Black & Decker ScumBuster XTREME S700 Instruction Manual

INSTRUCTION MANUAL
T
T
HANK YOU FOR CHOOSING
HANK YOU FOR CHOOSING
G G .B .B
O O T T O O WWW WWW LACKAND LACKAND
T T O O REGISTER REGISTER
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON PLEASE CALL
1-800-544-6986
BEFORE YOU CALL, HAVE THE CATALOG No. AND DATE CODE AVAILABLE. IN MOST CASES, A
BLACK & DECKER REPRESENTATIVE CAN RESOLVE THE PROBLEM OVER THE PHONE. IF YOU HAVE A
SUGGESTION OR COMMENT, GIVE US A CALL. YOUR FEEDBACK IS VITAL TO BLACK & DECKER.
Key Information You Should Know
• When immersing scrubber in water, DO NOT cover the unit with more
than 3 feet (1 meter) of water. Do not leave the Scrubber immersed for
more than 30 minutes.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CONSERVER LE PRÉSENT GUIDE À TITRE DE RÉFÉRENCE.
VEA EL ESPAÑOL EN LA CONTRAPORTADA.
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA.
ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
Catalog Number: S700 FORM NO. 90520667
Copyright © 2008 Black & Decker
WARNING: Important Safety Warnings and
Instructions
When using electrical appliances, basic safety precautions should always be followed,
including the following:
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS CAREFULLY BEFORE USING
THE UNIT.
WARNING:
Some cleaning products contain chemicals known to the State
of California to cause cancer, birth defects or other reproductive harm. When using
Scrubber, be sure to read cleaning product labels for any Proposition 65 warnings. Follow
directions on containers of all such products.
WARNING:
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS
• Close supervision is necessary when any appliance is used by or near children. Do not allow
to be used as a toy.
• To protect against risk of electrical shock, do not put Battery Charger in water or other liquid.
• Do not operate in the presence of explosives and/or flammable fumes or liquids.
• Always use proper eye protection when using the Scrubber with irritating substances. You
may also want to use rubber gloves. Read and follow manufacturer's instructions on the
cleaning product you use.
• Always store unit indoors.
• Keep hair, loose clothing, and all parts of body away from moving parts.
• Do not insert attachments/accessories while unit is running.
• Do not use or immerse unit without Charging Port Plug in place.
• Store out of reach of children.
• This appliance is intended for household use only and not for commercial or industrial use.
• Use only as described in this manual. Use only Black & Decker recommended attachments.
SAFETY GUIDELINES - DEFINITIONS
It is important for you to read and understand this manual.
The information it contains relates to protecting YOUR SAFETY and PREVENTING
PROBLEMS. The symbols below are used to help you recognize this information.
DANGER:
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING:
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderate injury.
CAUTION:
Used without the safety alert symbol indicates a potentially hazardous situation
which, if not avoided, may result in property damage.
Important Safety Instructions for the Battery And Charger
• Do not charge a battery if it is wet or shows any evidence of corrosion.
• Do not incinerate the battery. It can explode in a fire. A small leakage from the battery cell
may occur under extreme usage, charging, or temperature conditions. This does not indicate
a failure. However, if the outer seal is broken and this leakage gets on your skin:
Wash quickly with soap and water or neutralize with a mild acid such as lemon juice
or vinegar, if the liquid gets into the eyes, flush them immediately with clean water for a
minimum of 10 minutes. Seek medical attention.
NOTE: The liquid is a 20-35% solution of potassium hydroxide.
• Do not use an extension cord. Plug the Charger directly into an electrical outlet.
Catalog Number:
S700
B & D
B & D
LACK ECKER
LACK ECKER
D D . . /N /N O O
ECKER ECKER COM COM EW EW WNER WNER
. .
YOUR YOUR NEW NEW PRODUCT PRODUCT
PRINTED IN CHINA
JAN. '08
• Use the Charger only in a standard electrical outlet (120V/60Hz).
• Do not attempt to use this charger with any other product; do not attempt to charge this
product with any other charger. Use only the charger supplied by the manufacturer to
recharge.
• Do not use Charger in wet or damp conditions. It is intended for indoor use only. Do not
use the Charger near sinks, or tubs. Do not immerse in water.
• Do not allow the cord to hang over the edge of a table or counter or touch hot surfaces.
The Charger should be placed away from sinks and hot surfaces.
• Do not operate Charger with damaged cord or plug — have them replaced immediately.
• Do not operate Charger if it has received a sharp blow, been dropped, or otherwise
damaged in any way. Return the appliance to any authorized service facility for
examination, repair, or electrical or mechanical adjustment. Do not disassemble Charger.
• For best results, do not charge a battery when it or air temperature is BELOW 40°F (5°C) or
above 105°F (40°C).
• Unplug the Charger when not in use and before cleaning or maintenance.
• Do not abuse the cord. To reduce the risk of damage to the electric plug or cord, never
carry the Charger by its cord or yank the cord to disconnect; instead, grasp the Charger
plug and pull to disconnect. Keep Charger cord away from heat, oil, and sharp edges.
• The charger supplied with this product is intended to be plugged in such that it is correctly
orientated in a vertical or floor mount position.
SAVE THESE INSTRUCTIONS
A
2
!
!
1
B
2
10
11
D
14
Before First Use and Tips
• The battery is not fully charged when packed in the carton. Charge the battery for at least
16 hours before first use. See "Charging the Battery".
Charging the Battery: (Fig. B)
When disconnecting the Scrubber from the charger, be sure to unplug the charger from the
outlet first, then disconnect the charger cord from the Scrubber. The tool can be left on
charge for as long as you desire, a minimum charge of 16 hours is required to recharge a
completely discharged tool.
1. Remove the Charging Port Plug (10) on the end of the handle. Plug in the Output Cord
(11) of the Battery Charger (2) into the socket in the back of the Scrubber.
2. Plug the Battery Charger into a wall plug. The red indicator light on the Battery Charger
will come ON indicating that the battery is charging. This light will remain Red as long as
the unit is connected to the charger. While charging, the Battery Charger may hum and
feel warm to touch. This is normal.
3. If battery does not charge properly:
• check the current at the outlet by plugging in a lamp or other appliance there to see if it
will work,
• see if the outlet is connected to a wall switch which controls the power,
• move the Battery Charger and battery to a surrounding air temperature of +40°F (5°C)
to 105°F (40°C).
4. After charging replace the Charging Port Plug (10). Do not use or immerse unit without
charging port plug in place.
5. DO NOT CONTINUE TO USE THE Scrubber with a depleted battery. The user should
never attempt to remove the Scrubber Handle Cap except to recycle the Battery. The
removal of the Scrubber Handle Cap will affect the operation of the unit.
INSTALLATION INSTRUCTIONS
Accessories:
WARNING:
Scrubber ON/OFF push Switch Button (12) (Fig. C).
NOTE: Some accessories may not be included in your model. Refer to product packaging
for contents. Additional accessories are available at local retailers or by calling, toll-free
1-800-544-6986.
Attaching Roller Brush (3), Pad Holder (4), Radial Brush (8), and Carpet Brush (9)
Accessories: (Fig. C)
Insert the Accessory (3) over the Scrubber Gearbox (13). While slightly pushing, rotate the
Accessory (3) either direction until it engages with the Scrubber Gearbox (13). You will hear
a "click" sound when the Accessory (3) will be fully engaged with the Scrubber Gearbox
(13). To remove, pull the Accessory (3) off the Scrubber Gearbox (13).
Attaching Scrubber Pads (5, 6, and 7): (Fig C)
Attach Scrubber Pad (5, 6, or 7) to the Pad Holder (4) by fixing one of the Scrubber Pad
face to the Pad Holder Hook-and-Loop surface.
Functional Description
4
1. Scrubber
5 2. Battery Charger
3. Roller Brush
4. Pad Holder
6 (x2)
3
5. Heavy Scrubber Pad -
green
6. Coarse Scrubber Pad -
7
light blue (2)
7. Mild Scrubber Pad -
white
9
8. Radial Brush
9. Carpet Brush
8
C
12
1
E
Do not install/remove accessory while unit is running. To turn
4
5,6
or 7
3
13
15
