- Page 1 INSTRUCTION MANUAL Electric Breaker HM1511 HM1501 HM1512 HM1502 DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: HM1511 HM1501 HM1512 HM1502 Blows per minute 1,300 min Overall length 781 mm 809 mm Net weight 19.2 kg 18.4 kg 20.4 kg 19.7 kg Safety class Soft no-load rotation function • Due to our continuing program of research and development, the specifications herein are subject to change without notice. - Page 3 Personal safety Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power Stay alert, watch what you are doing and use common tool before making any adjustments, changing accesso- sense when operating a power tool. Do not use a power ries, or storing power tools.
-
Page 4: Indicator Lamp
Soft no-load rotation function CAUTION: Before plugging in the tool, always (For Model HM1511, HM1512 only) check to see that the switch lever actuates prop- Blows at no load per minute becomes smaller than erly and returns to the "OFF" position. - Page 5 For Model HM1511, HM1501 only Side handle (auxiliary handle) With the notched portion on the shank of the bit fac- ing toward the tool retainer, insert the bit into the tool holder as far as it will go.
- Page 6 To install the bit, follow either procedure (1) or (2) described below. To secure the bit, pivot the tool retainer as shown in the figure. NOTICE: The bit without a collar cannot be retained When the bit is retained by procedure (1). For bits with a collar Pivot the tool retainer as shown in the figure.
-
Page 7: Operation
Connect the hose to the hose of the vacuum cleaner with the hose joint. NOTE: If the hose is not included, attach the dust cover to the cleaner's joint or attach it to Makita's hose ø28. 7 ENGLISH... -
Page 8: Maintenance
Always be sure that the tool is These accessories or attachments switched off and unplugged before attempting to are recommended for use with your Makita tool perform inspection or maintenance. specified in this manual. The use of any other accessories or attachments might present a risk of...
