Zamel GRM-10 Manual Instruction

PC APPLICATION GRM-10
DESCRIPTION
The application is used to update the software of the GRM-10 device and its configura-
tion by means of a PC. In order to perform all the above activities it is necessary to con-
nect the GRM-10 device with a computer (PC) by means of a USB Micro B / USB A cable.
APPLICATION APPEARANCE
MAIN WINDOW - PARAMETERS SECTION
The window is used to configure the basic GRM-10 controller parameters (a password to control the text message, confirmations,
MODBUS communication parameters, IN1 / IN2 inputs configuration, OUT1 / OUT2 outputs configuration).
Configuration block.
Passwords to text messages.
Confirmations.
A configuration block of
transmission parameters.
Input configuration block.
MAIN WINDOW - TELEPHONE SECTION
The window is used to configure the telephone numbers, which have the access authorisation to control the GRM-10 device by means
of calling signals (CLIP) and authorisations connected with reporting and administration.
The block is used to add a new user's
telephone number:
Name / Surname / Number start with +48
Numbers authorised to
a remote control.
All telephone numbers.
MAIN WINDOW - EXTA FREE SECTION
The window is used to configure commends controlling the EXTA FREE system receivers.
Edition of commands /
Sending commands
(programming).
Numbers of buttons.
A section of configuration parameters adjustment.
A section of software update.
MANUAL INSTRUCTION
ul. Zielona 27
43-200 Pszczyna, Poland
Tel. +48 (32) 210 46 65
Fax +48 (32) 210 80 04
e-mail: marketing@zamel.pl
www.zamelcet.com
Blok
konfiguracji
wyjść.
Telephone numbers
authorised to control CLIP
and to control In the gate
mode (GATE)
– maximum 500 numbers.
Telephone numbers
that will receive
the confirmations.
The block is used to add
a new command
controlling the
EXTA FREE system
receivers.
Control
commands.
