- Page 1 Angle Grinder 125 mm (5”) MODEL 9015DB 150 mm (6”) MODEL 9016DB DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using.
- Page 2 SPECIFICATIONS model 9015DB 9016DB No load speed (RPM) 10,000/min 9,000/min Overall length 391 mm (15-3/8”) 391 mm (15-3/8”) Net weight 2.4 kg (5.3 lbs) 2.4 kg (5.3 lbs) Spindle thread 5/8” 5/8” • Manufacturer reserves the right to change specifications without notice.
- Page 3 5. Avoid body contact with grounded sur- be used for appropriate conditions. Ordinary eye or sun glasses are NOT eye protection. faces such as pipes, radiators, ranges and refrigerators. There is an increased risk of Tool Use and Care electric shock if your body is grounded. 15.
- Page 4 24. When servicing a tool, use only identical Use of unauthorized parts or failure to follow Maintenance instructions may create a risk of replacement parts. Follow instructions in the Maintenance section of this manual. electric shock or injury. USE PROPER EXTENSION CORD: Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw.
- Page 5 8. Be careful not to damage the spindle, the poor installation or a poorly balanced flange (especially the installing surface) wheel. or the lock nut. Damage to these parts 15. Use the specified surface of the wheel to could result in wheel breakage. perform the grinding.
- Page 6 FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Shaft lock 001025 CAUTION: • Never actuate the shaft lock when the spindle is moving. The tool may be damaged. Press the shaft lock to prevent spindle rotation when install- ing or removing accessories.
-
Page 7: Wheel Guard
Installing or removing wheel guard 001063 CAUTION: • When using a depressed center grinding wheel/Multi- disc, wire wheel brush or cut-off wheel, the wheel guard must be fitted on the tool so that the closed side of the guard always points toward the operator. Mount the wheel guard with the protrusion on the wheel 1. -
Page 8: Abrasive Disc
Installing or removing abrasive disc 001111 (optional accessory) NOTE: • Use sander accessories specified in this manual. These must be purchased separately. Mount the rubber pad onto the spindle. Fit the disc on the rubber pad and screw the lock nut onto the spindle. To 1. -
Page 9: Wire Wheel Brush
Once the edge of the wheel has been rounded off by use, the wheel may be worked in both A and B direction. Operation with wire cup brush 001140 (optional accessory) CAUTION: • Check operation of brush by running tool with no load, insuring that no one is in front of or in line with brush. - Page 10 Unplug tool and place it upside down allowing easy access to spindle. Remove any accessories on spindle. Thread wire wheel brush onto spindle and tighten with the wrenches. When using wire wheel brush, avoid applying too much pres- sure which causes over bending of wires, leading to prema- ture breakage.
- Page 11 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
-
Page 12: Table Of Contents
001183 9015DB 9016DB Grip 36 Wheel guard Inner flange 45 Inner flange 82 Depressed center grinding wheel/Multi-disc Lock nut 5/8-45 Lock nut 5/8-40 Rubber pad 115 Rubber pad 125 Abrasive disc Sanding lock nut 5/8-48 Wire wheel brush Urethane washer 14... - Page 13 Stamp Timbre Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold...
- Page 14 Your answers to the following questions are appreciated. 1. This product was purchased from? 3. How did you first learn of Makita Power Tools? Hardware/lumber Store Industrial Supply Magazine/Newspaper Catalog Tool Distributor Other ( From dealer Other ( Store display 2.
- Page 15 When you need service... DATE • Explain the problem in a letter PURCHASED: • Enclose the letter with the tool DEALER’S NAME • Package carefully and send prepaid & ADDRESS: to the nearest Makita factory or authorized service centre MODEL NO.: SERIAL NO.:...
- Page 16 WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
