care Self Diagnosis Signal Information Resets all Smart Hub settings to their factory defaults and deletes all information related to Samsung accounts, linked service accounts, Smart Hub service agreements and Smart Hub applications. Reset Smart Hub • Settings Support...

  • Page 140: Getting Support

    Support About Projector You can view the address of the Samsung website, the call centre phone number, your Projector's model number, your Projector's software version, Open Source License and other information you may need to get service support from a Samsung call agent or the Samsung website.

  • Page 141: Accessibility Guidance

    • Samsung Smart Remote On the Samsung Smart Remote, there are two thin horizontal rocker buttons next to each other located slightly below the middle of the remote. The one on the left is the volume button. Press and hold the volume button to...
  • Page 142 There are many commands you can say to control the Projector. These can be used together with Voice Guide give you voice input and voice output. You can use the Samsung Smart Remote but the Projector must be connected to the Internet.
  • Page 143 Learning about the Accessibility menu functions • Voice Guide Settings This function works on every screen on the Projector and when turned on verbally tells you what the Projector's current settings are and verbally provides details about the programme you are watching. For example, it tells you the selected volume and the current channel and gives you programme information.
  • Page 144 • Enlarge You can enlarge important elements on the menu such as the names of programmes. • Learn Remote Learn the names and functions of the buttons on remote control. On this screen, pressing the power button (top left button) will turn off the Projector, but when any other button is pressed the Projector will say the button name and briefly tell what that button does.

  • Page 145: Using The Projector With Voice Guide On

    • (Channel) button Of the two buttons that protrude from the centre of the Samsung Smart Remote, the right one is the (Channel) button. Push up or pull down the (Channel) button to change the channel. Press the up or down of CH button on the standard remote control to change the channel.
  • Page 146 (Volume) button on the left to change the volume. Every time you change the volume, the new volume level will be announced. Of the two buttons that protrude from the centre of the Samsung Smart Remote, the left one is the (Volume) button. Push up or pull down the (Volume) button to change the volume.

  • Page 147: Using The Guide

    When you want to know the programme information for each channel while watching a broadcast programme, press the (Channel) button on the Samsung Smart Remote. Use the directional buttons to view the programme information. On standard remote control, press the GUIDE button.
  • Page 148 When you open the Guide, a table grid of channels and programmes is displayed. The top row displays Filter By : All then the day and times. Each row has a channel name on the left and programmes on that channel on the right. In the Guide, use the up and down directional buttons to move between channels and use the left and right directional buttons to move between programmes at different times within a channel.

  • Page 149: Using Schedule Viewing

    Using Schedule Viewing Configure the Projector to show a specific channel or programme at a specific time and date. icon appears next to programmes that have been configured for a schedule viewing. To set up a schedule viewing, you must first set the Projector's clock ( Settings General System Manager...

  • Page 150: Using The Channel List

    Category list. Use the up and down directional buttons to move within this list. Press the Select button to choose a category you want from the Category list. The Category list contains All, Samsung TV Plus, Favourites...
  • Page 151 • Samsung TV Plus While the Projector is connected to the Internet, you can watch popular programmes or highlights for each theme through a virtual channel at any time. As in a general channel, it provides the daily programme schedules Samsung TV Plus.

  • Page 152: Using Smart Hub

    Plus. Press the up directional button to move to the top row. You will be on the Guide item. The items in this row may include Guide, Channel List, Schedule Manager and others. Samsung TV Plus may not be supported depending on the model or geographical area. - 152 -...
  • Page 153 Using the Smart Hub Home Screen On the leftmost part of the Smart Hub home screen is the static menu listed below. You can quickly and easily use the listed menu items to access the main Projector settings or external devices, search and apps. •...
  • Page 154 Universal Guide can recommend content tailored to your preferences. You can use this feature on your mobile device with the Samsung SmartThings app. To enjoy the content from these apps on your Projector, they must be installed on the Projector.

  • Page 155: Launching The E-Manual

    Open e-Manual You can view the embedded e-Manual containing information about your Projector's key features. Alternatively, you can download a copy of the e-Manual from Samsung's website (http://www.samsung.com). Words in blue (e.g., Internet) indicate a menu item. The e-Manual contains 2 rows of menu icons. Use the up and down directional buttons to move between rows and the left and right directional buttons to move within a row.

  • Page 156: Using Bixby

    Using Bixby A guide to using Bixby to control your Projector. To use Bixby, your Projector must be connected to the Internet and you must use the microphone on your Samsung Smart Remote. To use Bixby, press and hold the button on the Samsung Smart Remote, say a command into the microphone on the remote, and then release the button to run Bixby.

Table of Contents
