Summary of Contents for Harol SL400
- Page 1 InstallatIon & operatIon Manual WInd and sun screen SL400 Art. no. 49013 doors shutters sun protectIon...
-
Page 2: Table Of Contents
InstallatIon and operatIon Manual for WInd and sun screen sl400 Table of ConTenTs 1. IntroductIon 2. GeneraL warnInGS 3. LISt of tooLS requIred 4. InStaLLatIon StepS 4.1. checking and opening the packaging 4.2. checking the contents 4.3. checking the dimensions 4.4. -
Page 3: Introduction
InstallatIon and operatIon Manual for WInd and sun screen sl400 1. InTroduCTIon the SL400 is a wind and sun screen. the screen consists of a box with roll-up system, a fabric, a pull rod and a supporting system mounted at drop distance from the box. at the top, the fabric can be either straight or oblique with a maximum angle of 15°... -
Page 4: List Of Tools Required
InstallatIon and operatIon Manual for WInd and sun screen sl400 Guarantee, terms and conditions • Harol has endeavoured to design and manufacture the SL400 in compliance with the current ce standards. always check that our version complies with your own national standards. -
Page 5: Installation Steps
4.3. Checking the dimensions Measure the length of the box of the SL400. this should be 50 mm smaller than the specified ordered length! the drop can only be checked after the screen has been mounted. 4.4. -
Page 6: Mounting Height Of The Wall Brackets
InstallatIon and operatIon Manual for WInd and sun screen sl400 detach the wheel from the pull rod; this is done by unscrewing the pin with an Sw12 spanner. unscrew the cover on the other side of the pull rod with an Sw5 allen key. Switch around the wheel and cover and tighten the screws again. -
Page 7: Alignment Of The Wall Brackets
InstallatIon and operatIon Manual for WInd and sun screen sl400 4.6. alignment of the wall brackets the two wall brackets must be plumb and level. any irregularities in the mounting surface must be compensated. take the time to make sure the screen is positioned perfectly vertically. -
Page 8: Optional Installation Of A Supporting System For Wall Or Railing Assembly (A2639)
InstallatIon and operatIon Manual for WInd and sun screen sl400 always make sure that the supporting system is mounted perfectly vertically and is correctly anchored. the height of the pull rod depends on the height of the screen. for the locking system the rule of thumb is to have it positioned at half the height. -
Page 9: Dismantling
(see f.1.). never suddenly let go of the fabric and the pull rod! closing the SL400 in an uncontrolled manner can damage the fabric and result in personal injuries! 6.3. -
Page 10: User Info
7. user Info 7.1. basic information Before operating the SL400, you need to have sufficient knowledge of the product. the contents of this manual is a sound basis for a smooth, continuous operation and a long service life of this product. -
Page 11: Terms Of Use
7.4. Maintenance to guarantee trouble-free use of the SL400 it is prudent to regularly maintain and inspect the screen, at least once a year. check for signs of wear or damage to the fabric or frame. In the case of wear or damage, your installer is the designated person to carry out these repairs. -
Page 12: Troubleshooting
InstallatIon and operatIon Manual for WInd and sun screen sl400 8. TroublesHooTInG nature of tHe fauLt cauSe SoLutIon pull rod does not fit tightly the fabric does not roll up pull out the pull rod to fully against the box in the evenly. - Page 13 Wij, Harol NV, verklaren geheel onder eigen verantwoordelijkheid dat de producten Screens, type SC700, SC800 en We, Harol NV, declare fully on our own responsibility that the products uitvalschermen, type US701, US702 en wind-zonnescherm SL400 Screens, type SC700, SC800, SC900 and drop arm awnings, type...
-
Page 14: Service Log
Technical assistance: (name, address, telephone number) SERVICE-LOG BOOK This proof book contains technical references and records of installation, maintenance, repairs and alterations carried out and must be made available for any inspections by authorised bodies. Customer: (name, address and reference persoon) Description of the solar protection: (model, type) Identifi... - Page 15 Date Description of work Installer’s Customer’s (Installation, start-up, adjustments, check on signature signature safety devices, repairs, alterations, ...) 09/12 | 15...
- Page 16 1 = wind-force 4 Bft. = 27 km/h max. permitted SC800 SC900 SC700 SL400 / US702 US701 until a wind resistance class of 0 = wind-force ≤ 3 Bft. = ≤ 20 km/h max. permitted...
- Page 17 1 = wind-force 4 Bft. = 27 km/h max. permitted SC800 SC900 SC700 SL400 / US702 US701 until a wind resistance class of 0 = wind-force ≤ 3 Bft. = ≤ 20 km/h max. permitted...
