rev. 1.0 del 03/99
User's Manual
User's Manual
T I Z I A N O 5 6
M E M O R Y
http://www.digicom.it

Advertisement

Table of Contents
loading

Related Manuals for Digicom Tiziano 56 Memory

Summary of Contents for Digicom Tiziano 56 Memory

  • Page 1 1.0 del 03/99 User's Manual User's Manual T I Z I A N O 5 6 M E M O R Y http://www.digicom.it...
  • Page 2 TIZIANO 56 MEMORY Index INDEX PREFACE GENERALITY 1.1. PRODUCT PACKAGE CONTENTS 1.2. PRODUCT FEATURES INSTALLATION 2.1. HARDWARE INSTALLATION Picture 2.1. Desktop version rear panel 2.2. SOFTWARE INSTALLATION 2.2.1. WINDOWS® 95/98/NT4.0 2.2.2. MACINTOSH® - MODEM INSTALLATION FOR ARA OPEN TRANSPORT 2.6 MODEM AT COMMAND SET 3.1.
  • Page 3 The contents of this booklet may be modified without prior permission. Every possible care has been taken in testing and putting together all the documentation contained in this booklet, however Digicom can not take any responsability brought by the use of this booklet.

  • Page 4: Dear Customer

    (RTN). The homologation number is shown on the label under the modem. DEAR CUSTOMER, Your Tiziano 56 Memory complies with the 56Kbps standard according to the ITU-TV.90 regulation for data communication up to 56000 bps. The V.90 standard, like the K56Flex, has an unbalanced connection speed.

  • Page 5: Product Package Contents

    TIZIANO 56 MEMORY Generality 1.1. PRODUCT PACKAGE CONTENTS Tiziano 56 Memory Serial cable Drivers for Windows® 98/95, NT4 (Windows® version only) Drivers for Mac OS (Macintosh® version only) Voice/Data/Fax software for Windows® 98/95, NT4(Windows® version only) Voice/Data/Fax software for Macintosh® (Macintosh® version only) Installation guide 1.2.

  • Page 6: Hardware Installation

    TIZIANO 56 MEMORY Installation INSTALLATION 2.1. HARDWARE INSTALLATION Check the modem is OK after you removed it from the package. Use the universal cable in the package to connect the modem to anyone of the computer serial ports. Connect the modem to the telephone line through the cable supplied.

  • Page 7: Software Installation

    TIZIANO 56 MEMORY Installation Audio Power Input Supply LINE RS232 On/Off Microphone Audio Line Switch Headset output Input Picture 2.1. Desktop version rear panel 2.2. SOFTWARE INSTALLATION WINDOWS® 95/98/NT4.0 Drivers Before starting with the software installation, please read the file Readme.txt on the Floppy Disk or the CD ROM included with the modem package.

  • Page 8: Other Drivers

    TIZIANO 56 MEMORY Installation Follow this procedure to correctly disconnect the protocol: 1. Open the AppleTalk from the Control panel 2. Select "User Mode" from Edit Menu (or command-U) 3. Select "Advanced" and then click OK 4. Click "Options" 5. Select "Inactive" and then click OK 6.
  • Page 9 TIZIANO 56 MEMORY Installation 3. From the window "Install New Modem" put a tick in the box “Don’t detect my modem" and click Next. 4. Click on Disk. 5. In the window "Install from disk": Insert the Floppy disk or the CD ROM in the appropriate drive(A: or CD-Rom reader) and select the unit "Copy manufacturer's files from:"...
  • Page 10 TIZIANO 56 MEMORY Installation 6. From the list select the driver to use (e.g. Digicom Tiziano 56 Memory) and click Next. 7. Select the COM port where your modem is connected, then clik Next and then Finish. Your modem is now installed among the modems Windows® will use for the connections.
  • Page 11 TIZIANO 56 MEMORY Installation 2.2.2. MACINTOSH® - MODEM INSTALLATION FOR ARA OPEN TRANSPORT Be sure you have on your Mac the Open Transport drivers for your modem. Install them by copying the files from the ARA/OT folder (they are on the driver supplied with the modem) into the “System Folder ->...
  • Page 12 TIZIANO 56 MEMORY Installation From the bar menu select PPP and then TCP/IP... In the next window select the PPP protocol in the field "Connect via" The fields concerning the parameters used for the connection in PPP will appear. Eventually insert the parameters supplied by your provider (DNS etc.)

  • Page 13: At Command Set Description

    The default escape sequence is +++. To be valid, the sequence must be followed by an AT command, i.e. "+++AT<CR>". Data Length Digicom's modems can manage the following ASCII code formats: CASE START BIT DATA BIT...
  • Page 14 TIZIANO 56 MEMORY Modem AT Command Set Repeat last command Cause the modem to repeat the last AT command. This command must not be preceded by AT and followed by CR. Dial Command Dial numbers DTMF digits DTMF digits A..D*...
  • Page 15 TIZIANO 56 MEMORY Modem AT Command Set SPEAKER VOLUME Low speaker volume. Medium speaker volume. High speaker volume. SPEAKER CONTROL Speaker disabled. Speaker on until carrier is detected. Speaker always on. Speaker off during dialing and on until carrier is detected.
  • Page 16 TIZIANO 56 MEMORY Modem AT Command Set SHORT EXTENDED SHORT EXTENDED NO ANSWER CARRIER 28800 CONNECT 2400 CARRIER 31200 CONNECT 4800 CARRIER 33600 CONNECT 9600 COMPRESSION: CLASS 5 CONNECT 7200 COMPRESSION: V42 bis CONNECT 12000 COMPRESSION: NONE CONNECT 14400 PROTOCOL: NONE...
  • Page 17 TIZIANO 56 MEMORY Modem AT Command Set DIAL TONE DETECTION No control on dial tone. Busy and dial tone are ignored. Dial tone detected. Busy tone detected. All messages enabled. RESET AND LOAD USER PROFILE Reset and load user profile 0.
  • Page 18 TIZIANO 56 MEMORY Modem AT Command Set Some configuration examples Modem set up with automode enabled and connection speed between 300 bps and 56000 bps: AT+MS=12,1,300,56000 The modem will connect at the maximum speed available if the interface speed is equal or higher than the max rate (56.000bps).

  • Page 19: Guard Tone

    TIZIANO 56 MEMORY Modem AT Command Set Fallback/fallforward enabled. Enabled only in error corrector or buffer mode. AT%L DISPLAY RECEIVE LEVEL IN DBM Returns a value which indicates the received signal level. Example 009 = -9 dBm, 043 = -43 dBm.
  • Page 20 TIZIANO 56 MEMORY Modem AT Command Set AT&Q OPERATING MODE SELECTION &Q0 Asyncronous direct mode. &Q5 Operations with error corrector. It is automatically selected with \N command (different from 0 and 1). &Q6 Asynchronous with buffer enabled (AT/N0). AT&R C106 &R0...
  • Page 21 TIZIANO 56 MEMORY Modem AT Command Set Selects LAPM error corrector mode. Failure to make an LAPM error-correction connection results in the modem hanging up. Forces &Q5. Selects MNP error corrector mode. Failure to make an MNP error- correction connection results in the modem hanging up. Forces &Q5.

  • Page 22: Voice At Commands

    TIZIANO 56 MEMORY Modem AT Command Set 3.2. VOICE AT COMMANDS AT#BDR Select Baud Rate (No Speed Sensing) Select baud rate specified by n parameter n=0..48 baud rate=n*2400 bps AT#CLS Select DATA-FAX/VOICE/AUDIO #CLS=0 Select Data mode #CLS=1 Select Fax mode...
  • Page 23 TIZIANO 56 MEMORY Modem AT Command Set AT#VSS Enables the SILENCE detection #VSS=0 Disables the silence detection #VSS=1 Enables the silence detection (minimum sensitivity) #VSS=2 Enables the silence detection (medium sensitivity) #VSS=3 Enables the silence detection (maximum sensitivity) AT#VTS Tones generation...
  • Page 24 TIZIANO 56 MEMORY Modem AT Command Set 3.3. SPEAKERPHONE AT COMMANDS Tiziano 56 Memory can work also in full-duplex speakerphone mode. To modify the values setting in Speakerphone mode, use the following command: AT#SPK at#SPK =mute, spkr, mic at#spK =1,10, 1...
  • Page 25 TIZIANO 56 MEMORY Modem AT Command Set 3.4. S REGISTERS REG. RANGE UNIT DEF. DESCRIPTION SAVED 0,2-5 Ring Ring to answer on 0-255 Ring Ring count 0-255 ASCII Escape character 0-127 ASCII Carriage return character 0-127 ASCII Line Feed character...

  • Page 26: Connection Messages

    TIZIANO 56 MEMORY Modem AT Command Set ATS91 ADJUST TRANSMISSION LEVEL IN SWITCHED LINE 10-15 dB This register checks the modem transmission level in switched line Default=15 ATS92 ADJUST TRANSMISSION LEVEL IN FAX MODE 10-15 dB This register checks the modem transmission level in fax mode.

  • Page 27: Main Features

    AT$M0 before you send any other AT command. Tiziano 56 Memory can also connect at 64 Kbps over the ISDN line and at the same time it can use the second channel for the answering machine. You can surf the Internet via ISDN and simultaneously receive faxes and voice messages by using the memory section of the second ISDN channel.
  • Page 28 On the front panel there are some leds that indicate the status of the interface criteria of Tiziano 56 Memory. The PWR led indicates the status of the memory function. This led can change color (green, red, orange) and lighten in different ways.
  • Page 29 AT$M0 and AT%Px of the activated message and listen to the message. 9) Tiziano 56 Memory is now ready to be used with the Memory function and the customized message. NOTE: This procedure allows you to record one welcome message at a time. If you want to record the second welcome message, you have to repeat the procedure.
  • Page 30 DOWNLOAD OF VOICE MESSAGES AND FAX When some voice messages or faxes are in the memory, the PWR led is red continuous. You can download the messages stored by connecting Tiziano 56 Memory to the computer and activating the voice/fax application supplied with the modem.
  • Page 31 Tiziano 56 Memory Performance when Computer is Off AT%M Memory Option It allows to select different functionings of the memory mode. AT%M0 Answering machine and fax disabled AT%M1 Fax enabled AT%M2 Answering machine enabled AT%M3 Answering machine and fax enabled...

  • Page 32: Warranty Clauses

    Declaration CE of Conformity DECLARATION OF CONFORMITY Digicom S.p.A. via Alessandro Volta 39 21010 Cardano al Campo -Varese- declares that this product satisfies the basic requirements of Electromagnetic Compatibility and Safety of the below indicated Directive: 89/336/CEE of 3 may 1989 with subsequent modifications (Directive 92/ 31/CEE of april 28, 1992, Directive 93/68/CEE of july 22,1993 and Directive 93/97/CEE of 29 october 1993).
