Summary of Contents for Makita DFJ216
- Page 1 INSTRUCTION MANUAL Cordless Fan Jacket DFJ216 DFJ416 Read before use.
-
Page 2: Specifications
Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. SPECIFICATIONS Model: DFJ216 DFJ416 Material Outer Polyester 100% Lining... -
Page 3: Intended Use
Save all warnings and instruc- Symbols tions for future reference. Some of the following symbols are used for the product. Never use the fan jacket when temperature Be sure to understand their meaning before use. reach more than 50°C (122°F). Also avoid use in high humidity. -
Page 4: Electrical Safety
Charging improperly or at temperatures CAUTION: Only use genuine Makita batteries. outside the specified range may damage the Use of non-genuine Makita batteries, or batteries that battery and increase the risk of fire. have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. 4 ENGLISH... -
Page 5: Parts Description
PARTS DESCRIPTION Battery holder and fan unit Battery holder (10.8 V - Battery holder (14.4 V Fan unit Power cable 12 V max) /18 V) (optional accessory) (optional accessory) Model DFJ216 Battery pocket Mesh pocket for ice pack 5 ENGLISH... -
Page 6: Installation
Model DFJ416 Loop for name badge Battery pocket Detachable sleeve Loop for arm badge Shoulder pad To install the battery cartridge, align the tongue on the INSTALLATION battery cartridge with the groove in the housing and slip it into place. Insert the battery cartridge all the way until it locks in place with a small click. - Page 7 Turn the ring counterclockwise while lifting the Attaching the battery holder hook on it. Remove the ring when the mark on the ring aligns with the slot on the fan unit. You can hang the battery holder on your waist belt. To prevent the battery holder from dropping acciden- tally, attach a strap using the strap hole and secure it.
- Page 8 ► 1 . Battery holder Connect the power cable to the fan units. Support the cable using the cable holder. CAUTION: For model DFJ216 Always use the strip and snap button to secure the fan unit to the jacket. If the fan unit falls, it may cause an injury, or damage to the fan unit.
-
Page 9: Functional Description
When tightening the ring, stop it at the mark near the Indicating the remaining battery slot on the fan unit. After attaching the fan units, cover capacity the filter attachments with filters. Only for battery cartridges with the indicator ► 1 . Mark 2. Slot ► 1 . -
Page 10: Turbo Button
Turbo button Mesh pocket By pressing turbo button on the battery holder, the For DFJ216 only jacket works in turbo mode for quick cooling. Turbo Mesh pockets are provided on the back of the jacket for mode lasts for a minute and then air speed returns to storing ice packs. normal. ► 1 . Mesh pocket ► 1 . Turbo button... -
Page 11: Maintenance
Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Cleaning the fan unit • Use clean cloth to remove dirt, dust, oil, grease etc. - Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885800-223 www.makita.com 20200117...
