- Page 1 User Manual Supra R17 High Speed Centrifuge Place of Purchase Serial No. Date of Purchase...
- Page 2 Supra R17 Research Only Use © 2019 Hanil Scientific Inc. If you have any questions, contact our Technical Support Center. +82-2-3452-8966 / techsupport@ihanil.com www.ihanil.com The appearance or specifications of the device is subject to partial change for improvement. UM-Supra R17(E)(Rev.1), 20210118...
- Page 3 INDEX 1. Safety Precautions ------------------------------------------------------------ 4 1.1 Safety -4 1.2 Transport & Storage - 5 1.3 Safety label on the Device - 5 1.4 Electric safety - 5 2. Product Description ---------------------------------------------------------- 6 2.1 Structure - 6 2.2 Delivery package - 7 2.3 Technical Specifications - 8 3.
-
Page 4: Safety Precautions
2.Check the voltage to be used, before connecting the device to the power source. 3.Only use rotors, parts, and accessories provided by Hanil Scientific Inc. Hanil Scientific Inc. is not responsible for damages of the device and accidents caused by the usage of non- recommended parts and accessories. -
Page 5: Storage And Transport
1. Safety Precautions 1.2 Storage & Transport Storage Transport Ambient temperature : 5℃ ~ 40℃ Ambient temperature : -10℃ ~ 40℃ Maximum relative humidity : 30% ~ 85% Maximum relative humidity : 10% ~ 90% Air pressure : 500 ~ 1060 hpa Air pressure : 500 ~ 1060 hpa 1.3 Safety label on the Device Attention... -
Page 6: Product Description
2. Product Description 2.1 Structure ① ② ③ ④ ⑤ ⑥ ① Lid ② Chamber ③ Display & Control panel ④ Emergency lid open hole ⑤ Power switch ⑥ Caster 6 / 31 www.ihanil.com... -
Page 7: Delivery Package
2. Product Description 2.2 Delivery Package ① User manual ② Power code ③ Rotor locking tool(Emergency lid open tool) ④ Grease(Lubricant) ⑤ Bubble leverler ⑥ Spanner Technical Support : +82-2-3452-8966 / techsupport@ihanil.com 7 / 31... -
Page 8: Technical Specifications
2. Product Description 2.3 Technical Specifications Max. RPM / Fixed angle 17,000 rpm Max. RCF / Fixed angle 34,249 xg Max. capacity 6 x 250 mL ACC/DEC ramps 9/10 steps Temperature range -20℃ to 40℃ Fast cool Time control Pulse, Timed < 10 hr continu Noise level ≤... -
Page 9: Installation
3.1 Packing Inspection •Check packing conditions carefully, before unpacking. •Contact Hanil Scientific Inc. immediately if any damage is found. •Check the delivery for completeness ▶ Our contact information is written on the box and on the outer cover of the manual. - Page 10 3. Installation 3.2 Installation 3.2.2 Balance Adjustment Imbalancing of the device itself causes vibration, noise and error during operation. Check the level of the floor surface with a Bubble Leveler before installation. ▶ After locating the device on the solid and flat floor, check the horizontality with a Bubble Leveler.
-
Page 11: Power Connection
3. Installation 3.3 Power Connection •Connect the device to a voltage source which corresponds to the electrical requirements on the label attached to the device. •Use sockets with a protective earth conductor and provided power cord. 1. After connecting the AC Power cord at the power socket on the right back of the device, turn on the earth leakage breaker switch. -
Page 12: Opening/Closing The Lid
3. Installaion 3.4 Opening/Closing the Lid Lid button Display For opening the lid, press the [LID] button. ▶ Should touch the [LID] button when the lid is closed (Lid LED shows off) ▶ Close the lid until hearing clank shut. ▶... -
Page 13: Installing/Removing The Rotor
3. Installation 3.5 Installing/Removing the Rotor • Only use rotors , parts , and accessories provided by Hanil Science Inc. • Do not use scratched or cracked rotor in use. 1. Before installing the rotor, remove any foreign object or moisture. -
Page 14: Loading Tubes
3. Installaion 3.6 Loading Tubes • Only use tubes provided or approved by Hanil Scientific Inc. • Always use the same type of tube. • Tubes should be loaded symmetrically. • Do not exceed the maximum rated speed of the tube. -
Page 15: Operation
4. Operation 4.1 Control Panel 1 0DDD 09:59 4 Button Description RPM/RCF For automatic conversion of RPM/RCF and to set the speed Use to set time, available range up to 9 hour 59 min TIME (00:00: continuous) Use to set temperature (-20°C ~ 40°C). Use to reach rapid TEMP refrigeration up to the setting temperature. -
Page 16: Setting Rpm/Rcf
4. Oeration Button Description Keylock Use for key lock mode Use to count the run time once the actual run speed AT SET SPEED reaches to the set speed value 다. Sound Use to set the number of sound and volume 4.2 Setting RPM/RCF Button Display... -
Page 17: Setting Run Time
4. Oeration 4.3 Setting Run Time Button Display 4.3.1 Setting AT SET SPEED mode AT SET SPEED mode For exact time control, this device can be set with AT SET SPEED mode which counts supports the run time once the actual run speed reaches to the set speed value and stops when the deceleration begins. - Page 18 4. Operation 3. Press the numeric buttons to change the hour value. ▶If you do not touch the number button for 15 seconds, the setting mode is cleared. ▶If wrong number is entered, touch [←] button and change the value again. 4.
-
Page 19: Setting Acceleration/Deceleration
4. Operation 4.5 Setting Acceleration/Deceleration Use the adjustment function of acceleration (level: 1~9) & deceleration levels (level: 0~9) to protect sensitive samples. Display Button 1. Press the [ACC/DEC] button. 2. Press the numeric buttons to change ACC value. 3. Press the [Enter] button. 4. -
Page 20: Pulse(Short Spin)
4. Operation 4.6.2 Stop 1. Press the [Start/Stop] button. ▶When you touch the [Start/Stop] button twice, the operation is stopped with DEC 9. 4.7 Pulse(Short spin) It is for quick and short spin down. Display Button It is for quick and short spin down. After reaching the set speed, the centrifugation is decelated and stopped. -
Page 21: Saving/Calling Up A Program
4. Operation 4.8 KEY LOCK Display Button 1. Touch [KEY LOCK] button. ▶All input buttons except for [KEY LOCK] button can be locked for protocol security (lock: LED on/ unlock: LED off) ▶If you touch the [KEY LOCK] button again in the key lock mode, the key lock mode is cleared. - Page 22 4. Operation 4.9.2 Calling up a Program 1. Press the [PROG] button once. ▶‘CALL’ is turned on the display window. 2. Press the numeric buttons to select program number you want to recall and then touch the [Enter] button. ▶If you do not touch the number button for 15 seconds, the setting mode is cleared. ▶If wrong number is entered, touch [←] button and change the value again.
- Page 23 4. Operation 4.11 Setting the Repeat Count of End Alarm Display Button 1. Press [AT SET SPEED] for more than 2seconds. ▶‘Sound rPt’ appears on the display window. 2. Touch the number buttons to change the value for the repeat count. 3.
- Page 24 4. Operation 4.12 Emergency Lid Open If the device lid cannot be opened, you can activte the emergency open manually. · Wait for the rotor to stop completely before activating the emergency open. · After opening the lid manually, it is recommended to wait until normal electricity comes back.
-
Page 25: Maintenance
5. Maintenance 5.1 Maintenance [Outer part of the device] 1. Clean the outside of the device with dry soft cloth. If necessary, dip the cloth in neutral detergent and clean contaminated area. Keep completely dry after cleaning. 2. Do not use any volatile chemicals such as alcohol and benzene, etc. 3. - Page 26 5. Maintenance 5.2 Care Instructions for Refrigerated device [Open the lid after centrifugation] 1. Wipe up the moisture in the chamber with a soft cloth. 2. Leave the centrifuge lid open after centrifugation. [Remove the condensation water] 1. There is a drain cap on the leftside of the device. Remove the drain cap and empty condensation water regularly.
-
Page 27: Troubleshooting
6. Trouble Shooting 6.1 Check list Symptom Check List Connect the AC Power cord and make sure that the line is completely Power failure connected between the device and power outlet. Check the power switch is turned on. If the lid is not closed completely, the device can’t run. Check the Lid Can’t be started LED on the display window and close the lid completely. -
Page 28: Error Codes
- If the function of rotor recognition is failed, this message is appeared. temperature - This message will be cleared by coupling an appropriate rotor. over or Inner - If the error code shows continuously, please call Hanil tech support or temperature place of purchase. sensor error 28/31 www.ihanil.com... - Page 29 - If the device is not reached to setting temperature within an hour, this Chamber message is appeared. Temp error - No user action. Please call Hanil tech support or place of purchase. - If there is a faulty in the temperature sensing of chamber or over Temp. heated, this message is appeared.
-
Page 30: Rotors And Accessories
7. Rotors and Accessories Fixed Angle Rotors Tube Required Bore Ø x L (mm) Max. RPM (rpm) Rotor Capacity Adaptor Radius (mm) Max. RCF (xg) Bottom Type A2.0-36 1.5/2.0 mL 11 x 37.5 15,000 Hole angle : ∠30° Micro-filter tube 115.7 29,104 Max. - Page 31 7. Rotors and Accessories Fixed Angle Rotors for Supra Series (2) Tube Bore Ø x L Capacity Required Max. RPM (rpm) Rotor (mm) Bottom Adaptor Max. RCF (xg) Radius (mm) Type A50c-6 Hole angle : ∠23° Max. Capacity : 6 x 50 mL conical 50 mL 30 x 108.6 15,000...
- Page 32 RECYCLABLE...
