OPERATOR'S MANUAL
ARBOR PRESS
MODEL: AP-3R
Baileigh Industrial Holdings LLC
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileigh.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL
HOLDINGS LLC IS PROHIBITED. Baileigh Industrial Holdings LLC, Inc. does not assume and hereby disclaims any
liability for any damage or loss caused by an omission or error in this Operator's Manual, resulting from accident,
negligence, or other occurrence.
Rev. 05/2019
© 2019 Baileigh Industrial Holdings LLC

Advertisement

Table of Contents
loading

Related Manuals for Baileigh AP-3R

Summary of Contents for Baileigh AP-3R

  • Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL HOLDINGS LLC IS PROHIBITED. Baileigh Industrial Holdings LLC, Inc. does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurrence.

  • Page 2: Table Of Contents

    Table of Contents THANK YOU & WARRANTY ..................1 INTRODUCTION ......................3 GENERAL NOTES ......................3 SAFETY INSTRUCTIONS ....................4 SAFETY PRECAUTIONS ....................6 Dear Valued Customer: ....................6 TECHNICAL SPECIFICATIONS ..................8 TECHNICAL SUPPORT ....................8 UNPACKING AND CHECKING CONTENTS ..............9 Cleaning ........................

  • Page 3: Thank You & Warranty

    THANK YOU & WARRANTY Thank you for your purchase of a machine from Baileigh Industrial Holdings LLC. We hope that you find it productive and useful to you for a long time to come. Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or...
  • Page 4 We apologize for any discrepancies that may occur. Baileigh Industrial Holdings LLC reserves the right to make any and all changes deemed necessary in the course of business including but not limited to pricing, product specifications, quantities, and product availability.

  • Page 5: Introduction

    INTRODUCTION The quality and reliability of the components assembled on a Baileigh Industrial Holdings LLC machine guarantee near perfect functioning, free from problems, even under the most demanding working conditions. However, if a situation arises, refer to the manual first. If a solution cannot be found, contact the distributor where you purchased our product.

  • Page 6: Safety Instructions

    IMPORTANT PLEASE READ THIS OPERATORS MANUAL CAREFULLY It contains important safety information, instructions, and necessary operating procedures. The continual observance of these procedures will help increase your production and extend the life of the equipment. SAFETY INSTRUCTIONS LEARN TO RECOGNIZE SAFETY INFORMATION This is the safety alert symbol.
  • Page 7 SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others. PROTECT EYES Wear safety glasses or suitable eye protection when working on or around machinery. PROTECT AGAINST NOISE Prolonged exposure to loud noise can cause impairment or loss of hearing.

  • Page 8: Safety Precautions

    Baileigh does not recommend or endorse making any modifications or alterations to a Baileigh machine. Modifications or alterations to a machine may pose a substantial risk of injury to the operator or others and may do substantial damage to the machine.
  • Page 9 7. Dressing material edges. Always chamfer and deburr all sharp edges. 8. Do not force tool. Your machine will do a better and safer job if used as intended. DO NOT use inappropriate attachments in an attempt to exceed the machines rated capacity. 9.

  • Page 10: Technical Specifications

    (other than die sets and blades). For specific application needs or future machine purchases contact the Sales Department at: sales@baileigh.com, Phone: 920.684.4990, or Fax: 920.684.3944. Note: The photos and illustrations used in this manual are representative only and may not depict the actual color, labeling or accessories and may be intended to illustrate technique only.

  • Page 11: Unpacking And Checking Contents

    UNPACKING AND CHECKING CONTENTS Your Baileigh machine is shipped complete. Separate all parts from the packing material and check each item carefully. Make certain all items are accounted for before discarding any packing material. WARNING: SUFFOCATION HAZARD! Immediately discard any plastic bags and packing materials to eliminate choking and suffocation hazards to children and animals.

  • Page 12: Transporting And Lifting

    TRANSPORTING AND LIFTING NOTICE: Lifting and carrying operations should be carried out by skilled workers, such as a truck operator, crane operator, etc. If a crane is used to lift the machine, attach the lifting chain carefully, making sure the machine is well balanced. Follow these guidelines when lifting with truck or trolley: •...

  • Page 13: Anchoring The Machine

    4” (102mm) thick. 6” (153mm) minimum is preferred. .50" (12.7mm) If you intend to mount the Baileigh machine on a workbench be aware of the following: • Overall weight of the machine. • Weight of material being processed.

  • Page 14: Assembly And Set Up

    ASSEMBLY AND SET UP Your Baileigh AP-3R Arbor Press consists of the following loose parts. 1. Press Base 2. Gear Shaft 3. Long Handle 4. Hand Wheel 5. Ratchet Arm...
  • Page 15 6. Assemble the gear shaft (#2) into the hole in the base as shown in (fig.1). The steel ram may have to slide up or down slightly to mesh with the spline of the shaft. Note: Locking collar has been removed from shaft and will be re-installed in step 3.

  • Page 16: Adjustments

    9. To complete the assembly, insert the long handle (#3) into the hole of the ratchet arm (#5). ADJUSTMENTS 1. Bolts (A) can be used to control side play. When properly adjusted use the jam nuts to hold in place. DO NOT figure 4 OVERTIGHTEN.

  • Page 17: Operation And Maintenance

    3. Rotate the 4 position die plate (#9) to choose a suitable width slot to accommodate your application. 4. Lubricate the Baileigh AP-3R Arbor Press daily with a good quality EP grease. This will help ensure the press has a long life in your shop.

  • Page 18: Parts Identification Drawing

    PARTS IDENTIFICATION DRAWING...

  • Page 19: Parts List

    Parts List Item Part No. Description Qty. AP3R-1 Press Base AP3R-2 Gear Shaft AP3R-2-1 Rachet Gear AP3R-3 Long Handle AP3R-4 Hand Wheel AP3R-5 Ratchet Arm AP3R-6 Ram 1.5” x 1.5” (38mm x 38mm) AP3R-7 Pressure Plate AP3R-8 Cover AP3R-Die Pate 4 Position Bottom Die Plate AP3R-10 Roll Pin...
  • Page 20 BAILEIGH INDUSTRIAL HOLDINGS LLC 1625 D , WI 54220 UFEK RIVE ANITOWOC : 920. 684. 4990 F : 920. 684. 3944 HONE www.baileigh.com BAILEIGH INDUSTRIAL HOLDINGS LTD. U WIFT OINT WIFT ALLEY NDUSTRIAL STATE UGBY , CV21 1QH U IDLANDS...
