AUTODOME IP starlight 7000i
NDP‑7512‑Z30 │ NDP‑7512‑Z30K
en
Installation Manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch AUTODOME IP starlight 7000i

Summary of Contents for Bosch AUTODOME IP starlight 7000i

  • Page 1 AUTODOME IP starlight 7000i NDP‑7512‑Z30 │ NDP‑7512‑Z30K Installation Manual...

  • Page 3: Table Of Contents

    AUTODOME IP starlight 7000i Table of contents | en Table of contents Safety EN About this Manual Legal Information Safety Precautions Important Safety Instructions Important Notices Connection in Applications Customer Support and Service Unpacking Parts List Tools Required Product description...
  • Page 4 | Table of contents AUTODOME IP starlight 7000i Maintenance Technical data Support services and Bosch Academy 2021-03 | 1.2 | Bosch Security Systems Installation Manual...

  • Page 5: Safety En

    Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.
  • Page 6 | Safety EN AUTODOME IP starlight 7000i Object and liquid entry - Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electrical shock.
  • Page 7 16. Attachments, changes or modifications - Only use attachments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.
  • Page 8 | Safety EN AUTODOME IP starlight 7000i If a power adapter supplies power to the camera, you must ground the adapter properly. 2021-03 | 1.2 | Bosch Security Systems Installation Manual...

  • Page 9: Important Notices

    Camera signal - Protect the cable with a primary protector if the camera signal is beyond 140 feet, in accordance with NEC800 (CEC Section 60). Environmental statement - Bosch has a strong commitment towards the environment. This device has been designed to respect the environment as much as possible.
  • Page 10 | Safety EN AUTODOME IP starlight 7000i Servicing - Do not attempt to service this device yourself. Refer all servicing to qualified service personnel. This device has no user-serviceable parts. Notice! This is a class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures.

  • Page 11: Connection In Applications

    High Power-over-Ethernet (High PoE): This unit can by powered via High PoE. To power the unit this way, use only approved High PoE devices - those offered or recommended by Bosch. High PoE can be connected at the same time as a 24 VAC power supply. If auxiliary power (24 VAC to camera and to heater) and High PoE are applied simultaneously, the camera will selects auxiliary input (24 VAC) as the primary power source.

  • Page 12: Customer Support And Service

    | Safety EN AUTODOME IP starlight 7000i Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. USA and Canada Telephone: 800-289-0096, option 5 Fax: 800-366-1329 Email: repair@us.bosch.com...

  • Page 13: Unpacking

    Sales or Customer Service Representative from Bosch Security Systems. – Do not use this product if any component appears to be damaged. Please contact Bosch Security Systems in the event of damaged goods. – The original packing carton (if undamaged) is the safest container in which to transport the unit and must be used if returning the unit for service.
  • Page 14 Barrel connector – Roof parapet Mount – Pipe Mount Only if installing a fiber optic model The following table lists additional products, sold separately by Bosch or other manufacturers, necessary to install AUTODOME cameras. Quantity Product Part Number Size SD card...
  • Page 15 AUTODOME IP starlight 7000i Unpacking | en Quantity Product Part Number Size Studs, stainless steel, corrosion- (user-supplied) 6.4 mm (0.25 in.) resistant, to 8 mm (5/16 in.) Bosch Security Systems 2021-03 | 1.2 | Installation Manual...

  • Page 16: Product Description

    (HD) 1080p video. Easy to install, the camera is available in either a field-proven, outdoor pendant housing or an indoor, in-ceiling housing. The camera has been designed for quick and easy installation, a key feature from Bosch IP video security products.
  • Page 17 AUTODOME IP starlight 7000i Product description | en The following table lists the mandatory parts, sold separately, that you will need for attaching a Pendant to the Roof Parapet and Pipe mount packages: Mounting Options Part Numbers Parapet (Roof) Mount with one of the following Power Supply Boxes: VGA-ROOF-MOUNT –...

  • Page 18: Pre-Installation Checklist

    (not supplied). Warning! To minimize the potential for corrosion on the housing, use only Bosch hardware and mounts. See number 5 (Installation in a corrosive environment) in the section Recommended Use of Your Camera for more information.

  • Page 19: Stabilization

    Cameras attached to a pole, roof, or to a bridge are especially vulnerable. Bosch offers the following recommendations to stabilize an AUTODOME camera and to decrease the affects of vibration on transmitted images, privacy masks, and Intelligent Tracking.
  • Page 20 | Pre-installation Checklist AUTODOME IP starlight 7000i 12 ft (3.66 m) 8 ft (2.44 m) 6 ft (1.83 m) Guidelines for Implementing Intelligent Tracking Factors such as the viewing angle and unwanted motion (from trees, for example) may interfere with Intelligent Tracking operation. Use the following recommendations to ensure smooth Intelligent Tracking operation: –...

  • Page 21: Preparing The Bubble

    Notice! To avoid excessive moisture saturation inside the housing, limit the amount of time that the bubble is disconnected from the housing. Bosch recommends that the bubble be removed from the housing for no more than five (5) minutes. Remove the bubble from a pendant housing Using both hands, apply a firm counterclockwise (looking up at the dome) rotational force on the pendant bubble assembly to set the bubble latch.

  • Page 22: Optional) Installing An Sd Card

    | (Optional) Installing an SD Card AUTODOME IP starlight 7000i (Optional) Installing an SD Card The camera can accept a customer-supplied SDHC or SDXC memory card (hereafter referred to as “SD card”) for local storage. (The camera will not accept MicroSD cards.) Using an SD card is optional.

  • Page 23: Replacing The Trim Ring And Bubble

    AUTODOME IP starlight 7000i Replacing the trim ring and bubble | en Replacing the trim ring and bubble Replace the bubble in a pendant housing Insert the bubble and trim ring assembly into the pendant housing. Rotate the assembly clockwise until it locks. The latch mechanism makes a click when it locks.

  • Page 24: Mount Power Supply Box (Wall, Mast (Pole), And Corner Mounts)

    100-380 mm (4-15 in.). You must use a banding tool (sold separately) for a mast or pole installation. Follow the instructions provided with the banding tool to securely mount the Mast Plate to the pole. Contact your Bosch Sales Representative to order Banding Tool P/N TC9311PM3T.
  • Page 25 AUTODOME IP starlight 7000i Mount Power Supply Box (Wall, Mast (Pole), and Corner Mounts) | en Warning! For units intended to be installed outdoors: All wiring (power and I/O cabling) connecting to the unit must be routed separately inside different permanently earthed metal conduits (not supplied).

  • Page 26: Installing The Pendant Arm Wall, Corner, And Mast (Pole) Mounts

    | Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts AUTODOME IP starlight 7000i Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts Description This chapter details how to install an AUTODOME to a Wall, Corner, or Mast (pole) mount. Any differences to the installation between these two mounting systems are noted.
  • Page 27 AUTODOME IP starlight 7000i Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts | en WHITE BROWN P102 ORANGE GREEN WHITE BROWN ORANGE P103 GREEN YELLOW BLUE P104 Figure 9.1: Alarm and relay connectors 4-pin Alarm 6-pin Alarm In 7-pin Relay Connector (P104)
  • Page 28 Series cameras: If you are mounting an AUTODOME 7000 Series camera to an ARM mount that was wired for an earlier model of Bosch AUTODOME, you must either re-wire cable 8 to be audio input and output, or disconnected it from the power supply.
  • Page 29 AUTODOME IP starlight 7000i Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts | en Fuse Specifications Volts XF101 Mains XF102 Camera XF103 Heater 24 V T 5.0 A T 2.0 A T 3.15 A 115 V T 1.6 A T 2.0 A...

  • Page 30: Route Power Through Intermediate Power Supply Box

    | Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts AUTODOME IP starlight 7000i Route Power through Intermediate Power Supply Box You may route the main power supply through a VG4-PSU1 (120 V transformer) or through a VG4-PSU2 (230 V transformer) Power Supply Box before connecting the power to a VG4-PA0 (24 V, no transformer) Power Supply Box.
  • Page 31 AUTODOME IP starlight 7000i Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts | en To properly wire the incoming high voltage and the outgoing low voltage lines, refer to this table: Connector Pin 1 Pin 2 Pin 3...
  • Page 32 | Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts AUTODOME IP starlight 7000i Warning! Ensure that you connect the outgoing power supply wires to the P107 heater connectors (HN and HL). The heater power (XF103) fuse can handle a higher amperage (3.15 A) than the camera power (XF102) fuse (2.0 A).

  • Page 33: Attach Pendant Arm To Power Supply Box

    AUTODOME IP starlight 7000i Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts | en Attach Pendant Arm to Power Supply Box The bottom hinge pin of the Pendant Arm is provided with a Hinge Pin Stop to hold the hinge open while attaching the arm to the Power Supply Box.

  • Page 34: Make Connections In The Power Supply Box

    | Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts AUTODOME IP starlight 7000i Make Connections in the Power Supply Box 1 2 3 Figure 9.8: Pendant Arm connections to Power Supply Box Attach the earth ground wire (item 1 in the illustration above) to the grounding screw on the left side of the power box.

  • Page 35: Installing The Vga-Pend-Wplate

    Follow the instructions provided with the banding tool to securely mount the Mast Plate to the pole. Contact your Bosch Sales Representative to order Banding Tool P/N TC9311PM3T.
  • Page 36 | Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts AUTODOME IP starlight 7000i Attach the Pendant Arm to the Mounting Plate The bottom hinge pin of the Pendant Arm is provided with a Hinge Pin Stop to hold the hinge open while attaching the arm to the Mounting Plate.
  • Page 37 AUTODOME IP starlight 7000i Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts | en 24 VAC Power (red) Alarm Outputs (white) Relay Contacts (yellow) Alarm Inputs (gray) Coax Video (black) Serial Communications (green) (Not applicable for AUTODOME Used for Audio Input/Output in 7000 Series cameras) AUTODOME 7000 Series.

  • Page 38: Attach Pendant To Arm And Tighten

    | Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts AUTODOME IP starlight 7000i Attach the grounding spade from the 5-pin mating connector to the other spade terminal inside the mounting plate. Attach the 5-pin Power In mating connector to the 24 VAC Power cable (cable 2) connected to the pendant.
  • Page 39 AUTODOME IP starlight 7000i Installing the Pendant Arm Wall, Corner, and Mast (Pole) Mounts | en Figure 9.12: Attach Pendant to Arm Tilt up. Hook and drop. Recessed Hinge Pin 2b Dome Connector Rotate down to engage dome connector. Tighten the two (2) mounting screws to a minimum torque of 10-12 N-m (90-105 in.-lbs).

  • Page 40: Installing The Roof Parapet And Pipe Mounts

    The VGA-ROOF-MOUNT is a stationary mount intended for rooftop parapet vertical walls. It is made of light weight aluminum with a corrosion-resistant finish and is used for all Bosch AUTODOME cameras up to a rated load of 29 kg (64 lb). This mount can be fitted to the inside or outside of parapet walls and can swivel for ease of positioning and for servicing the camera.
  • Page 41 AUTODOME IP starlight 7000i Installing the Roof Parapet and Pipe Mounts | en J102 P101 (LED) LINE NC NEUT P106 P105 GND TXD RXD C+ C- GND TXD RXD C+ C- Figure 10.1: VG4-A-PSU1 or VG4-A-PSU2 Power Supply Box 120 VAC/230 VAC Power In...
  • Page 42 | Installing the Roof Parapet and Pipe Mounts AUTODOME IP starlight 7000i Notice! The Power Supply Box with transformer comes with a barrier that separates the high voltage side on the left from the low voltage 24 VAC side on the right.
  • Page 43 AUTODOME IP starlight 7000i Installing the Roof Parapet and Pipe Mounts | en J102 P101 (LED) 24V NC P106 GND TXD RXD C+ C- Figure 10.2: Fiber Optic Ethernet Module installed 1 RJ45 Ethernet socket 2 Port for SFP module (sold separately)
  • Page 44 | Installing the Roof Parapet and Pipe Mounts AUTODOME IP starlight 7000i Power Supply Box Connections The following figure is a detailed illustration of the Roof or Pipe Mount Power Supply Box, which includes the fuse specifications. J102 J102...

  • Page 45: Attach Cover Door To Power Supply Box

    AUTODOME IP starlight 7000i Installing the Roof Parapet and Pipe Mounts | en Connector Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 P101 115/230 VAC or Line Neutral 24 VAC Power In P107 24 VAC Power to...

  • Page 46: Installing The Vg4-A-9543 Pipe Mount

    | Installing the Roof Parapet and Pipe Mounts AUTODOME IP starlight 7000i Notice! After all wiring is complete, close the cover door and tighten the two (2) captive screws on the cover door to 10-12 N-m (90-105 in.-lbs) to ensure the Power Supply Box is watertight.

  • Page 47: Wire The Pipe Interface Board

    AUTODOME IP starlight 7000i Installing the Roof Parapet and Pipe Mounts | en Apply the supplied thread sealant to the threads on the Pipe. Make sure all surfaces are clean and dry. Apply a bead of sealant completely around the leading threads of the male fitting.
  • Page 48 | Installing the Roof Parapet and Pipe Mounts AUTODOME IP starlight 7000i Ref. Description Connector Wire Pin Description Gauge Pipe Interface Module Video Coax In J102 6-pin Connector P103 Alarms In (3-7) 4-pin Connector P102 Alarms Out (1-3) 100 Ω Resistor...
  • Page 49 AUTODOME IP starlight 7000i Installing the Roof Parapet and Pipe Mounts | en Ref. Description Connector Wire Pin Description Gauge Dome 24 VAC Heater Power P107 Heater 24 VAC 18-14 Heater 24 VAC RJ45 Ethernet J101 To camera The Pipe Interface Board contains all of the connectors for control, data, image, and power wires.
  • Page 50 | Installing the Roof Parapet and Pipe Mounts AUTODOME IP starlight 7000i Pin Description Description Description Alarm Out 1 Alarm in 3 Alarm Out 4 Normally Open Alarm Out 2 Alarm in 4 Alarm Out 4 COM Alarm Out 3...

  • Page 51: Attach Pendant To Pipe And Tighten

    AUTODOME IP starlight 7000i Installing the Roof Parapet and Pipe Mounts | en 10.6 Attach Pendant to Pipe and Tighten Before attaching the Pendant, visually inspect the Pendant dome and the Interface Board connectors for any blocked pin holes and bent pins.

  • Page 52: Make Connections In The Power Supply Box

    | Installing the Roof Parapet and Pipe Mounts AUTODOME IP starlight 7000i Caution! You must tighten the two mounting screws to a minimum torque of 10-12 N-m (90‑105 in.-lbs) to ensure a proper seal between the arm and the housing.

  • Page 53: Finalizing Installation

    AUTODOME IP starlight 7000i Finalizing installation | en Finalizing installation Remove the plastic on the bubble After you complete all other installation steps, remove the plastic material that is protection for the bubble. Bosch Security Systems 2021-03 | 1.2 |...

  • Page 54: Replacing A Pendant Bubble

    | Replacing a Pendant Bubble AUTODOME IP starlight 7000i Replacing a Pendant Bubble 1. Using both hands, apply a firm counterclockwise (looking up at the dome) rotational force on the pendant bubble assembly to set the bubble latch. 2. Insert a small (2 mm) straight blade screw driver into the release opening in the bubble trim ring to release the lock, and then remove the screwdriver.

  • Page 55: Connection

    IP Connection Network Switch Computer Notice! You can also use the Bosch Video Client software application to configure the network settings for an AUTODOME 7000 Series camera. Go to www.boschsecurity.com to download the Configuration Manager software and Operating Manual. 13.2...

  • Page 56: Ethernet Connections

    IP network using the built-in Web server. In addition, power can be supplied over the Ethernet cable using the Bosch High PoE 60W midspan (sold separately). Power can also be supplied over the Ethernet cable to in-ceiling models and indoor/outdoor pendant models used in indoor applications (where the heater is not powered) using PoE+ PSEs (midspan switches) compliant with the IEEE 802.3at, class 4 standard.

  • Page 57: Fiber Optic Ethernet Media Converter (Optional)

    100 m (328 ft) Bandwidth 10 Base-T/100 Base-TX High PoE (required for pendants in outdoor applications that use Use the Bosch High PoE 60W midspan heaters) (sold separately). PoE+ (only for indoor models or indoor applications for pendant model IEEE 802.3at, class 4 standard...

  • Page 58: Alarms And Relay Connections

    | Connection AUTODOME IP starlight 7000i 13.5 Alarms and Relay Connections Alarm Inputs The camera provides seven alarm inputs. Each input can be activated by dry contact devices such as pressure pads, passive infra-red detectors, door contacts, and similar devices. The table below summarizes the size and distance wires.
  • Page 59 AUTODOME IP starlight 7000i Connection | en AUTODOME Programmed N.O.S. Contact Alarm Condition Open Normal Closed Alarm Cut or break Tamper Configuring a Normally Closed Supervised Alarm Install a 2.2 K end-of-line resistor in the alarm circuit. Connect the alarm wires to input 1 or 2 (pin 5 or 6) and to the ground (pin 7) at the camera.
  • Page 60 | Connection AUTODOME IP starlight 7000i Alarm Inputs 3 to 7 Ground From Configuration, select Interfaces > Alarm Inputs, select the number of the Alarm input and finally, select N.O. See the table below for contact and condition details.

  • Page 61: Audio Connections (Optional)

    AUTODOME IP starlight 7000i Connection | en 13.6 Audio Connections (Optional) The camera is capable of receiving line level input signals and transmitting them over a network. It is also capable of receiving audio from the same network and sending it as audio output from the camera.
  • Page 62 | Connection AUTODOME IP starlight 7000i Audio Line Level Output Connections Connect the audio line level input of the audio output device (for example, an amplified speaker or a PC line level input) to the Audio_Out+ (RXD) output terminal.

  • Page 63: Troubleshooting

    If you cannot control the unit after the firmware upgrade, then cycle the power to the unit. If a power reset does not solve the problem, or if Configuration or video management software identifies the unit as “Videojet Generic,” then contact your Bosch Service Center for an RMA for the unit.

  • Page 64: Physical Reset Button

    | Troubleshooting AUTODOME IP starlight 7000i 14.2 Physical reset button Each camera has a hardware reset button. You may need to press the reset button to reset the camera to factory defaults if you encounter the following circumstances: –...
  • Page 65 AUTODOME IP starlight 7000i Troubleshooting | en Bosch Security Systems 2021-03 | 1.2 | Installation Manual...

  • Page 66: Customer Service And Support

    | Troubleshooting AUTODOME IP starlight 7000i 14.3 Customer Service and Support If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. USA and Canada Telephone: 800-289-0096, option 5 Fax: 800-366-1329 Email: repair@us.bosch.com...
  • Page 67 Never scrub the bubble with any abrasive material or cleaners. Bosch recommends cleaning the exterior of the bubble with NOVUS “No. 1” Plastic Clean & Shine (or equivalent), according to manufacturer’s instructions. Refer to www.novuspolish.com...
  • Page 68 | Technical data AUTODOME IP starlight 7000i Technical data For product specifications, see the datasheet for your camera, available on the appropriate product pages of the Online Product Catalog at www.boschsecurity.com. 2021-03 | 1.2 | Bosch Security Systems Installation Manual...
  • Page 69 – Troubleshooting – Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ Bosch Security Systems 2021-03 | 1.2 | Installation Manual...
  • Page 70 | Support services and Bosch Academy AUTODOME IP starlight 7000i 2021-03 | 1.2 | Bosch Security Systems Installation Manual...
  • Page 72 Bosch Sicherheitssysteme GmbH Bosch Security Systems, LLC Robert-Bosch-Ring 5 1706 Hempstead Road 85630 Grasbrunn Lancaster, PA, 17601 Germany www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2021 202103222045...
