- Page 1 INSTRUCTION MANUAL Demolition Hammer HM1205C DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model HM1205C Blows per minute 950 - 1,900 min Overall length 576 mm Net weight 9.7 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change with- out notice. - Page 3 14. Remove any adjusting key or wrench before HAMMER SAFETY WARNINGS turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may Wear ear protectors. Exposure to noise can result in personal injury. cause hearing loss.
-
Page 4: Functional Description
Number on adjusting dial Blows per minute FUNCTIONAL 1,900 DESCRIPTION 1,700 1,450 1,200 CAUTION: • Always be sure that the tool is switched off and CAUTION: unplugged before adjusting or checking function • The speed adjusting dial can be turned only as on the tool. - Page 5 If the bit cannot be pushed in, remove the bit. Pull the Side handle (auxiliary handle) releasing cover down a couple of times. Then insert the bit again. Turn the bit and push it in until it engages. ► 1. Side handle 2. Clamp nut After installing, always make sure that the bit is securely The side handle can be swung 360°...
-
Page 6: Operation
Authorized Service Centers only. This tool requires no hourly or daily lubrication because it has a grease-packed lubrication system. It should be relubricated regularly. Send the complete tool to Makita Authorized or Factory Service Center for this lubrication service. To maintain product SAFETY and RELIABILITY, repairs,... - Page 8 Makita Corporation 885244A1 20160525 www.makita.com...
