August 8, 2017
2018 Civic Type R: PDI Information
AFFECTED VEHICLES
Year
Model
2018
Civic
INTRODUCTION
This bulletin covers the pre-delivery inspection (PDI) of the 2018 Civic Type R. It includes these procedures:
1.
Fuel the Vehicle
2.
Remove the Exterior Protective Coatings
3.
Install the Fuses
4.
Remove the Interior Protective Coverings
5.
Install the Floor Mats
6.
Check the Battery
7.
Install the Body Plugs
To do a PDI on the navigation system, be sure to complete S/B 17-071, 2018 Civic Type R: PDI of the Navigation
System.
CLAIM INFORMATION
Reimbursement Time: 1.4 hours
NOTE: This time includes the PDI of the navigation system.
CUSTOMER INFORMATION: The information in this bulletin is intended for use only by skilled technicians who have the proper tools,
equipment, and training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and
you should not assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this
information applies, contact an authorized Honda automobile dealer.
© 2017 American Honda Motor Co., Inc. – All Rights Reserved
Service Bulletin
Trim Level
Type R Touring
8.
Remove the Front Suspension Height Retainers
9.
Install the Front License Plate Holder
10.
Set the Tire Pressures
11.
Start the TPMS Calibration Process
12.
Do the PCM Idle Learn Procedure
13.
Install the Shift Lock Release Cover
14.
Check/Refresh the SiriusXM
Service
17-070
07127 Version 1
®
Radio Dealer Demo
Page 1 of 9

Advertisement

loading

Related Manuals for Honda Civic Type R 2018

Summary of Contents for Honda Civic Type R 2018

  • Page 1 To determine whether this information applies, contact an authorized Honda automobile dealer. Page 1 of 9 © 2017 American Honda Motor Co., Inc. – All Rights Reserved...
  • Page 2 PDI PROCEDURES Before Starting Review these items: • Perfect Delivery documents, especially the information on battery maintenance and tire pressures • Checklist in the PDI and Final Delivery Checklist Make sure you record the PDI on the appropriate pages of the checklist. The PDI is not done until this bulletin and the checklist are both complete.
  • Page 3 The indicator will switch from blinking to steady when communication is complete. 3. Start the engine by pressing the ENGINE START/STOP button while pressing the clutch pedal. You must start the engine within 10 seconds of touching the remote to the button. Get familiar with the jacking and lift points show below.
  • Page 4 Fuel the Vehicle Fuel this vehicle using only unleaded premium gasoline with an octane rating of 91 or higher. Make sure the No. 18 BACKUP (10 A) fuse is installed before filling up the fuel tank (see “Install the Fuses”). If you do it without it installed, the fuel gauge will take much longer than normal to show an accurate reading.
  • Page 5 Install the Floor Mats Install the floor mats where they belong. Place the driver’s floor mat eyelets over the anchors in the floor, then turn the knobs clockwise to the lock position. Under-Hood (Engine Cold) Check the Battery To ensure long battery life and that the customer gets a fully charged battery, it must be checked at these times: •...
  • Page 6 Remove the Front Suspension Height Retainers To prevent damage to the front spoiler, this vehicle comes shipped with plastic retainers fitted into the front suspension. Be sure to remove and discard them. Vehicle Exterior (Vehicle Lowered to Half-Height) Install the Front License Plate Holder If state regulations require the use of a front license plate, install the holder as shown: Vehicle Exterior (Vehicle Lowered to Ground) Set the Tire Pressures...
  • Page 7 Start the TPMS Calibration Process This vehicle has an indirect TPMS. Unlike other systems that directly measure air pressure, an indirect TPMS uses the VSA wheel speed sensors to monitor and compare tire characteristics while driving and determine when one or more tires are significantly underinflated.
  • Page 8 4. When initialization is complete, this screen appears. Select OK. NOTE: Selecting OK is optional. The screen will change on its own. 5. With the transmission in Neutral, turn the ignition to ON. 6. On the display, select HOME, then Settings. 7.
  • Page 9 Vehicle Interior Install the Shift Lock Release Cover Install the shift lock release cover as shown. ® Check/Refresh the SiriusXM Radio Dealer Demo Service The audio system comes from the factory activated with the SirusXM Radio dealer demo service. Once you install the No.
