User's Guide (Basic Operations)
• Be sure to read the "Safety Precautions" on page E-2 and "Operating Precautions" on page
E-6 before trying to use this projector.
• This manual covers only basic operations, including how to set up the projector, how to
connect a computer or video device to the projector, and basic projector operations. For more
detailed information, see the User's Guide (UsersGuide_English.pdf) on the CD-ROM that
comes with the projector.
Contents
Safety Precautions .....................................E-2
Operating Precautions ...............................E-6
Lamp Handling Precautions ...................... E-6
Lamp Replacement Precautions ............... E-6
Other Precautions ..................................... E-7
Unpacking ...................................................E-9
General Guide ...........................................E-10
Getting Ready ...........................................E-12
Setting Up the Projector .......................... E-12
Setup Precautions ................................... E-13
Turning On the Projector ......................... E-16
Turning Off the Projector ......................... E-18
• DLP is a registered trademark of Texas Instruments Incorporated of the United States.
• Microsoft, Windows, Windows Vista, and PowerPoint are registered trademarks or trademarks
of Microsoft Corporation in the United States and other countries.
• HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
• Apple and Macintosh are registered trademarks of Apple Inc. of the United States.
• Adobe and Reader are registered trademarks of Adobe Systems Incorporated.
• XGA is a registered trademark of IBM Corporation of the United States.
• Other company and product names may be registered trademarks or trademarks of their
respective owners.
• The contents of this User's Guide are subject to change without notice.
• Copying of this manual, either in part or its entirety, is forbidden. You are allowed to use this
manual for your own personal use. Any other use is forbidden without the permission of CASIO
COMPUTER CO., LTD.
• CASIO COMPUTER CO., LTD. shall not be held liable for any lost profits or claims from third
parties arising out of the use of this product or this manual.
• CASIO COMPUTER CO., LTD. shall not be held liable for any loss or lost profits due to loss of
data caused by malfunction or maintenance of this product, or any other reason.
• The sample screens shown in this manual are for illustrative purposes only, and may not be
exactly the same as the screens actually produced by the product.
Projector Basics .......................................E-19
Selecting the Input Source ...................... E-19
Adjusting the Projected Image ................ E-19
Using the Setup Menu..............................E-21
User Maintenance.....................................E-22
Cleaning the Projector............................. E-22
Reattaching the Lens Cover.................... E-22
Replacing the Lamp ................................ E-23
Troubleshooting .......................................E-24
Indicators................................................. E-24
Projector Troubleshooting ....................... E-24
Specifications ...........................................E-28
