ADJUSTABLE FEATURES
SX TRANSISTOR CONTROLS
Section 5: SETUP FUNCTIONS FOR TRACTION
CONTROLLER
With GE Digital Expertise for Palm OS
Windows, the user can access any E
perform various maintenance, diagnostic, and trouble-shooting
tasks without the aid of additional test equipment. GE Digital
Expertise for Palm OS and GE Sentry for Windows links
TM
directly to the microprocessor in the controller. See GE Digital
Expertise for Palm OS and GE Sentry for Windows instructions
TM
for additional details.
Microsoft, Windows 95 and Windows NT are registered
trademarks of Microsoft Corporation and Palm OS and HotSync
are registered trademarks of Palm, Inc, the Palm logo and Palm
Powered logo are the trademarks of Palm, Inc.
FUNCTION 1 MPH SCALING
This function allows for the pulses from the tachometer to
be scaled to miles per hour, based on the number of pulses
received by the control in a given time. For example, if you
were scaling to 8 MPH, it would correspond to the length of
time that it took to capture 8 tachometer pulses when the
vehicle is traveling at 8 MPH. Note: This function should
always be calculated using MPH.
Range 0 to 1.28 seconds
Set 0 to 255
Resolution 0.005 seconds per set unit
Example Setting of 18 = 0.09 seconds
Example to determine sitting:
RR = Rolling Radius (Inches)
Pi = 3.14159265
GR = Gear Ratio
PPR = Pulses per rotation of motor
Setting = 3600 X 2 X Pi X RR
5280 X 12 X GR X PPR X .005
Setting = 3600 X 2 X 3.14159265 X 9
5280 X 12 X 8.91 X 4 X .005
Setting = 203575
11290
Setting = 18
or GE Sentry for
TM
Prom setting, quickly
2
FUNCTION 2 CREEP SPEED
This function allows for the adjustment of the creep speed
of the vehicle when the accelerator potentiometer is at its
minimum value and the start switch is closed.
Range 2% to 15% on time
Set 0 to 255
Resolution 0.047% per set unit
Example Setting of 205=(205x0.047)+2
Important Note: The function is used to optimize motor and
control performance and this setting will be determined by
GE and OEM engineers at the time of vehicle development.
This setting must not be changed by field personnel without
the permission of the OEM.
FUNCTION 3 ARMATURE ACCELERATION RATE
This function allows for the adjustment of the rate of time it
takes for the control to accelerate to 100% applied battery
voltage to the motor on hard acceleration in the forward
direction.
Range 0.1 to 25.5 seconds
Set 1 to 255
Resolution 0.086 seconds per set unit
Example: Setting of 20 = 20 x 0.086=1.72 seconds
FUNCTION 4 MAX ARMATURE CURRENT LIMIT
This function allows for the adjustment of the armature
current limit of the control during motoring.
Range 0 to 350 amps
Set 0 to 255
Resolution 1.38 amps per unit
Example: Setting of 255 =(255x1.38)
FUNCTION 5 NOT USED
FUNCTION 6 ODOMETER CALIBRATION
This function is used to adjust the number of tachometer
pulses (divided by 64) that are equivalent to 0.1 MPH.
Range 0 to 255
Set 0 to 255
Example: RR = rolling radius
GR = gear ratio
PPR = pulses per rotation of motor
Setting = 6336 x GR x PPR
Page 30
= 11% on time
= 350 amps
6.28 x RR x 64
