Micro Audio System
Contents
.................................................1-1 to 1-10
2 Laser Beam Safety Precautions......................................... 2-1
3 Important Safety Precautions .................................. 3-1 to 3-2
4 Safety Check After Servicing ............................................. 4-1
5 Safety Information General Notes & Lead Free
Requirements .................................................................... 5-1
7 Direction of Use ....................................................... 7-1 to 7-4
8 Cabinet Disassembly Instructions ........................... 8-1 to 8-2
9 Troubleshooting ....................................................... 9-1 to 9-2
10 Block Diagram .................................................................10-1
11 Wiring Diagram ...............................................................11-1
12 Headphone Board
Circuit Diagram ....................................................12-1
Layout Diagram ...................................................12-1
13 Display Board
Circuit Diagram ................................................12-2
Layout Diagram ...............................................12-3
14 Power Board
Circuit Diagram .................................................12-4
Layout Diagram.................................................12-5
© Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Published by Sophie-KM 1135 AVM
Version 1.0
Page
Contents
15 Decoder Board
16 Exploded View...................................................................13-1
17 Revision List .......................................................................14-1
Printed in the Netherlands
MCD2010/12/93/98
Circuit Diagram ......................................... 12-6 to 12-11
Layout Diagram ............................................... 12-12
Feature
Different
Features
RDS
Voltage Selector
ECO Standby
DTS
Subject to modi cation
Page
/12 /93 /98
/10
EN
3141 785 36600
